5. Locate the battery on the system board.
Figure 13. Battery location.
6. To remove the battery, use your finger to press down on one side of the battery; Then slide the
battery from the socket. The spring mechanism will push the battery out towards you as you
slide it from the socket.
7. Insert the new battery:
a. Tilt the battery so that you can insert it into the socket.
b. As you slide the battery into place, press the battery down into the socket.
42
Battery
Intel Server Compute Blade SBX82 Installation and User's Guide
