Cisco PIX 520 - PIX Firewall 520 Online Help Manual page 94

Source Name
Destination Address
Destination Name
Action
Service
These let you select a data type on which the search will be performed. On the right side are
list boxes in which the actual pattern to be matched can be entered. For each field Browse (...)
will display a list of items that are appropriate for the selected data type.
Search—Clicking this button initiates the search function. Results will be highlighted in yellow on PDM.
Reset—Clicking this button clears the search panel so the choices can be reentered.
Help—Provides more information.
Close—Clears any changes you may have made and closes this panel.
The Search by Field>Search dialog box opened from the Translation Rules tab lets you search for translation
rules by the following methods:
Type—The type of translation. In this case the options are
Original Interface—The interface where the translation originates.
Original Address—The original address that is to be translated.
Translated Interface—The address where the translation occurs.
Translated Address—The address to which the original address is translated.
Name—The name of the host or network.
Search—Clicking this button initiates the search function. Results will be highlighted in yellow on PDM.
Close—Clicking this button clears any changes you may have made and closes this panel.
Help—Provides more information.
Reset—Clicking this button clears the search panel so choices can be reentered.
Searching for Access Rules Containing a Pattern
Follow these steps to search for an access rule containing a pattern:
1. Click Search>Search by Field.
2. Click Match any of the following or Match all of the following.
3. From the search criteria option lists on the left, select the type of data to be searched.
4. In the boxes on the right either enter or select the pattern to be matched. To select a pattern, click Browse
and select the desired item from the list of items displayed. To enter a pattern, type the pattern in the box.
Partial patterns are allowed on the following search criteria options:
Source Address
Source Name
Destination Address
Destination Name
Static and Dynamic.
