Tyger TG-TG7T86668 Manual

TAIL LIGHT GUARD
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY
DAMAGE BEFORE INSTALLATION COULD LEAD TO A
REJECTION OF ANY CLAIM. IF MISSING PARTS OR ANY
DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE
CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
Driver/Left Tail Light Guard
x1
Passenger/Right Tail Light Guard
x1
Driver/Left Upper Bed Bracket
x1
Passenger/Right Upper Bed Bracket
x1
Driver/Left Lower Bed Bracket
x1
Passenger/Right Lower Bed Bracket
x1
Driver/Left Upper Light Bracket
x1
Passenger/Right Upper Light Bracket
x1
Driver/Left Upper
Light Bracket
Driver/Left Upper
Bed Bracket
Driver/Left Lower Light Bracket
Driver/Left Lower Bed Bracket
TORQUE VALUES
Fastener Size
6mm
8mm
10mm
12mm
14mm
Driver/Left Passenger/Right
Tail Light Guard Tail Light Guard
Customer Support: www.tygerauto.com/contact
1/4
Class 8.8 Torque (ft-lbs)
6-7
15-16
31-32
54-55
87-88
Driver/Left Lower Light Bracket
x1
Passenger/Right Lower Light Bracket
x1
x4
Foam Spacers
x8
6mm x 12mm Button Head Bolts
x8 6mm Lock Washers
6mm x 12mm OD x 1.6mm Flat Washers
x8
6mm Clip Nuts
x4
Passenger/Right
Upper Bed Bracket
Passenger/Right Lower Light Bracket
Passenger/Right Lower Bed Bracket
TG-TG7T86668
Class 10.9 Torque (ft-lbs)
6-7
22-23
44-45
78-79
125-126
Passenger/Right
Upper Light Bracket
6mm Clip Nuts (x4)
V220512
