- Page 1 Version: 1.4 INSTALLATION GUIDE WIDESPREAD BATHROOM SINK FAUCET MODEL FINISH S1414S-CH Chrome S1414S-BN Brushed Nickel S1414S-OB Oil Rubbed Bronze S1414S-MB Matte Black S1414S-BG Brushed Gold S1414S-MG Matte Black and Gold HOT LINE: +1-866-203-0866...
-
Page 2: Before Proceeding
THANK YOU Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions. -
Page 3: Limited Lifetime Consumer Warranty
If a defect is found in normal residential use, SUMERAIN will, at its election, repair, provide a replacement part or product, or make appropriate adjustment. - Page 4 FUNCTIONS AND SPECIFICATION Bathroom Sink Faucets Function Feature Widespread Style Contemporary Chrome/Brushed Nickel/Matte Black Finish Installation Holes Three Holes Number of Handles Handle style Lever Spout total Height 155mm [6-1/8 Inch] 120mm [4-3/4 Inch] Spout Reach Spout Width 42mm [1-21/32 Inch] Spout Height 131mm [5-1/8 Inch]...
- Page 5 DEMENSION FRONT VIEW OF FAUCET SIDE VIEW OF FAUCET...
-
Page 6: Installation Steps
INSTALLATION STEPS 1. BEFORE PROCEEDING WARNING: Read all the instructions completely before proceeding.SUMERAIN recommends calling a Professional,if you are uncertain about installing this product!, this product should be installed in accordance with all local and state plumbing and building codes. - Page 7 If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com 4. INSTALLATION HOLES INSPECTION Verify that the hole sizes and positions in the wall are correct, the diameter of mounting hole recommend 1-1/4” (32mm) and...
-
Page 8: Installation
5. INSTALLATION 5.1 Turn on your shut-off valve for cleaning the hot and cold water supply pipe before connect to the faucet, allow the water flush 3~5 minutes to flush out dirt and debris. Shut off the water supply again after done. 5.2 Remove the mounting hardware from the mounting shank... - Page 9 5.3 Put the faucet spout into faucet hole and slide rubber washer and mounting bracket onto the thread shank from below the sink. 5.4 Secure the rough-in valve to the mounting board with screws by Philips screwdriver.
- Page 10 5.5 Disassemble hot and cold water valve assembly to prepare for next step’s installation. Remove the mounting hardware from the mounting shank 5.6 Place the Hot water control valve body onto mounting surface, attach the rubber washer and locknut from underneath of mounting surface，Secure the rough-in valve to the mounting board with screws by Philips screwdriver..
- Page 11 5.7 Connecting the cold water valve body and hot water valve body to spout with flexible hoses. 5.8 Connect hot valve body’s inlet connector and cold water valve inlet connector to stop valve separately with supply hose. Mount Nut Connector: A.
- Page 12 6. INSPECTION 6.1 Turn on hot and cold water supply and check all connection for ensuring no leaking anywhere. INSTALL FINISH...
- Page 13 Please note: if the surface is already damaged, the effect of cleaning materials will cause further damage. Components with damaged surfaces must be replaced or injury could result. Damage caused by improper treatment is not covered under the warranty. HONGKONG SUMERAIN SANITARY INDUSTRY CO., LIMITED Address: ROOM 1018, HOLLYWOOD PLAZA 610 NATHAN ROAD MONGKOK, KL,HONGKONG Factory Address: Floor 3th,No.2 ZhongXing Road,ShuiNuan City Industrial Zone,Shuikou town, Kaiping City,...
