BENDIX MC-30 TRAILER ABS CONTROLLER Manual page 10

4S/2M Axle to 2S/2M Axle
Your trailer has two wheel speed
sensors and two ABS modulators
that are plumbed for axle control.
The MC-30 ™
installed is currently confi gured for
4S/2M axle control.
Provide power to the MC-30
and verify the current confi guration
using the LEDs or blink codes.
4S/2M Axle
H o l d m a g n e t i n p l a c e f o r 2 0
seconds.
The LEDs will begin to roll as the
installed sensors and modulators are
detected.
Remove the magnet.
2S/2M Axle
Stop! You do not need to perform an
ABS control toggle in this case.
Verify the new confi guration using
the LEDs or blink codes.
CHART 7 - EXAMPLES OF SELF-CONFIGURATION AND ABS CONTROL TOGGLE (2 of 2)
10
controller you have
™
controller
4S/2M Side to
2S/1M Dolly-Axle
Your trailer has two wheel speed
sensors and two ABS modulators
that are plumbed for side control.
™
The MC-30 controller you have
installed is currently confi gured for
4S/2M side control.
Provide power to the MC-30
and verify the current configuration
using the LEDs or blink codes.
4S/2M Side
H o l d m a g n e t i n p l a c e f o r 2 0
seconds.
The LEDs will begin to roll as the
installed sensors and modulators are
detected.
Remove the magnet.
2S/1M Dolly-Axle
Stop! You do not need to perform an
ABS control toggle in this case.
Verify the new confi guration using
the LEDs or blink codes.
™ controller
