Basic operation
Display open/tilt/close

Adjusting the angle of the display

With the display open, press
OPEN·TILT
second.
● The display setting screen will appear.
Touch
TILT
● The display will tilt upwards by one
step (5°). Each touch of switch tilts the
panel by another step.
● The display can be adjusted to 7
different tilt positions. (Front Position)
(Rear Position: 5 tilt positions)
After completing the adjustment,
press
OPEN·TILT
Do not attempt to manually adjust the display.
Applying excessive force to the display could damage it.
The adjusted display angle will be saved. When reopened, the display will
automatically return to this angle.
42
for less than 1
.
.
OPEN·TILT
button
OPEN·TILT
button
