DEUTSCH 2 PIN
PACKARD 2 PIN
CONNECTOR
CONNECTOR
STRAIGHT WS-20
™
90° WS-20
™
WHEEL
WHEEL SPEED SENSOR
SPEED SENSOR
™
FIGURE 4 - WS-20
WHEEL SPEED SENSORS & CONNECTORS
SPEED SENSOR
MOUNTING
BLOCK
100 TOOTH SPEED
SENSOR EXCITER
RING
BRAKE DRUM
™
WS-20
WHEEL
SPEED SENSOR
(90 DEG.)
HUB ASSEMBLY
™
FIGURE 4A - WS-20
WHEEL SPEED SENSOR INSTALLATION
4
