  • Page 1 AMI210 User Manual 2016 May Ver. A1 IBASE Technology Inc.
  • Page 3 AMI210 User Manual Copyright © 2014 IBASE Technology Inc. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of IBASE Technology INC.

  • Page 4: Table Of Contents

    1.2 System Specifications ..................7 1.2.1 Hardware Specifications ................. 7 1.2.2 Dimensions ....................10 1.2.3 I/O View ...................... 12 1.3 Exploded View of the AMI210/AMI210-PE Assembly ........14 1.3.1 Parts Description ..................15 1.4 Packing List ..................... 18 1.4.1 Optional Items ..................... 18 CHAPTER 2 MOTHERBOARD INTRODUCTION ............

  • Page 5: Setting Up Your System

    AMI210 User Manual Safety Information Your AMI210 is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions Setting up your system ...

  • Page 6: Care During Use

    AMI210 User Manual Care during use  Do not walk on the power cord or allow anything to rest on it.  Do not spill water or any other liquids on your system.  When the system is turned off, a small amount of electrical current still flows.

  • Page 7: Acknowledgments

    FINTEK is a registered trademark of FINTEK Electronics Corporation.  REALTEK is a registered trademark of REALTEK Electronics Corporation.  All other product names or trademarks are properties of their respective owners. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 8: Chapter 1 Introduction

    210mm(W) by 265mm(D) by 134mm(H) for expansion slot version, the AMI210 unit comes with a wall mount kit. We also provide the DC power adaptor for optional item if necessary . The model is currently available with either a 2.5-inch 64GB industrial grade SSD or CFAST slot installation.

  • Page 9: System Specifications

    (2.3Ghz) TDP=45W ® - Intel Core i5-4570TE (2.7Ghz) TDP=35W ® - Intel Core i5-4590T (2.0Ghz) TDP=35W ® - Intel Core i3-4350T (3.1Ghz) TDP=35W ® - Intel Core i3-4330TE (2.4Ghz) TDP=35W Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 10 AMI210 User Manual ® ® - Intel Celeron G1820TE (2.2Ghz) TDP=35W **Yellow = Haswell Refresh** ® Intel Q87/H81Platform Controller Hub Chipset - 23 x 22 mm package size, 0.65mm ball pitch ® Graphics Core I processor Integrated Intel HD Graphics 4000 Controller Memory 2 x DDR3-1600 SO-DIMM 2 GB, Max.
  • Page 11 Operating : 20G / 11ms Non-operating : 40G / 11ms Certification CE **follow EN55032** FCC ClassB / LVD Regulation RoHS 2.0 ‧ This specification is subject to change without prior notice. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 12: Dimensions

    AMI210 User Manual 1.2.2 Dimensions AMI210 Drawing...
  • Page 13 IBASE Technology Inc. AMI210-PE Drawing Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 14: I/O View

    AMI210 User Manual 1.2.3 I/O View...
  • Page 15 IBASE Technology Inc. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 16: Exploded View Of The Ami210/Ami210-Pe Assembly

    AMI210 User Manual 1.3 Exploded View of the AMI210/AMI210-PE Assembly AMI210...

  • Page 17: Parts Description

    IBASE Technology Inc. AMI210-PE 1.3.1 Parts Description AMI210 Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 18 AMI210 User Manual AMI210-PE...
  • Page 19 IBASE Technology Inc. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 20: Packing List

    AMI210 User Manual 1.4 Packing List Item No. Description Driver DVD Wall mount kit 1.4.1 Optional Items Description WiFi Solution WIRELESS;PCI-E MINI CARD 802.11B/G/N WiFi module [AW-NE238H] (A008WLAWNE238H000P) External Antenna WiFi Antenna (A055RFA02C2M20800P) From Wifi module to Rear/Front panel Internal cable-1/2 (A055RFA0000021000P/A055RFA0000032000P) MPCIE-EXT V-B1 Bracket, RoHS;...

