Specifications

The following table lists the specifications for all PosiTrack units.
Specifications
Dimensions (HWD):
AXB-PT10
Dimensions (HWD):
AXB-PT15
Dimensions (HWD)
AXB-PT30
Power Consumption:
AXB-PT10
AXB-PT15
AXB-PT30
Weight:
AXB-PT10
AXB-PT15
AXB-PT30
Angular Travel:
Maximum Speed:
AXB-PT10
AXB-PT15
AXB-PT30
Weight Capacity:
AXB-PT10
AXB-PT15
AXB-PT30
Repeatability:
AXB-PT10
AXB-PT15
AXB-PT30
2
Camera controller: 5.85" x 5.20" x 4.92" (14.86 cm x 13.22 cm x 14.70 cm)
Camera mount: 0.65" x 2.26" x 3.23" (1.75 cm x 5.74 cm x 8.21 cm)
Cradle support bracket: 3.64" x 5.50" x 0.20"
(9.25 cm x 13.97 cm x 0.51 cm)
Camera controller: 6.43" x 5.61" x 5.38"
(16.32 cm x 14.25 cm x 13.67 cm)
Camera mount: 0.65" x 2.26" x 3.23" (1.75 cm x 5.74 cm x 8.21 cm)
Cradle support bracket: 3.64" x 5.50" x 0.20"
(9.25 cm x 13.97 cm x 0.51 cm)
Camera Controller: 7.10" x 5.70" x 4.65" (18.03 cm x 14.49 cm x 11.81 cm)
Camera Cradle: 4.75" x 3.75" x 6.25" (120.67 mm x 95.28 mm x 158.75 mm)
2.6 A max @ 12 VDC
4 A max @ 12 VDC
6 A max @ 12 VDC
8.00 lbs. (3.63 kg)
10.51 lbs. (4.77 kg)
13.05 lbs. (5.92 kg)
± 179° (358° total)
Pan
± 90° (180° total)
Tilt
• Pan 45°/sec.
• Tilt 45°/sec.
• Pan 55°/sec.
• Tilt 55°/sec.
• Pan 35°/sec.
• Tilt 35°/sec.
10 lbs. (4.54 kg) balanced lens/camera weight (maximum)
15 lbs. (6.80 kg) balanced lens/camera weight (maximum)
30 lbs. (13.6 kg) balanced lens/camera weight (maximum)
± 5 arc minutes
± 3 arc minutes
± 5 arc minutes
