Summary of Contents for HOOKE ROAD BXG.2052-S
- Page 1 Front Bumper BXG.2052-S (1) Contents:...
- Page 2 Part Name Size(mm) Picture Hex Bolts M8*20 Split Lock Washer Flat Washer M12*30*2 Hex Nuts M8*16*1.2 (2) Tools required: a. 19mm Shallow Socket; b. 19mm Wrench; c. Drive Socket Ratchet Wrench;...
- Page 3 About 1 hour, 1-2 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.2052-S), please scan the QR code.
- Page 4 (4) Installation instruction: Step 1: Remove your original bumper. Get ready to install the new bumper. Step 2: Prepare the Front bumper components for installation (Pay attention to the structure of the Front bumper, make you have some preparation for installation.)
- Page 5 There are 4 holes each side. **Make sure you have an assistant help you hold the bumper, when you install the Screws) Step 4: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product!
- Page 6 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