  • Page 21: Chapter 2 Motherboard Introduction

    - 23 x 22 mm package size, 0.65mm ball pitch Memory 2 x DDR3-1600 SO-DIMM 8 GB, Max. 16GB (Non-ECC) - 1x DIMM on solder side Dual channel DDR3-1600 MHz with 1.5V Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 22 AMI210 User Manual SO-DIMM x 2, Max.=16GB (Non-ECC) [Horizontal type] ® Intel Generation Core DT processor integrated HD Gfx, Direct X 11.1, OpenGL 3.2, Open CL 1.2 DVI-D x 1 (Thru port B, with level shifter ASM1442K) DisplayPort x 1 (Thru port C)
  • Page 23 - 2 x DB9 for 4 pins [for TX/RX only] - 2 x USB for 8 pins - 1 x FAN for 3 pins - 1 x SMbus for 2 pins Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 24 AMI210 User Manual - 2x Mini PCI-E sockets [Full-sized] , [both support USB 2.0] [refer to MI808] - Support mSATA thru either one Mini-PCI-E socket Onboard Header/Connector 2 x 5 pins DF11 box header x1 for Digital IO 1 x 4 pins [2 x 2]ATX power connector for DC-input...

  • Page 25: Board Dimensions

    IBASE Technology Inc. 2.2 Board Dimensions Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 26: Setting The Jumpers

    AMI210 User Manual 2.3 Setting the Jumpers Jumpers are used on MB210 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on MB210 and their respective functions.
  • Page 27 JP6: Flash Descriptor Security Override (Factory use only) Flash Descriptor Security Override Open Disabled (Default) Close Enabled JP8: COM2 RS232 RI/+5V/+12V Power Setting Setting Function Pin 1-3, +12V Short/Closed Pin 3-4, RI (Default) Short/Closed Pin 3-5, Short/Closed Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 28 AMI210 User Manual JP9: COM1Terminal Selection Flash Descriptor Security Override Terminal Disable Open (Default) Pin 1-2, Short/Closed Terminal Enable Pin 3-4, Short/Closed JP10: RS-422/RS-485 Selection Flash Descriptor JP10 Security Override RS-422 Pin 1-2, Short/Closed RS-485 Pin 3-4, Short/Closed JP11: AT/ATX Mode Selection...
  • Page 29 IBASE Technology Inc. Connector Locations on MB210 Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 30 AMI210 User Manual CN2: USB2.0 (UB1112C-8HS6-4F) /USB3.0 Connector (UEA1112C-8HS6-4F) CN3: CRT + DVI-D Connector (QH11121-DBGH-4F, BX4) CN4: Audio Connector (JA23331-HA6Q-4F (E)) CN5: CFAST Connector (CY101-1100191 v1.2) CN6: SATA Connector (WATM-07DBN4B2B8UW4) CN7: RJ45 + USB3.0 Connector (JFM38U1B-B313-4F) CN8: RJ45 + USB2.0 Connector (JFM38U1B-21U5-4F)
  • Page 31 IBASE Technology Inc. J1: Reset Button Connector (Techbest 2001-WS-02-LF) Pin # Signal Name Reset BTN Ground Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 32 AMI210 User Manual J2: SPI Flash Connector (Factory use only) (2mm) Signal Pin # Pin # Signal Name Name Protect Pin SPI_CS# +3.3V SPI_SO SPI_HOLD# SPI_WP# SPI_CLK Ground SPI_SI J3, J12: DDR3 SO-DIMM Socket J4: SATA Power Connector (1600-4SD) Pin # Signal Name...
  • Page 33 Pin # Signal Name LPC_AD0 Reset# LPC_AD1 LPC_FRAME# LPC_AD2 +3.3V LPC_AD3 Ground CLK_33MHz Protect Pin J6, J7: Mini PCIE Connector (Foxconn AS0B226-S99Q-7H) J8: iSMART Debug Connector (Factory use only) (E-CALL 0110-161-040) Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 34 AMI210 User Manual J9: Digital I/O Connector (豪國DF11-10S-PA66H) Signal Name Signal Name Ground VCC5 OUT3 OUT1 OUT2 OUT0 J10: DC-in Connector (4M-ATX-S) Pin # Signal Name Power Ground Case Ground +12V to +24V +12V to +24V...
  • Page 35 CPU_FAN1: CPU Fan Power Connector (HF27040-M1) Pin # Signal Name Ground +12V Rotation detection Control LED1: HDD Active LED PCIE1: Include PCI-E x1, USB2.0, SYS_FAN, SATA, COM TX/RX Signal Connector PCIE2: PCI-E x16 Connector Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 36 AMI210 User Manual...

