- Page 1 FT.20020 Overhead Molle Panel (1) Contents:...
- Page 2 Part Name Size(mm) Picture Button Head Socket Cap Bolts Screws M8*20 Split Lock Washer Flat Washer M8*16*1.5 Flange Hex Lock Nuts...
- Page 3 About 40 minutes, 1-2 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (FT.20020), please scan the QR code.
- Page 4 (4) Installation instruction: Step 1: Assemble the Molle Panels with the Button Head Socket Cap Bolts Screws (M8*20), Split Lock Washer (D8), Flat Washer (M8*16*1.5), Flange hex lock nuts (M8). Step 2: Install the Front Bracket & the Rear Bracket into the molle panles with the Button Head Socket Cap Bolts Screws (M8*20), Split Lock Washer (D8), Flat Washer (M8*16*1.5), Flange hex lock nuts (M8).
- Page 5 Step 3: Install the molle panels into your vehicle with the factory bolts.
- Page 6 Step 4: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product! Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product.
