- Page 2 Attention Note: Please make sure the voltage is consistent with the local voltage before printing.If not, please adjust it (110V- 220V） Please check if the all the items are included in the packing list before installing the printer . If you have any questions, please contact customer service.
- Page 3 2. Packing list ………………………………… 3 3. Machine details ……………………………… 4 4. Installation ………………………………… 5 5. Wiring connection …………………………… 7 6. Structure debug ……………………………… 8 7. Operation & Print ………………………… 9 8. Failure cause analysis ………………………15 Service email ：Support@tronxy.com Tronxy Support FaceBook...
- Page 4 PLA、ABS、PETG、TPU Temp parameters： Print environment ： 8-40℃ ： Nozzle temp 275℃（MAX） Power supply： AC 110/220V 50/60Hz DC 24V/360W Software： ： Slicer Tronxy、Cura、Simplify3D ： Input format .stl、.obj ： Output format .gcode ： Connection SD card、USB cable Machine parameters： ： Machine size 485*482*643mm ：...
- Page 5 2. Packing list Upper bracket Base XY-3 PRO Z stop Filament bracket Reader（with SD Power line USB cable Shovel card） 10mPLA Hot End HM4*10 8PCS Tools （Color random） Notes ：Please check if all the items are included before installing the printer.
- Page 6 3、Machine Structure Part Part Part Upper frame Right sliding board X axis motor Filament sensor Print head Extruder motor switch Hotbed and Lattice 30P adapt board Z1 motor Glass USB/SD card Left sliding board Z2 motor interface Z limit switch Touch screen power switch Power 110v-220v...
- Page 7 4. Installation Note: Please make sure the voltage is consistent with the local voltage before printing . If not, please adjust it (110V-220V） Use 8pcs M4*10 screws to lock the left and right motor part of above frame to the base.
- Page 8 Use a hex wrench to tighten the boat nut to fix the Z stop on the aluminum extrusions of the Z axis Use a hex wrench to tighten the boat nut to fix the filament holder on the aluminum extrusions of the upper frame...
- Page 9 5. Wiring connection Switch board Z Stop Z2 motor line Z1 motor line Switch line installation method: Remove the buckle, and put it on the notch side of the quasi-adapter plate on the raised side of the adapter, and insert it firmly until the buckle bounces back.
- Page 10 6. Structure debug If the machine structure is loose during transportation, it can be solved by adjusting the eccentric nut.As shown in the figure below (eccentric nut in red circle), turn the nut with a wrench to adjust the tightness of the pulley (the pulley should not be adjusted too tight to avoid smooth operation).
- Page 11 7. Operation & Print...
- Page 12 Manual leveling： Click the four points of ABCD (see the picture ), the print head will move to the corresponding position, and then adjust the leveling nut M, to ensure the space between the nozzle and the platform is a piece of A4 paper.
- Page 13 Load and unload filaments： 23/0 Click 23/199 After waiting for temperature up to 180 ℃, filament go through from the filament detection, extruder and feed pipe to the nozzle until the filaments are squeezed , as the following picture shows : Feed pipe Straighten Filament...
- Page 14 1. Installation Find out slice software in SD card“TronxyInstall.exe ”click twice ， Then follow these steps to complete the installation.
- Page 15 2. How to use slice software ① Type setting: follow the steps below to complete the setting. ① ③ ② ④ ⑤ ⑥...
- Page 16 ② Parameter setting：（The following figure gives the reference value, according to their own needs can be modified） Some parameters are set for reference： Layer thickness ： 0.1-0.3mm ： PLA - 200 ℃ ABS - 240 ℃ Print temp ABS - 80 ℃ Heatbed temp ：...
- Page 17 8. Failure cause analysis 1. Machine cannot start 1）Check the power line and other wires are connected well or not . 2）Check whether the supply voltage suits the local standard. 3）Check whether the screen or power supply is damaged and replace it in time.
- Page 18 5. The model is not easy to take off 1）Try to heat the hot bed to 50-70 ℃ take off it by the shovel . 2) It is recommended to buy TRONXY magnetic stickers. 6. Can‘t heat it up 1）Check the heating rod and thermistor for poor contact or damage.
- Page 19 9. Model dislocation and fault 1）Nozzle feeding not smoothly, please clean the nozzle or replace the nozzle 2）Check that if the printing speed is too fast 3）The quality of filaments is poor, please replace with new filaments 10. Abnormal sound and vibration of filaments feeding motor 1）Please check whether the nozzle is blocked 2）The nozzle feeding is not smooth, please clean the nozzle...