  • Page 37: Chapter 3 Bios Setup

    AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 38 AMI210 User Manual Main Settings Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Choose the system default language Total memory 8192 MB (DDR3) Memory Frequency 1600 Mhz System Language [English]...
  • Page 39 [32 PCI Bus Clocks] Change Field VGA Palette Snoop [Disabled] F1: General Help PERR# Generation [Disabled] F2: Previous Values SERR# Generation [Disabled] F3: Optimized Default F4: Save ► PCI Express Settings ESC: Exit Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 40 AMI210 User Manual PCI Latency Timer Value to be programmed into PCI Latency Timer Register VGA Palette Snoop Enables or Disables VGA Palette Register Snooping. PERR# Generation Enables or Disables PCI Device to Generate PERR#. SERR# Generation Enables or Disables PCI Device to Generate SERR#.
  • Page 41 F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit Wake on PCI PME Enables or Disables Wake on PCI PME. CPU Configuration This section shows the CPU configuration parameters. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 42 AMI210 User Manual Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Advanced Main Chipset Boot Security Save & Exit CPU Configuration Intel(R) Core(TM) i5-4590T CPU @ 2.00GHz CPU Signature 306c3 Processor Family Microcode Patch FSB Speed 100 MHz...
  • Page 43 CPU AES Enable/Disable CPU Advanced Encryption Standard instructions. Boot performance mode Select the performance state that the BIOS will set before OS handoff. EIST Enable/Disable Intel SpeedStep Turbo Mode Enable/Disable Turbo Mode. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 44 AMI210 User Manual SATA Configuration Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Advanced Main Chipset Boot Security Save & Exit SATA Controller(S) [Enabled] SATA Mode Selection [AHCI] ► Software Feature Mask Configuration Serial ATA Port 0 Empty...
  • Page 45 Schedule Slot 2 [None] F2: Previous Values F3: Optimized Default F4: Save ESC: Exit Power-on after Power Failure Enable or Disable Power-on after Power failure. Temperature Guardian Enable or Disable Temperature Guardian. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 46 AMI210 User Manual Schedule Slot Setup the hour/minute for system power on. AMT Configuration Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Advanced Main Chipset Boot Security Save & Exit Intel AMT [Enabled] BIOS Hotkey Pressed [Disabled] MEBx Selection Screen...
  • Page 47 Activate Remote Assistance Process Trigger CIRA boot. USB configure Enable/Disable USB Configure function. PET Progress User can Enable/Disable PET Events progress to receive PET events or not. Watchdog Enable/Disable Watchdog Timer Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 48 AMI210 User Manual USB Configuration Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Advanced Main Chipset Boot Security Save & Exit USB Configuration USB module Version 8.10.28 USB Devices: 1 Keyboard, 2Hubs Legacy USB Support [Enabled] → ←...
  • Page 49 ► Serial Port 2 Configuration F2: Previous Values ► Serial Port 3 Configuration F3: Optimized Default ► Serial Port 4 Configuration F4: Save ► Serial Port 5 Configuration ESC: Exit ► Serial Port 6 Configuration Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 50 AMI210 User Manual Standby Power on S5 This function is supported only with MB210EF(with EuP/ErP function). Serial Port 1 Configuration Set parameters of Serial Port 0 (COMA) Serial Port 2 Configuration Set parameters of Serial Port 1 (COMB) Serial Port 3 Configuration...
  • Page 51 Save & Exit Intel PCH RC Version 1.8.0.0 Options for SATA Configuration Intel PCH SKU Name Intel PCH Rev ID 05/C2 → ← ► PCI Express Configuration Select Screen ► USB Configuration Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 52 AMI210 User Manual ↑↓ Select Item ► PCH Azalia Configuration Enter: Select Change Field PCH LAN Controller [Enabled] F1: General Help Wake on LAN [Enabled] F2: Previous Values F3: Optimized Default F4: Save ESC: Exit PCI Express Configuration PCI Express Configuration settings.
  • Page 53 This section allows you to configure the boot settings. Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc. Boot Main Advanced Chipset Security Save & Exit Boot Configuration Setup Prompt Timeout Bootup NumLock State [On] Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 54 AMI210 User Manual Quiet Boot [Disabled] Fast Boot [Disabled] Boot mode select [LEGACY] FIXED BOOT ORDER Priorities → ← Select Screen Boot option #1 [Hard Disk] ↑↓ Select Item Boot option #2 [CD/DVD] Enter: Select Boot option #3 [USB Hard Disk]...
  • Page 55 Set display mode for Option ROM INT19 Trap Response BIOS reaction on INT19 trapping by Option ROM: IMMEDIATE – execute the trap right away ; POSTPONED – execute the trap during legacy boot. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 56 AMI210 User Manual CSM parameters OpROM execution, boot options filter, etc. Aptio Setup Utility – Copyright © 2015 American Megatrends, Inc. Boot Main Advanced Chipset Security Save & Exit → ← Select Screen Launch CSM [Enabled] ↑↓ Select Item Boot option filter...
  • Page 57 F2: Previous Values Minimum length F3: Optimized Default Maximum length F4: Save ESC: Exit Administrator Password User Password Administrator Password Set Setup Administrator Password. User Password Set User Password. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 58 AMI210 User Manual Save & Exit Settings Aptio Setup Utility – Copyright © 2015 American Megatrends, Inc Advanced Main Chipset Boot Security Save & Exit Save Changes and Exit Discard Changes and Exit Save Changes and Reset Discard Changes and Reset Save Options →...
  • Page 59 Restore/Load Defaults values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 60: Chapter 4 Drivers Installation

