IBASE Technology AGS104L User Manual

Ultra-compact iot gateway edge computing system with intel atom x7211re processors
Hide thumbs

Advertisement

Quick Links

Download this manual
AGS104L
Ultra-Compact IoT Gateway
Edge Computing System with
Intel® Atom® x7211RE Processors
User's Manual
Version 1.0
(April 2025)

Advertisement

loading
Need help?

Need help?

Do you have a question about the AGS104L and is the answer not in the manual?

Questions and answers

Related Manuals for IBASE Technology AGS104L

Summary of Contents for IBASE Technology AGS104L

  • Page 1 AGS104L Ultra-Compact IoT Gateway Edge Computing System with Intel® Atom® x7211RE Processors User’s Manual Version 1.0 (April 2025)
  • Page 2 Disclaimer otherwise—without prior written consent from IBASE Technology, Inc. IBASE reserves the right to make changes and improvements to the products described in this document without prior notice. Every effort has been made to ensure the accuracy of this document;...
  • Page 3 • Cadmium: 100 ppm • Mercury: 1,000 ppm • Lead: 1,000 ppm • Bis(2-ethylhexyl) phthalate (DEHP): 1,000 ppm • Butyl benzyl phthalate (BBP): 1,000 ppm • Dibutyl phthalate (DBP): 1,000 ppm • Diisobutyl phthalate (DIBP): 1,000 ppm AGS104L User’s Manual...
  • Page 4 Avoid Disassembly Do not disassemble, repair, or modify the device, as doing so may cause damage, pose safety hazards, or result in injury. Additionally, any unauthorized modifications will void the warranty. AGS104L User’s Manual...
  • Page 5 Detailed description of the problem • The error messages in text or in screenshots if there is any • The arrangement of the peripherals • Software in use (such as OS and application software, including the version numbers) AGS104L User’s Manual...
  • Page 6 J8: M.2 (B-Key) Socket ............27 2.4.18 J11: Nano SIM Card Slot (for M.2 B-Key socket) ....28 2.4.19 J12: M.2 (E-Key) Socket ............28 2.4.22 J14: Mini PCIe Socket ............29 2.4.23 CN9/CN10: COM1/COM2 Connector ........30 AGS104L User’s Manual...
  • Page 7 Advanced Settings ................47 Chipset Settings ..................56 Security Settings ................... 58 Boot Settings..................59 Save & Exit Settings................60 Appendix ...................... 61 I/O Port Address Map ................62 Interrupt Request Lines (IRQ) ............... 64 Watchdog Timer Configuration .............. 65 AGS104L User’s Manual...
  • Page 9 Chapter 1 General Information The information provided in this chapter includes: • Introduction • Features • Specifications • Product View • Dimensions...
  • Page 10 2.5G LAN ports, three USB 3.2 ports, and two COM ports (RS232/422/485) for industrial control and data transmission. Designed for harsh environments, the AGS104L supports a wide operating temperature range from -40°C to 70°C and includes a 9V to 36V DC wide-range power input with overvoltage, undervoltage, and reverse voltage protection.
  • Page 11 • 1x Power button with Green LED • 1x 3-pin DC-in terminal block for 9V-36V • 1x Antenna hole • 2x RS232/422/485 ports for COM#1/COM#2 Left Panel External I/O • 1x Antenna hole • 1x Line-out/ Mic-in AGS104L User’s Manual...
  • Page 12 Relative Humidity 5~90% @ 45°C, (non-condensing) • Vibration Operating: 0.5Grms / 5~500Hz • Non-operating: 1Grms / 5~500Hz • Shock Operating: 30G/11 ms Duration • Non-operating: 40G/11 ms Duration All specifications are subject to change without prior notice. AGS104L User’s Manual...
  • Page 13 General Information 1.4 Product View AGS104L User’s Manual...
  • Page 14 No. Name No. Name Power button Antenna holes* DC-In (9V ~ 36V ) 8 Type C connector USB 3.2 Ports SIM card slot GbE LAN Ports Line Out / Mic In DisplayPort COM1/COM2 ports HDMI AGS104L User’s Manual...
  • Page 15 General Information Wall Mounting DIN Rail Mounting (optional) AGS104L User’s Manual...
  • Page 16 1.5 Dimensions Unit: mm AGS104L User’s Manual...
  • Page 17 Chapter 2 Hardware Configuration The information provided in this chapter includes: • Installations • Information and locations of connectors...
  • Page 18 2. Gently push the module in an upright position until the clips of the slot close to hold the module in place when the module touches the bottom of the slot. To remove the module, press the clips outwards with both hands, and the module will pop-up. AGS104L User’s Manual...
