RISER
®
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE
CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO
IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF
ANY CLAIM. IF MISSING PARTS OR ANY DAMAGE FOUND, PLEASE TAKE A
PICTURE FOR THE CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Class 10.9 Torque (ft-lbs)
6-7
15-16
31-32
54-55
87-88
125-126
Customer Support: www.TygerAuto.com/Contact
TG-RS2D40068
x1
x1
x2
x2
x1
x1
x6
x12
x6
x12
x12
x12
x12
x6
6-7
x6
x10
22-23
x20
44-45
x10
78-79
x2
x4
x1
1/6
Parts List
Driver/Left T4 Sidebar
Passenger/Right T4 Sidebar
Driver/Left Front/ Passenger/Right Rear Bracket
Driver/Left Rear/ Passenger/Right Front Bracket
Driver/Left Center Bracket
Passenger/Right Center Bracket
Plastic Covers
Plastic Clips
8mm x 30mm Bolt Plates
8mm x 25mm Combo Bolts
8-1.25mm x 30 Hex Bolts
8mm x 24mm OD x 2mm Flat Washers
8mm Lock Washers
8mm Hex Nuts
8mm Plastic Retainers
6mm x 25mm Button Head Bolts
6mm x 18mm OD x 1.6mm Flat Washers
6mm Flange Nuts
16mm x 34mm Spacer Plates
16mm x 60mm Spacer Plates
4mm Hex Wrench
V201109
Advertisement
Related Manuals for Tyger RISER TG-RS2D40068
Summary of Contents for Tyger RISER TG-RS2D40068
- Page 1 RISER ® Parts List Driver/Left T4 Sidebar TG-RS2D40068 Passenger/Right T4 Sidebar Driver/Left Front/ Passenger/Right Rear Bracket Driver/Left Rear/ Passenger/Right Front Bracket BEFORE INSTALLATION Driver/Left Center Bracket READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE Passenger/Right Center Bracket CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO Plastic Covers IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF Plastic Clips...
