- Page 1 Body Armor BXG.2045 (1) Contents: (2) Tools required: a.6mm HEX Socket Wrench; b.One Drill; c.11mm Drill bit; d.M10 Pneumatic Rivet Nut Setting Kit...
- Page 2 About 2 hours, 2-3 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.2045), please scan the QR code.
- Page 3 (4) Installation instruction: Step 1: Ready to install the new product. Step 2: Try to confirm the bolt holes .As shown below.
- Page 4 Step 3: Drill the bolt holes. And install the PART”I” by the M10 Pneumatic Rivet Nut Setting Kit.
- Page 5 Step 4: Install PART”A2” with PART”H”, PART”J” by the 6mm HEX Socket Wrench.
- Page 6 Step 5: Repeat above steps on another side. Step 6: Installation completed. After Before...
- Page 7 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
