BENDIX EC-15 ANTILOCK CONTROLLER ASSY Manual page 13

START HERE
DASH LAMP FLASHES AND COMES ON AND
STAYS ON. INCREASE VEHICLE SPEED TO
ABOVE 10 MPH FOR AT LEAST 30 SECONDS
AND OBSERVE THE DASH LAMP.
THE SYSTEM IS FUNCTIONING NORMALLY.
MAKE NOTES OF THE PARTS REPLACED OR
REPAIRED AND STEPS TAKEN ON THE TROUBLE
SHOOTING SHEET.
TROUBLESHOOTING
INITIAL START-UP PROCEDURE
TURN VEHICLE IGNITION ON.
OBSERVE DASH ANTILOCK
CONDITION LAMP.
IS DASH LAMP ILLUMINATED?
YES
DASH LAMP DOES NOT BLINK, IT COMES
ON AND REMAINS ON.
NO
DASH LAMP REMAINS ON
NO
NO
GO TO SECTION I
"DASH LAMP TESTING"
GO TO SECTION II
YES
"INSPECTION FOR
ILLUMINATED LED(S)"
YES
GO TO SECTION III "INSPECTION
FOR ILLUMINATED LED(S)".
