AMS320

Compact Expandable Fanless System

User's Manual

Version 1.0

(August 2024)

Need help?

Do you have a question about the AMS320 and is the answer not in the manual?

Questions and answers

Summary of Contents for IBASE Technology AMS320

Page 1 AMS320 Compact Expandable Fanless System User’s Manual Version 1.0 (August 2024)
Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
Page 3 CE conformity declaration may no longer apply. AMS320 has been tested and found to comply with the limits for a Class B device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 4 It is advised to disassemble, repair or make any modification to the device. Disassembly, modification, or any attempt at repair could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. AMS320 User Manual...
Page 5 Software in use (such as OS and application software, including the version numbers) 3. If repair service is required, you can download the RMA form at the website of IBASE. Fill out the form and contact your distributor or sales representative. AMS320 User Manual...
Page 6 General Information ............... 1 Introduction ..................... 2 Features ....................2 Packing List .................... 3 Optional Accessories ................3 Specifications ..................4 Product View – AMS320 ................. 6 Dimensions – AMS320 ................8 Chapter 2 Hardware Configuration ............10 Hardware Installations ................11 2.1.1 Memory Installation / Replacement .........
Page 7 Advanced Settings ................39 Chipset Settings ..................48 Security Settings ................... 50 Boot Settings..................51 Save & Exit Settings................52 Appendix ...................... 53 I/O Port Address Map ................54 Interrupt Request Lines (IRQ) ............... 56 Watchdog Timer Configuration .............. 57 AMS320 User Manual...
Page 8 This page is intentionally left blank. viii AMS320 User Manual...
Page 9 Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Optional Accessories • Specifications • Product View • Dimensions...
Page 10 -10ºC to 60ºC with airflow. Engineered with a passive finned heat sink for efficient heat transfer, the AMS320 incorporates the MBE320 motherboard, powered by 11th Gen Intel® Core™ i7/i5/i3 processors. It supports dual DDR4 SO-DIMM up to 64GB and features front removable drive bays for easy HDD/SSD replacement.
Page 11 Round Head Screw (for Wall Mount Kit) • Disk (including drivers and this user manual) • 1.4 Optional Accessories WiFi / Bluetooth antenna kit • LTE / 5G antenna kit • GPS antenna kit • 24V/180W power adaptor • AMS320 User Manual...
Page 12 1x M.2 3052 B-Key (USB 3.0 & PCI-E) Storage • 1x 2.5'' HDD/SSD (external-accessible) Construction Aluminum & steel Chassis Color Color Silver & Gray Mounting • Desktop or wall mounting (wall mount kit included) • Side mounting DIN-rail mounting (optional) AMS320 User Manual...
Page 13 Operatiing: 0.25 grms / 5~500Hz / random operation Operating: 20 g / 11 ms Shock Non-operating: 40 g / 11 ms Certification CE / LVD / FCC Class-B All specifications are subject to change without prior notice. AMS320 User Manual...
Page 14 1.6 Product View – AMS320 Front View Name Name LED Indicator 3x 2.5GbE Ports (from top to bottom: S1*, E1*, SSD, HDD, Power) Audio Jack for Line-Out Power Button Terminal block for 2x COM Ports remote power button DC-in terminel block for DP Ports 24V (±10%)
Page 15 General Information Rear View AMS320 User Manual...
Page 16 1.7 Dimensions – AMS320 Unit: mm AMS320 User Manual...
Page 17 General Information Unit: mm AMS320 User Manual...
Page 18 Chapter 2 Hardware Configuration The information provided in this chapter includes: • Essential installations before you begin • Information and locations of connectors...
Page 19 4. Gently push the module in an upright position until the ejector tabs of the memory slot close to hold the module in place when the module touches the bottom of the slot. To remove the module, press the ejector tabs outwards with your fingertips to eject the module. AMS320 User Manual...
