Connecting the parking-brake signal and the reverse signal
A connecting point for the parking-brake signal
(example)
A connecting point for the reverse signal
(example)
254
● Warning ●
Verify the parking-brake signal and the reverse signal before
making the signal connection. Using the wrong wires may cause
accidents or malfunctions.
● Note ●
The connecting point for the parking-brake signal and the reverse
signal may vary with models and grades. Check with your nearest
car dealer regarding remove details.
HAND OPERATED
PARKING BRAKE
PARKING BRAKE
SIGNAL-CABLE
FOOT OPERATED
PARKING BRAKE
ATTACH A SPLICING
CONNECTOR AT THIS LOCATION
REVERSE SIGNAL CABLE
ATTACH A SPLICING
CONNECTOR AT THIS LOCATION
PARKING BRAKE
LAMP
REVERSE LAMP
REVERSE SIGNAL CABLE