  • Page 19 1. Thread and fasten the hex nut and the 2. Apply adhesive around here. washer. Then install the antenna. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). AGS104L User’s Manual...
  • Page 20 2.1.4.1. Wall-Mounting Installation 1. Turn your product upside down to attach the mounting brackets to your product and secure with the supplied 4 screws. 2. Prepare at least 4 screws (M3) to install the device on wall. AGS104L User’s Manual...
  • Page 21 1. Attach the DIN rail mounting bracket to your product, and secure with the supplied 2 screws. 2. Hook the DIN rail mounting bracket over the top of the DIN rail, and then press the lower section of the bracket towards the DIN rail to clip the bracket onto it. AGS104L User’s Manual...
  • Page 22 RS-422 RS-485 DCD, Data carrier detect DATA- RXD, Receive data DATA+ TXD, Transmit data DTR, Data terminal ready RX- Ground Ground Ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator AGS104L User’s Manual...
  • Page 23 Hardware Configuration 2.1.5.2. DC-In Power Connector (3-pin terminal block) Pin Assignment Pin Assignment Power Ground 9V ~ 36V Case Ground 2.1.5.3. Audio Line-Out Jack AGS104L User’s Manual...
  • Page 24 Open When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. AGS104L User’s Manual...
  • Page 25 Hardware Configuration 2.3 Motherboard Jumper & Connector Locations MBE104T-1 Motherboard AGS104L User’s Manual...
  • Page 26 AGS104L User’s Manual...
  • Page 27 Hardware Configuration 2.4 Motherboard Jumpers and Connectors 2.4.1 JP3: Mini PCIe Select for PCIe or mSATA Function Pin closed Illustration mSATA PCIe (default) AGS104L User’s Manual...
  • Page 28 2.4.2 JP2: Power Failure Mode Setting Function Pin closed Illustration ATX Mode (default) AT Mode 2.4.3 SW2: Clear CMOS Setting Function Setting Normal (default) P1-OFF Clear CMOS P1-ON AGS104L User’s Manual...
  • Page 29 Hardware Configuration 2.4.4 J3/SW1: Power Button and Power On LED Connector J3: TECHBEST_01017021001-L Pin Signal Name Ground Power Button AGS104L User’s Manual...
  • Page 30 2.4.5 CN1: USB 3.2 Connector 2.4.6 CN3: USB 3.2 Dual Connector 2.4.7 CN4, CN5: RJ-45 Connector (I226IT) AGS104L User’s Manual...
  • Page 31 Hardware Configuration 2.4.8 CN6: DP Connector 2.4.9 CN7: HDMI Connector AGS104L User’s Manual...
  • Page 32 2.4.10 CN2: Type-C Connector 2.4.11 CN8: Audio Connector AGS104L User’s Manual...
  • Page 33 Hardware Configuration 2.4.12 J1: Nano SIM Card Slot (for Mini PCIe socket) 2.4.13 J2: Reset Button Connector J2: TECHBEST_01017021001-L Pin Signal Name Ground Reset Button AGS104L User’s Manual...
  • Page 34 2.4.14 J4: SPI Flash Connector 2.4.15 J6: DC-in Connector (DINKLE_ECH381RM-03P) Signal Name Power Ground Case Ground +9V to +36V AGS104L User’s Manual...
  • Page 35 Hardware Configuration 2.4.16 J7: Memory Socket 2.4.17 J8: M.2 (B-Key) Socket AGS104L User’s Manual...
  • Page 36 2.4.18 J11: Nano SIM Card Slot (for M.2 B-Key socket) 2.4.19 J12: M.2 (E-Key) Socket ◆ J12: For WLAN & BT connection (PCIe + USB2.0) AGS104L User’s Manual...
  • Page 37 Hardware Configuration 2.4.20 J14: Mini PCIe Socket ◆ J14 supports mSATA [USB 2.0 + PCIe + SATA] AGS104L User’s Manual...
  • Page 38 RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator GND, ground Not Used Pin # Signal Name RS-232 R2-422 RS-485 DATA- DATA+ Ground Ground Ground AGS104L User’s Manual...
  • Page 39 Hardware Configuration 2.4.22 LED2: Blue LED Indicator for WLAN Status AGS104L User’s Manual...
  • Page 40 2.4.23 LED3: Red LED Indicator for SSD Status 2.4.24 LED4: Yellow LED Indicator for B-Key WWAN Status AGS104L User’s Manual...
  • Page 41 Chapter 3 Driver Installation The information provided in this chapter includes: • ® Intel Chipset Software Installation Utility • Graphics Driver Installation • HD Audio Drivers Installation • ® Intel ME Drivers Installation • ® Intel Serial I/O Drivers Installation •...
  • Page 42 Chipset drivers should be installed first before the software drivers to install INF files for Plug & Play function for the chipset components. Follow the instructions below to complete the installation. 1. Click Intel and then Intel(R) Amston Lake Chipset Drivers. AGS104L User’s Manual...
