TAIL LIGHT GUARD
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE
CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO
IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF
ANY CLAIM. IF MISSING PARTS OR ANY DAMAGE FOUND, PLEASE TAKE A
PICTURE FOR THE CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Driver/Left
Tail light Guard
Class 10.9 Torque (ft-lbs)
6-7
15-16
31-32
54-55
87-88
125-126
(8) Rubber Spacers
Customer Support: www.TygerAuto.com/Contact
Parts List
TG-TG7J83338
6-7
22-23
44-45
78-79
1/3
Driver/Left Tail Light Guard
x1
Passenger/Right Tail Light Guard
x1
Rubber Spacers
x8
x4
Pan Head ST 5mm x 50mm (Large) Screws
Pan Head ST 4mm x 45mm (Small) Screws
x4
Passenger/Right
Tail light Guard
V200911
