Ilo 3 Mp Lan; Hp-Ux; Setup Checklist - HP Integrity rx2800 - i2 User's & Service Manual

IMPORTANT:
operating system to interact with the server. This symptom can be misinterpreted as a system hang.

iLO 3 MP LAN

DHCP with DNS is the HP-recommended method to configure the LAN. DHCP with DNS comes
preconfigured with default factory settings, including a default user account and password. By
default, the iLO 3 MP LAN uses DHCP to retrieve a new LAN address for itself. When this occurs,
the default DNS name is set to mp<MACADDRESS>.
The MAC address for the iLO 3 MP LAN is printed on a label on the server. If Dynamic DNS
(DDNS) is enabled in the data center, the DNS server automatically registers the new name and
enables you to access iLO 3 through the web browser by entering https://mp<MACADDRESS>/.
For information on iLO 3, see the HP Integrity Integrated Lights-Out 3 Operations Guide on the HP
website at: http://www.hp.com.

HP-UX

The HP-UX operating system uses the console connection of the iLO 3 MP as the default console.
However, if the iLO 3 MP console path is not selected in the UEFI Boot Manager Console
Configuration menu, HP-UX messages may not be presented to the console device. Also, HP-UX
systems should have only one console path selected in the UEFI Boot Manager Console Configuration
menu.
You can also use VGA to connect consoles that use HP-UX operating system.
For information on changing the default console and using the UEFI Boot Manager Configuration
Options, see Selecting Your HP-UX Console in the HP-UX Installation and Update Guide on the HP
website at: http://www.hp.com/go/hpux.

Setup checklist

Use the checklist in
Table 17 Setup checklist
Step Action
Standard setup
1 Preparation
2 Configure the iLO 3 MP LAN
3 Log on to the iLO 3 MP
4 Change default user name and
password
5 Set up user accounts
6 Set up security access
Failure to properly configure the console device can result in the inability of the
Table 17 while setting up the Integrity iLO 3.
Procedure
a. Determine an access method to select and connect the
cables.
b. Determine a LAN configuration method and assign an IP
address if necessary.
Select one of the three methods to configure the LAN for iLO
3 MP access:
DHCP with DNS
RS-232 serial port
Static IP address
Log on to the iLO 3 MP from a supported web browser or
command line using the default user name and password.
Change the default user name and password on the
administrator account to your predefined selections.
Set up the user accounts if you are using the local accounts
feature.
Set up the security access settings.
Connecting and setting up the console
Status
