TYGER TRAX
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY
DAMAGE BEFORE INSTALLATION COULD LEAD TO A
REJECTION OF ANY CLAIM. IF MISSING PARTS OR ANY
DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE
CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
x1
Driver/Left Tyger Trax
x1
Passenger/Right Tyger Trax
x1
Driver/Left Front Mounting Bracket (A)
x1
Passenger/Right Front Mounting Bracket (D)
x1
Driver/Left Second Mounting Bracket (B)
x1
Passenger/Right Second Mounting Bracket (E)
Reference the letters printed on the brackets to determine mounting locations
(F)
Front
Customer Support: www.tygerauto.com/contact
TG-TX7T29798
TORQUE VALUES
Fastener Size
x2
Driver/Left Rear Mounting Brackets (C)
x2
Passenger/Right Rear Mounting Brackets (F)
x16
8mm x 30mm Hex Bolts
x16
8mm x 25mm Combo Bolts
x16
8mm Lock Washers
x16
8mm x 24mm OD x 2mm Flat Washers
(E)
(D)
Driver/Left TYGER TRAX
1/3
Class 8.8 Torque (ft-lbs)
6mm
6-7
8mm
15-16
10mm
31-32
12mm
54-55
14mm
87-88
(A)
(B)
Scan to Download the
Latest Digital Version
Class 10.9 Torque (ft-lbs)
6-7
22-23
44-45
78-79
125-126
(C)
V240823
Advertisement
Related Manuals for Tyger TRAX TG-TX7T29798
Summary of Contents for Tyger TRAX TG-TX7T29798
- Page 1 CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT: 14mm 87-88 125-126 WWW.TYGERAUTO.COM/CONTACT Driver/Left Rear Mounting Brackets (C) Driver/Left Tyger Trax Passenger/Right Rear Mounting Brackets (F) Passenger/Right Tyger Trax Driver/Left Front Mounting Bracket (A) 8mm x 30mm Hex Bolts Passenger/Right Front Mounting Bracket (D)
