VDO SENSORS - INSTRUMENTATION V3.0 Manual page 80

Tubular-Type Senders – Without Warning Contact, Common Ground or Insulated Return* (ø 54 mm)
Without Warning Contact,
Common Ground or Insulated Return
Technical Data
Rated voltage:
6 V to 24 V – Ground on tank housing
Operating temperature:
-25° C to +65° C or
-25° C to +70° C
Installation from above
* Depending on connection
80
Dimensions
ø 71 mm
Installation ø ø 41 mm
ø 40 mm
or
F1
F2
Type of Connection
I II
Hex nut (M4) Hex nut (M4)
and washer and washer
54 mm
G G
(ø 54 mm)
*
Special Features
A Seal
A1 Cork
ø 66.5 x 4.5 mm
A2 Rubber
ø 67 x 2.5 mm
A3 Rubber
ø 65 x 2.7 mm
A4 Cork
ø 65 x 3 mm
B Flange
C Flange assy
D Screws (M5)
and washers
E Screws (M5)
with sealing ring
Bottom of F Cover assy
tank F1 Compression spring
compressible down
to 6 mm
F2 Compression
spring compressible
down to 25 mm
III
Blade terminal
6.3 x 0.8 mm
54 mm
54 mm
G
4x
1x
C
E
4x
5x 1x
D
A
B
or
F
IV
Blade terminal
6.3 x 0.8 mm
Ground connector
6.3 x 0.8 mm
54 mm
G
