Figure 10 Rear panel components
PCI 5
1
PCI 6
2
PCI 4
3
PCI 2
4
PCI 3
5
PCI 1
6
Power supply 2
7
Power supply 2 LED
8
Figure 1 1 Rear panel LEDs and buttons
Power supply LED
1
UID LED/button
2
20 Overview
Power supply 2 power
9
connector
Power supply 1
10
Power supply 1 LED
1 1
Power supply 1 power
12
connector
UID LED button
13
USB connectors (2)
14
Video connector
15
NIC 1 connector
16
NIC link LED
3
NIC activity LED
4
NIC 2 connector
17
Physical presence
18
Serial connector
19
iLO 3 connector
20
NIC 3 connector
21
NIC 4 connector
22
NIC link LED
23
NIC activity LED
24
iLO 3 physical presence
5
button