Page 20 M.2 Installation / Replacement 1. After removing the bottom cover, locate the M.2 sockets. 2. There are two M.2 sockets available on AMS320 (J17: E-Key and J9: B- Key), as shown in the picture below. Locate the desired socket to be used for installation/replacement of M.2 devices to proceed.
Page 21 2.1.3 SSD Installation 1. To install or replace the SSD, follow the instructions below. Release 2 screws to pull out the SSD tray. Tray 4 screws Remove/replace the four screws shown to remove or install the SSD. AMS320 User Manual...
Page 22 1. Thread and fasten the hex nut and the 2. Apply adhesive around here. washer. Then install the antenna. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). AMS320 User Manual...
Page 23 The AMS320 system comes with a set of wall mount kit and four round head screws that are to be used in securing the mounting brackets to the main unit, as shown in the picture below.
Page 24 When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. AMS320 User Manual...
Page 25 Hardware Configuration 2.3 Jumper & Connector Locations on Motherboard Motherboard: MB320 AMS320 User Manual...
Page 26 2.4 Jumpers Quick Reference Function Jumper Clear RTC Clear ME M.2 B-Key Support Type AT/ATX Mode Setting 2.4.1 Clear RTC (JP1) Function Illustration Normal (default) 1-2 Closed Clear CMOS 2-3 Closed AMS320 User Manual...
Page 27 Hardware Configuration 2.4.2 Clear ME (JP2) Function Illustration Normal (default) Closed Clear ME Closed AMS320 User Manual...
Page 28 2.4.3 M.2 B-Key Support Type (JP4) Function Illustration 1-2 Closed PCIe 2-3 Closed AMS320 User Manual...
Page 29 Hardware Configuration 2.4.4 AT/ATX Mode Setting (JP5) Function Illustration ATX Mode 1-2 Closed (default) AT Mode 2-3 Closed AMS320 User Manual...
Page 30 RTC Battery Connector SATA Power Connector SO-DIMM Sockets J3, J4 SPI Debug Header SIM Card Slot for 4G/5G M.2 E-Key Socket M.2 B-Key Socket ESPI Debug Header Reset Header Digital IO Connector AT On/Off Switch DC_IN Connector AMS320 User Manual...
Page 31 CN5, CN7: DisplayPort Ports 2.5.6 CN6, CN8: USB 3.1 Ports 2.5.7 CN9, CN10, CN11: I226V GbE Ports 2.5.8 CN12 : Terminal Block Connector for Remote Access 2.5.9 J14: DC_IN Connector (2-pin terminal block) Signal Name Signal Name Ground AMS320 User Manual...
Page 32 2.5.10 J1: RTC Battery Connector 2.5.11 J2: SATA Power Connector Signal Name Signal Name Ground Ground +12V 2.5.12 J3, J4: SO-DIMM Sockets AMS320 User Manual...
Page 33 Hardware Configuration 2.5.13 J5: SPI Debug Header 2.5.14 J6: SIM Card Slot for 4G/5G 2.5.15 J7: M.2 E-Key Socket Note: J7 supports USB 2.0 & PCIe (for wifi module) AMS320 User Manual...
Page 34 2.5.16 J9: M.2 B-Key Socket Note: J9 supports USB 2.0 & 3.0 & PCIe (for 4G / 5G module) 2.5.17 J10: ESPI Debug Header 2.5.18 J11: Reset Header AMS320 User Manual...
Page 35 Hardware Configuration 2.5.19 J12: Digital IO Connector 2.5.20 J13 : AT On/Off Switch Assigment SHDN# Ground AMS320 User Manual...
Page 36 Chapter 3 Driver Installation The information provided in this chapter includes: • Intel ® Chipset Software Installation Utility • Graphics Driver Installation • HD Audio Driver Installation • LAN Driver Installation • Intel ® ME Drivers Installation ® • Intel Thunderbolt Drivers Installation...
Page 37 INF files for Plug & Play function for the chipset components. Follow the instructions below to complete the installation. 1. Run the drivers disk.Click Intel and then Intel(R) TigerLake-U Chipset Drivers. 2. Click Intel(R) Chipset Software Installation Utility. AMS320 User Manual...
Page 38 Next to continue. 4. Accept the terms in the software license agreement. 5. On the Readme File Information screen, click Install. ® 6. When Intel Chipset Device Software has been completely installed, click Finish to complete the setup process. AMS320 User Manual...
Page 39 4. Accept the terms in the license agreement and click Yes. 5. On the Readme File Information screen, click Next. 6. In the Setup Progress screen, click Next. 7. When Setup is Complete, click Finish to restart the computer. AMS320 User Manual...