    AMI210 User Manual CHAPTER 4 DRIVERS INSTALLATION This section describes the installation procedures for software and drivers. The software and drivers are included with the motherboard. If you find the items missing, please contact the vendor where you made the purchase.

  • Page 61: Intel Chipset Software Installation Utility

    1.Insert the DVD that comes with the board. Click Intel and then Intel(R) 8 Series Chipset Drivers. 2. Click Intel(R) Chipset Software Installation Utility 3. When the Welcome screen to the Intel® Chipset Device Software appears, click Next to continue. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 62 AMI210 User Manual 4. Click Yes to accept the software license agreement and proceed with the installation process. 5. On the Readme File Information screen, click Next to continue the installation.
  • Page 63 IBASE Technology Inc. 6. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 64: Vga Drivers Installation

    AMI210 User Manual 4.2 VGA Drivers Installation 1.Insert the DVD that comes with the board. Click Intel and then Intel(R) 8 Series Chipset Drivers. 2. Click Intel(R) HD Graphics Driver. 3. When the Welcome screen appears, click Next to continue.
  • Page 65 IBASE Technology Inc. 4. Click Yes to agree with the license agreement and continue the installation. 5. On the screen shown below, click Install to continue. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 66 AMI210 User Manual 6. Setup complete. Click Finish to restart the computer and for changes to take effect.

  • Page 67: Realtek Hd Audio Driver Installation

    1. Insert the DVD that comes with the board. Click Intel and then Intel(R) 8 Series Chipset Drivers. 2. Click Realtek High Definition Audio Driver. 3. On the Welcome to the InstallShield Wizard screen, click Yes to proceed with and complete the installation process. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 68: Lan Drivers Installation

    AMI210 User Manual 4. The InstallShield Wizard Complete. Click Finish to restart the computer and for changes to take effect. 4.4 LAN Drivers Installation 1.Insert the DVD that comes with the board. Click Intel and then Intel(R) 8 Series Chipset Drivers.
  • Page 69 IBASE Technology Inc. 2. Click Intel(R) PRO LAN Network Driver. 3. When the Welcome screen appears, click Next. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 70 AMI210 User Manual 4. Click Next to to agree with the license agreement. 5. Click the checkbox for Drivers in the Setup Options screen to select it and click Next to continue. 6. The wizard is ready to begin installation. Click Install to begin the installation.

  • Page 71: Intel Management Engine Interface

    1.Insert the DVD that comes with the board. Click Intel and then Intel(R) 8 Series Chipset Drivers and then Intel(R) ME 9.0 Drivers. 2. When the Welcome screen to the InstallShield Wizard for Intel® Management Engine Components, click the checkbox for Install Intel® Control Center & click Next. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 72 AMI210 User Manual 3. Click Yes to to agree with the license agreement. 4. When the Setup Progress screen appears, click Next. Then, click Finish when the setup progress has been successfully installed.

