Summarization of Contents
Introduction and Support
Package Contents
Lists included items like the fixture, power cord, hanging bracket, and QR guide.
Service & Support Information
Provides details on the 2-year warranty, technical support website, and phone number for assistance.
Product Overview
Front View Components
Identifies and labels the front parts of the fixture, including the Moving Head, Yoke, Base, LED Display, buttons, and microphone.
Back View Components
Identifies and labels the rear connections and components like DMX In/Out, Power, and Fan.
Mounting
Orientation and Rigging Guidelines
Details how to mount the fixture in any position and provides guidelines for safe rigging practices, including ventilation and weight capacity.
Display Operation
Control Panel Navigation
Explains how to use the MENU, UP, DOWN, and ENTER buttons to navigate the fixture’s display and menus.
Menu Guide
Menu Options and Functions
Lists various menu settings like DMX Address, Channel Mode, Slave Mode, Sound Active, Sensitivity, Display Reverse, Motor Reverse, and System Reset.
Gobo and Color Channel Assignments
Gobo and Color Wheel Selections
Visually displays the available gobos (1-12) and color selections (1-7) for the fixture.
DMX Values
11-Channel DMX Mode
Details the channel assignments, value ranges, and functions for the 11-channel DMX mode.
13-Channel DMX Mode
Details the channel assignments, value ranges, and functions for the 13-channel DMX mode.
Additional DMX Functions
Covers remaining DMX functions for 13-channel mode like Prism Rotation, Rainbow Prism, Auto Mode, Sound Active, and Reset.
Stand Alone Settings
Automatic Programs
Instructions to run the fixture in automatic mode by selecting programs 1-4.
Sound Active Mode Setup
Steps to operate the fixture in sound-active mode and adjust sound sensitivity.
Invert Pan Configuration
How to invert the pan orientation of the fixture using the menu.
Invert Tilt Configuration
Instructions to invert the tilt orientation of the fixture via the menu.
Screen Reverse Settings
How to reverse the display orientation using menu options.
Maintenance
Cleaning and Care Instructions
Provides detailed steps for cleaning the fixture, including dust removal and cleaning transparent surfaces.
Technical Information
Product Specifications
Lists key technical specifications such as LED wattage, color wheel, gobos, dimmer, pan/tilt range, prism types, DMX modes, power consumption, dimensions, and weight.
Updates and Support Contact
Advises checking the website for updates and provides an email address for support.