  • Page 43 Chipset Device Software appears, click Next. 4. Accept the terms of the software license agreement. Click Next. 5. On the Readme File Information screen, click Install and then Next. 6. When the driver is completely installed, click Finish. AGS104L User’s Manual...
  • Page 44 3.3 Graphics Driver Installation 1. Click Intel and then Intel(R) Amston Lake Chipset Drivers. 2. Click Intel(R) Amston Lake Graphics Driver. 3. In the Intel Software License Agreement screen, click I agree. AGS104L User’s Manual...
  • Page 45 Driver Installation 4. Click Start for the Installer to install the components shown below. 5. You need to restart your system in order to apply the driver changes. Click Finish. AGS104L User’s Manual...
  • Page 46 2. Click Intel(R) Amston Lake Graphics Driver. 3. Agree to the terms of the license agreement, and click Next. 4. Click Next to install the components shown below. 5. After installation has been completed, restart your system. Click Finish. AGS104L User’s Manual...
  • Page 47 1. Click Intel and then Intel(R) Amston Lake Chipset Drivers. 2. Click Realtek High Definition Audio Driver. 3. On the Welcome screen of the InstallShield Wizard, click Next. 4. After installation has been completed, restart the computer for changes to take effect. AGS104L User’s Manual...
  • Page 48 3.6 Realtek Audio DCH Drivers Installation 1. Click Intel and then Intel(R) Amston Lake Chipset Drivers. 2. Click Realtek Audio DCH Drivers. 3. On the Welcome screen of the InstallShield Wizard, click Next. 4. After installation has been completed, restart the computer. AGS104L User’s Manual...
  • Page 49 1. Click Intel and then Intel(R) Amston Lake Chipset Drivers. 2. On the Welcome screen, click Next. 3. Click Next to accept the destination folder or click Change to choose another destination folder. 4. Click Finish when you have installed the ME components. AGS104L User’s Manual...
  • Page 50 3. When the Welcome screen appears, click Next to continue. 4. Accept the terms of the license agreement and click Next. 5. On the Readme File Information screen, click Next. 6. On the Confirmation screen, click Next. 7. On the Completion screen, click Finish. AGS104L User’s Manual...
  • Page 51 3.9 LAN Driver Installation 1. Click LAN Card on the left and then Intel LAN Controller Drivers. 2. Click Intel(R) I21x Gigabit Network Drivers. 3. Click Install Drivers. 4. After the drivers have been successfully installed, click Close. AGS104L User’s Manual...
  • Page 52 Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Security Settings •...
  • Page 53 These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. AGS104L User’s Manual...
  • Page 54 4.3 Main Settings BIOS Setting Description System Date Sets the date. Use the <Tab> key to switch between the date elements. System Time Set the time. Use the <Tab> key to switch between the time elements. AGS104L User’s Manual...
  • Page 55 BIOS Setup 4.4 Advanced Settings This section allows you to configure, improve your system and to set up some system features according to your preference. 4.4.1 CPU Configuration AGS104L User’s Manual...
  • Page 56 Enable/Disable AES (Advanced Encryption Standard) Intel(R) SpeedStep(tm) Allows more than two frequency ranges to be supported Intel(R) Speed Shift Enable/Disable Intel(R) Speed Shift Technology Technology support. Enabling will expose the CPPC v2 interface to allow for hardware controlled P-states. AGS104L User’s Manual...
  • Page 57 BIOS Setup 4.4.2 Power & Performance BIOS Setting Description CPU – Power CPU – Power Management Control Options Management Control AGS104L User’s Manual...
  • Page 58 Enable or Disable Endorsement Hierarchy Hierarchy Physical Presence Select to tell OS to support PPI Spec Version 1.2 or Spec Version 1.3. Note some HCK tests might not support 1.3. Device Select TPM 2.0 will restrict to support TPM 2.0 devices. AGS104L User’s Manual...
  • Page 59 Enables / Disables the system ability to hibernate (OS/S4 Sleep State). This option may not be effective with some OS. ACPI Sleep State Selects a ACPI sleep state for the system to enter. Options: Suspend Disabled, S3 (Suspend to RAM) AGS104L User’s Manual...
  • Page 60 4.4.5 F81964 Super IO Configuration BIOS Setting Description Serial Port Sets Parameters of Serial Ports. Select an optimal Configuration settings for the Super IO device. AGS104L User’s Manual...
