BENDIX EC-15 ANTILOCK CONTROLLER ASSY Manual page 15

START HERE
NO
ARE ANY RED LEDS
ILLUMINATED?
YES
NOTE AND RECORD
THE CONDITION OF
ALL RED LEDS
GO TO SECTION IV
"INSPECTION FOR
ILLUMINATED LEDS".
GO TO SECTION VIII "TESTING
FOR FALSE FAILURE INDICATION
- CAUSED BY DASH LAMP
RELAY".
TROUBLESHOOTING
SECTION II - INSPECTION FOR ILLUMINATED LEDS
INSPECT EC-15
CONTROLLER FOR
PRESENCE OF
ILLUMINATED LEDS
AND RECORD.
CHECK CLOSELY
AND NOTE IF GREEN
LED IS ILLUMINATED
YES (ON)
NO
IS GREEN LED FLASHING?
GO TO SECTION V "TESTING
FOR POWER TO THE EC-15
CONTROLLER".
™
NO (OFF)
ARE ANY RED
LED'S
ILLUMINATED?
YES
™
REPLACE
YES
THE EC-15
CONTROLLER
NO
GO TO SECTION V
"TESTING FOR POWER
™
TO THE EC-15
CONTROLLER"
™
15
