CDCE(L)9xx and CDCEx06 Programming Evaluation
This user's guide explains how to use the CDCE(L)9xx Programming EVM, which is a generic
printed-circuit board. It is designed to program devices in the CDCE(L)9xx and CDCEx06 families. These
families use different core voltages, requiring voltage adjustment. This document explains the settings in
detail. The CDCE(L)9xx and the CDCEx06 programming is now available.
...................................................................................................................
1
Introduction
1.1
Features
2
Quick Start – USB Plug 'N' Play
3
EVM Hardware
3.1
Jumper Settings
3.2
Positioning of the Devices in the Socket
...................................................................................................................
4
Schematics
5
Related Documentation From Texas Instruments
1
CDC Programming EVM
2
Functional Block Diagram of CDCE(L)9xx
3
Functional Block Diagram of CDCEx06
4
CDCE(L)9xx and CDCEx06 Programming EVM Block Diagram
5
CDCE(L)9xx Device Location in Socket
6
CDCEx06 Device Location in Socket
1
Introduction
The CDCE9xx and CDCEx06 programming EVM has an errata in the
silkscreen on jumper J5. Where it reads CDCE9xx, it should read
CDCEx06 and vice versa.
1.1
Features
• Easy-to-use evaluation module for fast programming of prototyping units and low production
• Allows programming of all members of the TI's CDCE(L)9xx family and CDCEx06 family with the same
board
• Easy and fast device programming through TI ClockPro software
• EVM completely USB powered
The CDCE(L)9xx programming EVM is designed to program all devices of both the CDCE(L)9xx and the
CDCEx06 families.
SCAU026 – December 2008
Submit Documentation Feedback
..............................................................................................................
...........................................................................................
...............................................................................................................
.....................................................................................................
....................................................................................................
...............................................................................
...................................................................................
..................................................................................
.....................................................................................
WARNING
Contents
.........................................................................
.....................................................................
List of Figures
......................................................
CDCE(L)9xx and CDCEx06 Programming Evaluation Module
User's Guide
SCAU026 – December 2008
Module
1
1
5
5
5
6
8
12
3
4
4
5
6
7
1
Advertisement
Related Manuals for Texas Instruments CDCE 06 Series
Summary of Contents for Texas Instruments CDCE 06 Series
- Page 1 EVM Hardware ..................... Jumper Settings ................. Positioning of the Devices in the Socket ........................Schematics ..............Related Documentation From Texas Instruments List of Figures ....................CDC Programming EVM ................Functional Block Diagram of CDCE(L)9xx ................... Functional Block Diagram of CDCEx06 ............
- Page 2 Introduction www.ti.com These families are modular PLL-based, low-cost, high-performance, programmable clock synthesizers. The CDCE(L)9xx family ranges from three (1-PLL) up to nine (4-PLL) output clocks from a single input frequency. A crystal or LVCMOS clock signal is possible as reference clock. VCXO functionality as well as SSC functionality is built in every device of the CDCE(L)9xx family, which allows synchronizing the output frequency to an external control signal, e.g., a PWM signal.
- Page 3 Introduction www.ti.com Figure 1. CDC Programming EVM SCAU026 – December 2008 CDCE(L)9xx and CDCEx06 Programming Evaluation Module Submit Documentation Feedback...
- Page 4 Introduction www.ti.com Figure 2. Functional Block Diagram of CDCE(L)9xx CCOUT1 PLL Bypass Output Switch Matrix PLL1 prg. 9 Bit Divider M CMOS Filter prg. 12 Bit Divider N CMOS CLK_IN0 PLL2 w/ SSC prg. 9 Bit 2 LVCMOS CMOS Divider M Differential CLK_IN1 Input...
- Page 5 Quick Start – USB Plug 'N' Play www.ti.com Quick Start – USB Plug 'N' Play Follow these steps to quickly start using the EVM. 1. Connect the EVM with the PC with a 2.0 USB cable. 2. Install the driver software using the provided CD-ROM. 3.
- Page 6 EVM Hardware www.ti.com WARNING The CDCE9xx and CDCEx06 programming EVM has an errata in the silkscreen on jumper J5. Where it reads CDCE9xx, it should read CDCEx06 and vice versa. Positioning of the Devices in the Socket The socket is slightly bigger then the devices to be programmed. This allows for different devices to be programmed with only one EVM.
- Page 7 EVM Hardware www.ti.com 3.2.2 Programming the CDCEx06 All devices of the CDCEx06 family are programmed by positioning on the lower edge of the socket with pin 1 toward the pin 1 marking of the socket. (see Figure CDCEx06 Figure 6. CDCEx06 Device Location in Socket SCAU026 –...
- Page 8 Schematics www.ti.com Schematics CDCE(L)9xx and CDCEx06 Programming Evaluation Module SCAU026 – December 2008 Submit Documentation Feedback...
- Page 9 Schematics www.ti.com SCAU026 – December 2008 CDCE(L)9xx and CDCEx06 Programming Evaluation Module Submit Documentation Feedback...
- Page 10 Schematics www.ti.com CDCE(L)9xx and CDCEx06 Programming Evaluation Module SCAU026 – December 2008 Submit Documentation Feedback...
- Page 11 Schematics www.ti.com SCAU026 – December 2008 CDCE(L)9xx and CDCEx06 Programming Evaluation Module Submit Documentation Feedback...
- Page 12 Related Documentation From Texas Instruments www.ti.com Related Documentation From Texas Instruments • CDCE949, CDCEL949, Programmable 4-PLL VCXO Clock Synthesizer With 1.8V, 2.5V, and 3.3V LVCMOS Outputs data sheet (SCAS844) • CDCE937, CDCEL937, Programmable 3-PLL VCXO Clock Synthesizer With 1.8V, 2.5V, and 3.3V LVCMOS Outputs data sheet (SLAS564) •...
- Page 13 EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must have electronics training and observe good engineering practice standards.
- Page 14 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
- Page 15 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments CDCEL9XXPROGEVM...
