ATTENTION!
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. PLEASE FOLLOW THE APPROVED
INSTALLATION ACCORDING TO THE WRITTEN INSTRUCTIONS.
FAILURE TO DO SO MAY CAUSE DAMAGE TO YOUR VEHICLE
AND INVALIDATE THE WARRANTY.
WARNING!
DIRT OR DEBRIS MAY BECOME LODGED BETWEEN FLARES AND
VEHICLE'S FENDERS CAUSING SCRATCHING AND PAINT WEAR
FROM VEHICLE VIBRATION. TYGER™ IS NOT RESPONSIBLE FOR
ANY DAMAGE, AND INSTALLATION IS DONE WITH BUYER'S
UNDERSTANDING
THAT
THIS
OCCUR.
PRIOR TO INSTALLATION:
CHECK EVERYTHING
USE NON-ABRASIVE
BEFORE INSTALLATION
SURFACE TO INSTALL
REMOVE DECALS &
MUD FLAPS FIRST
SAFETY INFORMATION:
NO AUTOMATIC
BRUSH-STYLE WASH
ABOUT PAINTING: Painted flares cannot be returned. Test fit
before painting. We are not responsible for any costs that may
incur if flares were painted without test fitting.
• Clean surface to be painted with a good grade degreaser. Do
not use lacquer thinner or any solvent based product.
• Wipe flare surface completely dry with a tack rag prior to paint.
• Application of plastic adhesion promoter for PP plastic as per
your paint system manufacturer's recommendations is required.
• Use a high quality enamel or polyurethane automotive paint to
paint the flares.
• Not recommend to paint the edge trim, but if desired use a flex
additive.
TG-FF8T4358
DAMAGE
MAY POTENTIALLY
VERIFY FITMENT OF
FLARES TO VEHICLE
ABRASIVE DETERGENT
IS PROHIBITED
CHECK TIGHTNESS
CHECK CAREFULLY
BEFORE DRIVE
Customer Support: www.TygerAuto.com/Contact
Customer Support: www.TygerAuto.com/Contact
Customer Support: www.TygerAuto.com/Contact
Customer Support: www.TygerAuto.com/Contact
Customer Support: www.TygerAuto.com/Contact
Customer Support: www.TygerAuto.com/Contact
TOOLS FOR EASIER INSTALLATION
Utility Knife
Soft Wiping Cloth
Socket Wrench
Electric Drill
1/2"
Wrench
Phillips Driver
HARDWARE KIT INCLUDED
31
338"
X
[A]
[B]
Edge Trim
Torx Bolt
4
2
X
X
[G]
[K]
PH Truss Screw
SS Torx Screw
1
X
Driver Side
1
X
Passenger Side
DAMAGED or MISSING parts?
www.TygerAuto.com/Contact
Page 1/8
Pry Tool
5/16"
Drill Bit
#2
Grease Pencil
35
33
X
X
[C]
[D]
SS Washer
Nylock Nut
1
2
X
X
[L]
[M]
Nylon Retainer
Edge Trim Tool
1
X
Driver Side
1
X
X
Driver Side
Passenger Side
10mm
Socket
1/8"
Drill Bit
Work Gloves
1
X
[E]
T45 Torx Bit
1
X
Passenger Side
1
V200720