Page 40 1. Run the drivers disk. Click Intel and then Intel(R) TigerLake-U Chipset Drivers. 2. Click Realtek High Definition Audio Driver. 3. On the Welcome screen of the InstallShield Wizard, click Next. 4. When InstallShield Wizard has completed the installation, restart the computer. AMS320 User Manual...
Page 41 5. Accept the terms in the License Agreement and click Next. 6. Click Next in the Setup Options screen. 7. Install Wizard is now ready to install the program, click Install. 8. When Install Wizard has completed the installation, click Finish. AMS320 User Manual...
Page 42 4. Accept the terms in the license agreement and click Next to continue. 5. Click Next to install to the default folder, or click Change to choose another destination folder. 6. When the Intel Management Engine Components has been successfully installed, click Finish. AMS320 User Manual...
Page 43 1. Run the driver disk. Click Intel and then Intel(R) TigerLake-U Chipset Drivers. 2. Click Intel(R) Thunderbolt Drivers. 3. Agree to the license terms and conditions. Click Install to continue. 4. When the installation has been successfully completed, click Restart. AMS320 User Manual...
Page 44 Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Introduction • BIOS Setup • Main Settings • Advanced Settings •...
Page 45 These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. AMS320 User Manual...
Page 46 4.3 Main Settings BIOS Setting Description Sets the date. System Date Use the <Tab> key to switch between date elements. Set the time. System Time Use the <Tab> key to switch between time elements. AMS320 User Manual...
Page 47 Displays system ACPI parameters. Super IO Configuration Displays super IO chip parameters. Hardware Monitor Shows super IO monitor hardware status. Network Stack Enable/Disable UEFI Network Stack. Configuration USB Configuration Displays USB configuration parameters. NVMe Configuration Configures NVME Device AMS320 User Manual...
Page 48 When enabled, a VMM can utilize the Intel (VMX) Virtualization additional hardware capabilities provided by Technology Vanderpool Technology. Number of cores to enable in each processor Active Processor Cores package. Enable or Disable Hyper-Threading Hyper-Threading Technology. Enables / Disables AES (Advanced Encryption Standard). AMS320 User Manual...
Page 49 (Assured Power) Configurations Configurations Configurable TDP Mode as Nominal/Up/Down/ Deactiivate TDP selection. Deactivate option will Configurable TDP Boot set MSR to Nominal and MMIO to zero. For TCL Mode UP3: Nominal=Nominal, Up=cTDP Down1 and Down=cTDP Down2 AMS320 User Manual...
Page 50 Physical Presence Spec 1.3). Note: Some HCK tests might not support 1.3. Version Auto will support TPM 1.2 / 2.0 devices with the default Device Select set to TPM 2.0. If not found, TPM 1.2 devices will be enumerated AMS320 User Manual...
Page 51 BIOS Setup 4.4.5 ACPI Settings BIOS Setting Description Enables / Disables the system ability to Enable Hibernation hibernate (OS/S4 Sleep State). This option may not be effective with some OS. 4.4.6 Super IO Configuration AMS320 User Manual...
Page 52 Options: Disabled (default),. 50 °C, 60 °C, 70 °C, 80 °C These fields are the parameters of the hardware monitoring function feature of the Temperatures / Voltages motherboard. The values are read-only as monitored by the system and showing the PC health status AMS320 User Manual...
Page 53 Maximum time the device will take before it properly reports itself to the Host Controller. Device power-up delay ‘Auto’ uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Options: Auto, Manual AMS320 User Manual...
Page 54 4.4.9 Network Stack Configuration BIOS Setting Description Network Stack Enable/Disable UEFI Network Stack AMS320 User Manual...
Page 55 BIOS Setup 4.4.10 USB Configuration 4.4.11 NVME Configuration AMS320 User Manual...
Page 56 System Agent (SA) parameters Configuration PCH-IO Configuration PCH parameters VT-d Enables / Disables VT-d capability. Selectively enable/disable the corresponding USB Port Disable USB port from reporting a device connection to Override the controller. 4.5.1 System Agent Configuration AMS320 User Manual...
