Using the show platform forward Command

The no debug all privileged EXEC command disables all diagnostic output. Using the no debug all
command is a convenient way to ensure that you have not accidentally left any debug commands
enabled.

Redirecting Debug and Error Message Output

By default, the network server sends the output from debug commands and system error messages to the
console. If you use this default, you can use a virtual terminal connection to monitor debug output
instead of connecting to the console port.
Possible destinations include the console, virtual terminals, internal buffer, and UNIX hosts running a
syslog server. The syslog format is compatible with 4.3 Berkeley Standard Distribution (BSD) UNIX
and its derivatives.
Note Be aware that the debugging destination you use affects system overhead. Logging messages to the
console produces very high overhead, whereas logging messages to a virtual terminal produces less
overhead. Logging messages to a syslog server produces even less, and logging to an internal buffer
produces the least overhead of any method.
For more information about system message logging, see
Logging."
Using the show platform forward Command
The output from the show platform forward privileged EXEC command provides some useful
information about the forwarding results if a packet entering an interface is sent through the system.
Depending upon the parameters entered about the packet, the output provides lookup table results and
port maps used to calculate forwarding destinations, bitmaps, and egress information.
For more syntax and usage information for the show platform forward command, see the command
Note
reference for this release.
Most of the information in the output from the command is useful mainly for technical support
personnel, who have access to detailed information about the switch application-specific integrated
circuits (ASICs). However, packet forwarding information can also be helpful in troubleshooting.
This is an example of the output from the show platform forward command on port 1 in VLAN 5 when
the packet entering that port is addressed to unknown MAC addresses. The packet should be flooded to
all other ports in VLAN 5.
Switch# show platform forward gigabitethernet0/1 vlan 5 1.1.1 2.2.2 ip 13.1.1.1 13.2.2.2
udp 10 20
Global Port Number:24, Asic Number:5
Src Real Vlan Id:5, Mapped Vlan Id:5
Ingress:
Lookup
InptACL
L2Local
Station Descriptor:02340000, DestIndex:0239, RewriteIndex:F005
==========================================
Cisco Catalyst Blade Switch 3020 for HP Software Configuration Guide
29-16
Key-Used
40_0D020202_0D010101-00_40000014_000A0000
80_00050002_00020002-00_00000000_00000000
Chapter 29
Chapter 24, "Configuring System Message
Index-Hit A-Data
01FFA 03000000
00C71 0000002B
