Active or Inactive Diagnostic Trouble Codes:
See Page 42 for Appendix A: J1587 SID and FMI Codes and Their Bendix Blink Code Equivalents
INDEX
How to interpret the first digit of messages received when
Active or Inactive Diagnostic Trouble Code Mode is entered.
1st
Blink
Go Here for Troubleshooting Tests
Code
Number
1 ............................................... No faults (1,1)
2 ............... Wheel Speed Sensors - page 18
3 ............... Wheel Speed Sensors - page 18
4 ............... Wheel Speed Sensors - page 18
5 ............... Wheel Speed Sensors - page 18
6 .............................. Power Supply - page 23
7 ........ Pressure Modulator Valves - page 20
8 ........ Pressure Modulator Valves - page 20
9 ........ Pressure Modulator Valves - page 20
10 ....... Pressure Modulator Valves - page 20
11 .......................................... J1939 - page 24
12 ............................ Miscellaneous - page 26
13 ............................................. ECU - page 25
14 .............. Wheel Speed Sensors - page 18
15 .............. Wheel Speed Sensors - page 18
16 ....... Pressure Modulator Valves - page 20
17 ....... Pressure Modulator Valves - page 20
18 ................ Traction Control Valve - page 22
Example: For a message sequence of:
3, 2 12, 4
For the first sequence go to page 18 and
for the second sequence go to page 26.
17
