BENDIX EC-15 ANTILOCK CONTROLLER ASSY Manual page 18

TURN IGNITION OFF, REFER TO FIGURES 7
AND 8, DISCONNECT WIRE HARNESS
START HERE
CONNECTOR FROM EC-15
(FRONT CONNECTOR ONLY IN FIGURE 7)
18
TROUBLESHOOTING
SECTION V - TESTING FOR POWER TO THE EC-15
TURN IGNITION ON AND, MEASURE
VOLTAGE BETWEEN BATTERY AND
GROUND PINS ON WIRE HARNESS
CONNECTOR (SEE FIGURES 7 AND 8).
VOLTAGE SAME AS BATTERY
VOLTAGE, MUST BE BETWEEN
11 AND 17 VOLTS.
YES
REPLACE EC-15
CONTROLLER
™
CONTROLLER
NO
™
™
CONTROLLER
RECONNECT CONNECTOR TO EC-15
CONTROLLER. CHECK THE VEHICLE
WIRING FOR CONTINUITY. REFER TO
THE VEHICLE SERVICE MANUAL AND
CHECK THE BATTERY VOLTAGE.
REPAIR OR REPLACE AS NECESSARY
AND REPEAT THE "INITIAL START-UP
PROCEDURE"
REPEAT THE
"INITIAL START-UP
PROCEDURE"
™
