BENDIX MC-30 TRAILER ABS CONTROLLER Manual page 19

ABS Component
MC-30 ™ Controller
Harness
30-pin Packard
Metri-Pack
150 Series (Gray)
ABS Modulator
Connector
3-Pin Packard
Metri-Pack
280 Series
MOD 2
(Pigtail Side)
3-Pin Packard
Metri-Pack
280 Series
Power Connector
(Pigtail Side)
5-Pin Packard
Weather-Pack
Power Connector
(Vehicle Side)
5-Pin Packard
Weather-Pack
Wheel Speed
Sensor
2-Pin
DTM06-2S-E007
Diagnostic Port
4-Pin
(Remote Side / Cap)
Auxiliary
Port
8-Pin
DTM04-#P
™
CHART 12 - MC-30 CONTROLLER WIRING AND COMPONENT CONNECTORS
Connector
Terminal
12048455 12103881
(18-16 GA)
12040977
12077411
(18-16 GA)
15300003
12048159
(18-16 GA)
15324197
12124580
(14-16 GA)
12065158
12124582
(14-16 GA)
DTM04-2P
462-201-20141
(Pigtail Side)
(S-Side of
Connector)
(Sensor Side)
DTM06-4S
(Pigtail Side)
DTM04-4P
460-202-20141
(P-Side of
Connector)
DTM06-8S
(Pigtail Side)
DTM04-8P
(Remote Side)
DTM06-#S
Wire Wire Seal/
Plug
Plug
12065266
12015323
(18-16 GA)
Plug
12010300
Deutsch
DTM Series
N/A
WM-#P
Terminal Terminal
Lock Crimp Tool
12094429 for Metri-
N/A
Pack Terminals
12014012 for Weather
Pack Terminals
12034145
12155975 for Metri-
Pack Terminals
15300015
12014254 for Weather
Pack Terminals
N/A
HDT-48-00
WM-2P
(Pigtail Side)
WM-2S
(Sensor Side)
WM-4S
(Pigtail Side)
WM-4P
(Remote Side)
WM-8S
(Pigtail Side)
WM-2P
(Remote Side)
WM-#S