Page 57 BIOS Setting Description SATA and RST SATA device options settings Configuration USB Configuration USB configuration settings Power-on after Power Specify what state to go to when power is re- failure applied after a power failure (G3 state). AMS320 User Manual...
Page 58 4.6 Security Settings BIOS Setting Description Administrator Password Sets an administrator password. User Password Sets a user password. Secure Boot Secure Boot configuration AMS320 User Manual...
Page 59 Selects the keyboard NumLock state. Quiet Boot Enables / Disables Quiet Boot option. Fixed Boot Order Priorities Sets the system boot order. UEFI Hard Disk Drive BBS Specifies the Boot Device Priority sequence Priorities from available UefI Hark Disk Drives. AMS320 User Manual...
Page 60 Restores / Loads defaults values for all the Restore Defaults setup options. Save as User Defaults Saves the changes done so far as user defaults. Restores the user defaults to all the setup Restore User Defaults options. AMS320 User Manual...
Page 61 Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Watchdog Timer Configuration...
Page 62 Intel(R) SMBus - 06A3 0x000003F8-0x000003FF Communications Port (COM1) 0x000002F8-0x000002FF Communications Port (COM2) 0x000003E8-0x000003EF Communications Port (COM3) 0x000002E8-0x000002EF Communications Port (COM4) 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller AMS320 User Manual...
Page 63 0x00000D00-0x0000FFFF PCI Express Root Complex 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x00001854-0x00001857 Motherboard resources 0x00002000-0x000020FE Motherboard resources 0x00003000-0x0000303F Intel(R) UHD Graphics 630 0x00003090-0x00003097 Standard SATA AHCI Controller 0x00003080-0x00003083 Standard SATA AHCI Controller 0x00003060-0x0000307F Standard SATA AHCI Controller AMS320 User Manual...
Page 64 IRQ 4294967291 Standard SATA AHCI Controller IRQ 4294967279~83 Intel(R) Ethernet Controller (3) I225-V IRQ 4294967284~88 Intel(R) Ethernet Controller (3) I225-V #2 IRQ 4294967278 Intel(R) Management Engine Interface IRQ 4294967294 Intel(R) PCI Express Root Port #12 - 06B3 AMS320 User Manual...
Page 65 **endptr; char SIO; printf("Fintek 81964 watch dog program\n"); SIO = Init_F81964(); if (SIO == 0) printf("Can not detect Fintek 81964, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) AMS320 User Manual...
Page 66 //enable WDTO output bBuf = Get_F81964_Reg(0xF5); bBuf |= 0x20; Set_F81964_Reg(0xF5, bBuf); //start counting //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81964_LD(0x07); //switch to logic device 7 bBuf = Get_F81964_Reg(0xFA); bBuf &= ~0x01; Set_F81964_Reg(0xFA, bBuf); //disable WDTO output AMS320 User Manual...
Page 67 (ucDid == 0x07) //Fintek 81964 { goto Init_Finish; } F81964_BASE = 0x2E; result = F81964_BASE; ucDid = Get_F81964_Reg(0x20); if (ucDid == 0x07) //Fintek 81964 { goto Init_Finish; } F81964_BASE = 0x00; result = F81964_BASE; Init_Finish: return (result); AMS320 User Manual...
Page 68 LD); Lock_F81964(); //--------------------------------------------------------------------------- void Set_F81964_Reg( unsigned char REG, unsigned char DATA) Unlock_F81964(); outportb(F81964_INDEX_PORT, REG); outportb(F81964_DATA_PORT, DATA); Lock_F81964(); //--------------------------------------------------------------------------- unsigned char Get_F81964_Reg(unsigned char REG) unsigned char Result; Unlock_F81964(); outportb(F81964_INDEX_PORT, REG); Result = inportb(F81964_DATA_PORT); Lock_F81964(); return Result; //--------------------------------------------------------------------------- AMS320 User Manual...
Page 69 #define F81964_DATA_PORT (F81964_BASE+1) //--------------------------------------------------------------------------- #define F81964_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81964_UNLOCK 0x87 #define F81964_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81964(void); void Set_F81964_LD( unsigned char); void Set_F81964_Reg( unsigned char, unsigned char); unsigned char Get_F81964_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81964_H AMS320 User Manual...