  • Page 73: Usb 3.0 Drivers

    1.Insert the DVD that comes with the board. Click Intel and then Intel(R) 8 Series Chipset Drivers. 2. Click Intel(R) USB 3.0 Drivers. 3. When the Welcome screen to the Install Shield Wizard for Intel® USB 3.0 extensible Host Controller Driver, click Next. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 74 AMI210 User Manual 4. Click Yes to to agree with the license agreement and continue the installation.

  • Page 75: Appendix

    IBASE Technology Inc. Appendix Mounting AMI210 to the wall Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 76: Mounting Ami210-Pe To The Wall

    AMI210 User Manual Mounting AMI210-PE to the wall You can install AMI210 on plastic (LCD monitor), wood, drywall surface over studs, or a solid concrete or metal plane directly. Ensure the installer uses at least four M3 length 6mm screws to secure the system on wall. Four M3 length 6mm screws are recommended to secure the system on wall.

  • Page 77: Wall Mounting Requirements

    This recommendation reduces the risk that someone may accidentally walk into and damage the device. Local laws governing the safety of individuals might require this type of consideration. Copyright © 2014 IBASE Technology Inc. All Rights Reserved.

  • Page 78: Watchdog Timer Configuration

    AMI210 User Manual Watchdog Timer Configuration The WDT is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. Under these sorts of circumstances, the timer will count to zero and the selected outputs will be driven.
  • Page 79 %d seconds\n", bTime); if (bTime) { EnableWDT(bTime); else { DisableWDT(); return 0; //--------------------------------------------------------------------------- void EnableWDT(int interval) unsigned char bBuf; bBuf = Get_F81866_Reg(0x2B); bBuf &= (~0x20); Set_F81866_Reg(0x2B, bBuf); Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 80 AMI210 User Manual //Enable WDTO Set_F81866_LD(0x07); //switch to logic device 7 Set_F81866_Reg(0x30, 0x01); //enable timer bBuf = Get_F81866_Reg(0xF5); bBuf &= (~0x0F); bBuf |= 0x52; Set_F81866_Reg(0xF5, bBuf); //count mode is second Set_F81866_Reg(0xF6, interval); //set timer bBuf = Get_F81866_Reg(0xFA); bBuf |= 0x01;...
  • Page 81 Set_F81866_LD(0x07); //switch to logic device 7 bBuf = Get_F81866_Reg(0xFA); bBuf &= ~0x01; Set_F81866_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81866_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81866_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 82 AMI210 User Manual //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE.
  • Page 83 F81866_UNLOCK); outportb(F81866_INDEX_PORT, F81866_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81866 (void) outportb(F81866_INDEX_PORT, F81866_LOCK); //--------------------------------------------------------------------------- void Set_F81866_LD( unsigned char LD) Unlock_F81866(); outportb(F81866_INDEX_PORT, F81866_REG_LD); outportb(F81866_DATA_PORT, LD); Lock_F81866(); //--------------------------------------------------------------------------- void Set_F81866_Reg( unsigned char REG, unsigned char DATA) Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
  • Page 84 AMI210 User Manual Unlock_F81866(); outportb(F81866_INDEX_PORT, REG); outportb(F81866_DATA_PORT, DATA); Lock_F81866(); //--------------------------------------------------------------------------- unsigned char Get_F81866_Reg(unsigned char REG) unsigned char Result; Unlock_F81866(); outportb(F81866_INDEX_PORT, REG); Result = inportb(F81866_DATA_PORT); Lock_F81866(); return Result; //--------------------------------------------------------------------------- //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY...
  • Page 85 #define F81866_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81866_UNLOCK 0x87 #define F81866_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81866(void); void Set_F81866_LD( unsigned char); void Set_F81866_Reg( unsigned char, unsigned char); unsigned char Get_F81866_Reg( unsigned char); //--------------------------------------------------------------------------- #endif //__F81866_H Copyright © 2014 IBASE Technology Inc. All Rights Reserved.
