VDO SENSORS - INSTRUMENTATION V3.0 Manual page 31

Temperature Senders – Without Warning Contact, Common Ground or Insulated Return*
Article No.
323-801-001-006K 120
323-801-001-006N 120
323-801-001-007N 120
323-801-001-008N 120
323-801-001-009N 120
323-801-001-010K 120
323-801-001-010N 120
323-801-001-022K 120
323-801-001-022N 120
323-801-001-026K 120
323-801-001-026N 120
323-801-001-029N 120
323-801-001-033N 120
323-801-001-038D 100
323-801-001-040N 120
323-801-001-054D 120
323-801-003-001D 200
323-801-004-002N 150
323-801-004-003D 150
323-801-004-006D 150
323-801-004-007D 150
323-801-004-012C 150
323-801-004-017D 150
323-801-004-039D 150
323-801-004-039K 150
323-801-004-042D 150
323-801-005-001D 120
323-801-005-005D 120
323-801-009-001D 150
323-801-009-003D 150
323-801-010-001D 150
323-801-010-003K 150
323-801-012-001D 150
323-801-012-002D 150
323-801-012-002K 150
323-801-012-003D 150
323-801-013-001D 200
323-801-017-001K 120
323-801-017-001N 120
323-801-018-001D 200
323-801-020-002D 120
- 90 51.2 ± 5.3
- 90 51.2 ± 5.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 4.3
- 90 51,5 ± 4.3
- 90 51.2 ± 4.3
- 90 51.2 ± 5.3
- 160 32.2 ± 2.1
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 90 51.2 ± 4.3
- 90 51.2 ± 5.3
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 ± 2.7
- 120 36.5 + 4.0 -2.7
- 120 36.5 + 4.0 -2.7
- 120 36.5 + 4.0 -2.7
- 120 36.5 + 4.0 -2.7
- 160 32.2 ± 2.1
- 90 51.2 ± 5.3
- 90 51.2 ± 5.3
- 160 32.2 ± 2.5
- 90 51.2 ± 4.3
M14 x 1.5
M14 x 1.5
3/8 – 18 NPTF
5/8 – 18 UNF – 3A
1/4 – 18 NPTF
1/2 – 14 NPTF
1/2 – 14 NPTF
M18 x 1.5
M18 x 1.5
M14 x 1.5
M14 x 1.5
M16 x 1.5
5/8 – 18 UNF-2A with taper seat
3/8 – 18 NPTF
M16 x 1.5
M14 x 1.5
M10 x 1.5
M14 x 1.5
R 1/2
1/2 – 14 NPTF
1/2 – 14 NPTF
M16 x 1.5
1/4 – 18 NPTF
M14 X 1.5 Thread length 14
M14 X 1.5 Thread length 14
1/2 – 20 UNF – 2A
1/8 – 27 NPTF
M10 x 1,0
1/8 – 27 NPTF
M10 X 1 con. short
M10 x 1.5
M12 x 1.5
M16 x 1.5
M14 x 1.5
M14 x 1.5
M18 x 1.5
1/8 – 27 NPTF
M10 X 1 con. short
M10 X 1 con. short
1/8 – 27 NPTF
M14 x 1.5
9 29 A
9 29 A
9 29 A
9 29 A
9 29 A
9 29 A
9 29 A
9 29 A
9 29 A
9 29 E
9 29 E
9 29 E
9 29 A
9 29 E
9 29 A
9 29 D
6.9 22 C
9 29 A
9 29 A
9 29 D
9 29 A
9 29 E
9 29 D
9 29 B
9 29 B
9 29 D
8.5 22 C
8.5 22 C
8.2 22 C
8.2 22 C
6.9 22 C
6.9 22 C
9 15 B
9 15 B
9 15 B
9 15 B
8.2 ±0.2 22 ±0.5 C
without 10.5 C
without 10.5 C
without 10.5 C
9 24 F
