Summary of Contents for VDO CANCOCKPIT
- Page 1 CANcockpit Flexible instrumentation with CAN bus technology...
- Page 2 VDO products are modular instrumentation solution may be integrated deployed in a wide range of applications from con- into existing VDO panel solu tions. Thanks to the struction vehicles, agricultural and forestry equipment powerful WINgauge software it is exceptionally easy to to stationary machines, sports cars and boats.
- Page 3 Engine oil Brake Transmission Coolant pressure pressure oil pressure temperature temperature Up to 16 instruments can be controlled by a central instrument. Integration into VDO panel solutions can be carried Fuel Battery current Battery voltage out easily.
- Page 4 Variable configuration options CANcockpit, the flexible solution for a wide range of puts, three resistive inputs, one 4–20 mA input, plus applications, offers numerous configuration and ex- one 0–5 volt input. In addition, it is equipped with two pansion options. It is based around a central instrument switched outputs, a configurable digital display field which can be either a tachometer or a speedometer.
- Page 5 Any for central instrument, 0–85 ° for satellite instruments Operating temperature – 40 to + 85 °C, limitated LCD readability beyond – 20 °C and + 70 °C Storage temperature – 40 to + 85 °C For further information about VDO visit the website at www.vdo.com.
- Page 6 WINgauge Flexible configuration software WINgauge has been specially developed for CANcock- training to help you program a CANcockpit solution. pit. This software enables the convenient and flexible This training tells users everything they need to know configuration of individual instruments or a complete about the innovative features, such as how to person- series of instruments.
- Page 7 Selecting the central instrument and Setting the basic CAN settings (if applica- Sensor database and mapping adjust- basic settings ble) emnts for optimum performance Setting warnings and alarms including DTC handling and personal configuration Programming of requests, e. g., query choice of response and priorities with individual messages and symbols operating hours...
- Page 8 VDO – A Trademark of the Continental Corporation The information provided in this brochure contains only general descriptions or performance characteristics, which do not always apply as described in case of actual use or which may change as a result of further development of the products. This information is merely a technical description of the product. This information is not meant or intended to be a special guarantee for a particular quality or particular durability.
