a. Turn off the server power button and unplug the ac power cords and any cables.
b. Re-seat all of the SAS disk drives installed in the server.
c. Reconnect the ac power cords and any cables. Restart the server to determine whether
the LEDs now become illuminated during the boot. If not, contact your reseller.
4. Use the UEFI Shell info io command to check the SCSI drives.

System LAN LEDs

There are four system LAN LEDs on the rear bulkhead of the server. These LANs are connected to
the system board.
Table 44 Gb LAN connector LEDs
LED
Link (left)
Activity (right)

Troubleshooting the boot process

Table 45 shows the normal boot process, as reflected in changes to front panel LED states:
Table 45 Normal boot process LED states
Step System Event
Log
1 Off
2 Off
3 Off
4 Off
5 Off
6 Steady green
NOTE: In the normal boot process, shown in the preceding table, even though the BMC is running
while the system is shut down (power LED is steady amber), it doesn't drive the external health LED
to steady green until +12 V dc power from the Bulk Power Supplies is applied.
The following list itemizes the steps that characterize basic platform boot flow. Step numbers
provided correspond to the steps in
3) System power switch turns on bulk power supplies and fans, and releases RESET on all CPUs
simultaneously, when toggled on.
5) Initial CPU firmware code fetch is PAL code from EEPROM in PDH, retrieved 4 bytes at a time
by DMDC in ICH10 (No shared memory or I/O devices are available at this time; for example
they are not initially configured).
Description
Green: link
Off: no link
Green: link
Off: No link
Health Power
Off Off
Off Steady amber
Off Steady green
Steady green Steady green
Steady green Steady green
Steady green Steady green
Table 45 (page
SID Normal power-up through OS boot
Off No ac power to the system.
Off System is shut down, but ac power
and standby power is active.
Off System power rails are on when
power switch is toggled.
Off System power rails are on; BMC
drives external health LED.
Off System is booting firmware (has
passed BOOT_START in firmware).
Off System has finished booting
firmware and an OS is either
booting or running.
93).
Troubleshooting the boot process 93