  • Page 61 BIOS Setup 4.4.6 Hardware Monitor AGS104L User’s Manual...
  • Page 62 The maximum time the device will take before it properly reports itself to the Host Controller. Auto uses default value. For a Root port, it is 100 ms. For a Hub port, the delay is taken from Hub descriptor. AGS104L User’s Manual...
  • Page 63 BIOS Setup 4.4.8 Network Stack Configuration BIOS Setting Description Network Stack Enables / Disables UEFI Network Stack. AGS104L User’s Manual...
  • Page 64 2048 MB aperture. To use this feature, disable CSM support. PSMI SUPPORT PSMI Enable/Disable DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memeory size used by the Internal Graphics Device Graphics Configuration VT-d capability AGS104L User’s Manual...
  • Page 65 BIOS Setup 4.5.2 PCH-IO Configuration AGS104L User’s Manual...
  • Page 66 Password utility. User Password Sets a user password. Secure Boot Secure Boot feature is Active if Secure Boot is Enabled. Platform Key(PK) is enrolled and the System is in user mode. The mode change requires platform reset. AGS104L User’s Manual...
  • Page 67 Turns on/off the keyboard NumLock state. Quiet Boot Enables / Disables Quiet Boot option. FIXED BOOT ORDER Sets the system boot order PRIORITY UEFI Hard Disk Drive Specifies the boot device priority sequence from BBS Priorities available UEFI hard disk drives. AGS104L User’s Manual...
  • Page 68 Saves the changes done so far as user defaults. Restore User Defaults Restores the user defaults to all the setup options. Launch EFI Shell from Attempts to Launch EFI Shell application filesystem device (Shell.efi) from one of the available filesystem devices. AGS104L User’s Manual...
  • Page 69 Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Watchdog Timer Configuration...
  • Page 70 SMBus - 54A3 0x00003000-0x0000303F Intel(R) UHD Graphics 0x00001854-0x00001857 Motherboard resources 0x00000000-0x00000CF7 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex 0x00003090-0x00003097 Standard SATA AHCI Controller 0x00003080-0x00003083 Standard SATA AHCI Controller 0x00003060-0x0000307F Standard SATA AHCI Controller 0x00002000-0x000020FE Motherboard resources AGS104L User’s Manual...
  • Page 71 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x00000060-0x00000060 Standard PS/2 Keyboard 0x00000064-0x00000064 Standard PS/2 Keyboard AGS104L User’s Manual...
  • Page 72 Intel(R) UHD Graphics IRQ 4294967286~90 Intel(R) Ethernet Controller I226-IT #2 IRQ 4294967291 Intel(R) USB 3.10 eXtensible Host Controller - 1.20 (Microsoft) IRQ 4294967292 Intel(R) USB 3.20 eXtensible Host Controller - 1.20 (Microsoft) IRQ 4294967294 Standard SATA AHCI Controller AGS104L User’s Manual...
  • Page 73 81866 watch dog program\n"); SIO = Init_F81964(); if (SIO == 0) printf("Can not detect Fintek 81866, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); AGS104L User’s Manual...
  • Page 74 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81964_LD(0x07); //switch to logic device 7 bBuf = Get_F81964_Reg(0xFA); bBuf &= ~0x01; Set_F81964_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81964_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81964_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- AGS104L User’s Manual...
  • Page 75 (ucDid == 0x07) //Fintek 81866 goto Init_Finish; } F81964_BASE = 0x00; result = F81964_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81964 (void) outportb(F81964_INDEX_PORT, F81964_UNLOCK); outportb(F81964_INDEX_PORT, F81964_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81964 (void) outportb(F81964_INDEX_PORT, F81964_LOCK); //--------------------------------------------------------------------------- void Set_F81964_LD( unsigned char LD) Unlock_F81964(); AGS104L User’s Manual...
  • Page 76 #define F81964_DATA_PORT (F81964_BASE+1) //--------------------------------------------------------------------------- #define F81964_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81964_UNLOCK 0x87 #define F81964_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81964(void); void Set_F81964_LD( unsigned char); void Set_F81964_Reg( unsigned char, unsigned char); unsigned char Get_F81964_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81964_H AGS104L User’s Manual...
