Filter-id = "internet_access"
3 The DiffServ policy specified in the attribute must already be configured on the switch, and the policy
names must be identical.
For information about configuring a DiffServ policy, see "Differentiated Services" on page 137. The
section, "Example #1: DiffServ Inbound Configuration" on page 138," describes how to configure a
policy named internet_access.
NOTE:
If the policy specified within the server attribute does not exist on the switch, authentication will fail.

Access Control Lists (ACLs)

This section describes the Access Control Lists (ACLs) feature.

Overview

Access Control Lists (ACLs) are a collection of permit and deny conditions, called rules, that provide
security by blocking unauthorized users and allowing authorized users to access specific resources.
ACLs can also provide traffic flow control, restrict contents of routing updates, and decide which types of
traffic are forwarded or blocked. Normally ACLs reside in a firewall router or in a router connecting two
internal networks.
The PowerConnect M6220/M6348/M8024 switches support ACL configuration in both the ingress and
egress direction. Egress ACLs provide the capability to implement security rules on the egress flows
rather than the ingress flows. On the M6348 and M8024 switches, ingress and egress ACLs can be
applied to any physical port (including 10G), port-channel, or VLAN routing port. On the M6220, egress
ACLs may only be applied to physical ports and may only be IPv4 ACLs (not MAC or IPv6 ACLs).
Ingress ACLs support Flow-based Mirroring and ACL Logging, which have the following characteristics:
• Flow-based mirroring is the ability to mirror traffic that matches a permit rule to a specific physical
port or LAG. Flow-based mirroring is similar to the redirect function, except that in flow-based
mirroring a copy of the permitted traffic is delivered to the mirror interface while the packet itself is
forwarded normally through the device. You cannot configure a given ACL rule with mirror and
redirect attributes.
• ACL Logging provides a means for counting the number of "hits" against an ACL rule. When you
configure ACL Logging, you augment the ACL deny rule specification with a "log" parameter that
enables hardware hit count collection and reporting. The switch uses a fixed five minute logging
interval, at which time trap log entries are written for each ACL logging rule that accumulated a non-
zero hit count during that interval. You cannot configure the logging interval.
Using ACLs to mirror traffic is called flow-based mirroring since the traffic flow is defined by the ACL
classification rules. This is in contrast to port mirroring, where all traffic encountered on a specific
interface is replicated on another interface.
You can set up ACLs to control traffic at Layer 2, Layer 3, or Layer 4. MAC ACLs operate on Layer 2. IP
ACLs operate on Layers 3 and 4.
