- Page 1 BXG.2016A Tubular Door (1)Contents: (2)Tools required: A. 1/4 & 10mm Torque...
-
Page 2: Installation Time
(3)Installation time: About 1.5 hours, 2 persons needed. (Installation time is different according to individual person) (Please read all instructions thoroughly before starting installation!) (4)Installation instruction: Step 1: Disconnect wiring harness before removing the door. Remove the plastic cover at the base of the B-pillar to access the electrical connector. Release the red locking tab and pull down on the connector. - Page 3 Step 4: Lay the door on the ground,use a blanket or big cardboard between the door and the ground to keep the outside of the door from scratching. Attention : The hinge at the lower part of doors,they have installed with straps at back.Don’t forget to install.Showed Below. Step 5: Build up door assembly.Install the Hinges and other part on the door.
- Page 4 (1)(2)Install the front upper hinge with the screws in the package. (3)(4)Install the front lower hinge with the screws in the package. B. The Front door Installation...
- Page 5 (5) Slide the door onto the factory hinge pins. Tighten the hinge bolts while the door is closed. (6) Place the strap over the top over the top of the retaining hook and make sure the door is secured. (7) Install the original Torx nut at the bottom of each factory hinge pin. Then the Front door installation is over.
- Page 6 Step 7: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product! Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product.
