Controls, ports, and LEDs
Front panel controls, ports, and LEDs
Figure 5 Front Panel Controls, Ports, and LEDs
Quick release levers
1
iLO3 toe tag
2
SID
3
Optical drive bay
4
Figure 6 Front panel LEDs and buttons
UID LED and button
1
Table 4
lists the front panel controls.
16
Overview
Hard drive bays
5
Video connector
6
USB connectors
7
System health LED
2
Power button
3
