TJERNLUND PRODUCTS, INC.
1601 Ninth Street • White Bear Lake, MN 55110-6794
PHONE (800) 255-4208 • (651) 426-2993 • FAX (651) 426-9547
Visit our web site • www.tjernlund.com
INSTALLATION INSTRUCTIONS
!
Recognize this symbol as an indication of important safety information!
OWNER INSTRUCTIONS, DO NOT DESTROY
NOTE: MAXIMUM FLUE GAS TEMPERATURES MUST NOT EXCEED 650 o F.
THESE INSTRUCTIONS ARE INTENDED AS AN AID TO QUALIFIED, LICENSED SERVICE
PERSONNEL FOR PROPER INSTALLATION, ADJUSTMENT AND OPERATION OF THIS
UNIT. READ THESE INSTRUCTIONS THOROUGHLY BEFORE ATTEMPTING INSTALLA-
TION OR OPERATION. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN
IMPROPER INSTALLATION, ADJUSTMENT, SERVICE OR MAINTENANCE POSSIBLY
RESULTING IN FIRE, ELECTRICAL SHOCK, CARBON MONOXIDE POISONING, EXPLO-
SION, PERSONAL INJURY OR PROPERTY DAMAGE.
DO NOT DESTROY. PLEASE READ CAREFULLY AND
KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
Copyright © 1998, Tjernlund Products, Inc. All rights reserved
56826
MODEL SS2G
REV. 1 11/98
P/N 8504075
Advertisement
Table of Contents
Related Manuals for TJERNLUND SS2G SIDESHOT (DISCONTINUED) 8504075 REV 1 1198
Summary of Contents for TJERNLUND SS2G SIDESHOT (DISCONTINUED) 8504075 REV 1 1198
-
Page 1: Installation Instructions
RESULTING IN FIRE, ELECTRICAL SHOCK, CARBON MONOXIDE POISONING, EXPLO- SION, PERSONAL INJURY OR PROPERTY DAMAGE. DO NOT DESTROY. PLEASE READ CAREFULLY AND KEEP IN A SAFE PLACE FOR FUTURE REFERENCE. Copyright © 1998, Tjernlund Products, Inc. All rights reserved P/N 8504075... -
Page 2: Table Of Contents
SS2G Vent Cabinet Mounting Template ........................14 SideShot ® is a registered trademark of Tjernlund Products, Inc. for their Model SS2G Vent System. DESCRIPTION The SS2G is a mechanical vent system designed and listed for use with natural draft gas heating equipment. It is factory assem- bled and wired. -
Page 3: Installation Restrictions
SPECIFICATIONS Motor: 115/1/60, 3000 RPM, 1/25 HP, 1.6 FLA, Ball Bearing Permanently Lubricated. Fan Proving Switch: Non-adjustable set point of -.40” W.C. on pressure drop. Contacts rated for an inductive load of 6.2 FLA. High Limit: Manual reset N/C contacts, open at 170 o F + 8 o F. Contacts rated at 10 FLA at 120 VAC. Post-Purge Timer: Nonadjustable 24 VAC input, approximately 45 second post-purge delay. -
Page 4: Safety Inspection Of A Previously Used Gas Appliance
Disconnect the power supply when making wiring connections or when working around the fan wheel and motor. Failure to do so can result in electrical shock, personal injury, death or property damage. 1. “Qualified Installer” shall mean an individual properly trained and licensed. 2. -
Page 5: Vent Hood Termination Clearances, Clearances To Combustibles & Obstructions
It is not recommended for the SS2G to be terminated on a wall that faces the direction of the prevailing winds. Backdrafts by severe winds can interrupt equipment operation. DIAGRAM A TJERNLUND SIDESHOT MUST TERMINATE 4 FEET BELOW, 4 FEET HORIZONTALLY FROM OR 1 FOOT ABOVE ANY DOOR, WINDOW OR GRAVITY AIR INLET INTO THE BUILDING. -
Page 6: Installation Tools Required
INSTALLATION TOOLS REQUIRED • • • Nut Runner Set Drill w/Bits Combination Wrench Set • • • Screwdriver Set Wire Cutter/Stripper Draft Gauge • Reciprocating Saw INSTALLING SS2G VENT CABINET 1. a) Fold SS2G Vent Cabinet template (Page 14) along dashed line and attach between the floor joists ensuring that it is snug against the sill plate and centered between the floor joists. -
Page 7: Vent System Installation
8. Slide the SS2G vent cabinet through the wall with drip DIAGRAM F flange facing down towards ground, (See Diagram F). Mount Vent Hood to exterior using (6) #10 x 1 1/4” wood screws provided, (See Diagram F). If installing in masonry wall drill 1/4”... -
Page 8: Installation Of Vent Pipe
INLET PIPE INSTALLATION 1. Remove 4” round inlet pipe from box. DIAGRAM I 2. Align the 4 slots of the inlet pipe to the 3 pins and proving switch sensing tube, push pipe up until it bottoms out in the SS2G inlet. 3. -
Page 9: Ss2G Wiring With Single Zone Thermostat
NOTE: When Power Venter is interlocked with a thermostat wire all zones, circulators and limits as would normally be done if venting into a chimney. If you are unable to wire the SS2G as outlined in these instructions, call Tjernlund’s Customer Service Department toll free at 1-800-255-4208 for assistance. -
Page 11: Draft Adjustment Procedure
DRAFT ADJUSTMENT PROCEDURE The SS2G Vent System will properly vent a wide range of BTU/hr. input capacities. To compensate for different burner capacities, vent connector lengths, types and sizes, it features a draft adjustment located on the back of the venter assembly. Turning this draft adjustment knob clockwise will increase draft and raise the BTU capacity. -
Page 12: Troubleshooting Electrical Problems
Extreme caution must be exercised to prevent injury. If you are unable to determine the defective part with the use of this guide, call your Tjernlund distributor or Tjernlund Products direct at 1-800-255-4208 for further assistance. - Page 13 SYMPTOM 3: APPLIANCE WILL NOT OPERATE, BUT SS2G DOES Step1. Set draft adjustment according to "Draft Verify draft adjustment has been made. Adjustment Procedure" on page 10. SS2G and appliance are not interlocked Step 2. correctly or malfunction of appliance controls. With the appliance calling for heat and SS2G Refer to electrical diagrams in this manual and operating, verify 24V exists between SS2G &...
-
Page 14: Maintenance
TJERNLUND LIMITED TWO YEAR WARRANTY Tjernlund Products, Inc. warrants to the original purchaser of this product that the product will be free from defects due to faulty material or workmanship for a period of (2) years from the date of original purchase or delivery to the original purchaser, whichever is earlier.
