VDO SENSORS - INSTRUMENTATION V3.0 Manual page 32

Temperature Senders – Without Warning Contact, Common Ground or Insulated Return*
Article No.
323-803-001-061C
323-803-001-062C
323-803-001-064C
323-804-015-005D
323-805-001-001K
323-805-001-001N
323-805-001-002C
323-805-001-004K
323-805-001-004N
323-805-001-005N
323-805-001-015N
323-805-003-001N
323-805-003-002N
323-805-003-003N
323-805-017-002C
323-805-034-002B
323-805-039-001C
323-805-042-001C
323-809-019-003A
325-801-002-002D
325-805-003-001C
325-805-003-002C
325-805-003-003C
* Depending on connection
** For dual-station readings
32
100 116 ±3 90 51.2
100 114 ±3 90 51.2
100 112 ±3 90 51.2
120 - 90 88.6
120 - 90 51.2
120 - 90 51.2
120 - 90 51.2
120 - 90 51.2
120 - 90 51.2
120 - 90 51.2
120 - 90 51.2
150 - 120 36.5
150 - 120 36.5
150 - 120 36.5
120 - 100 40.10 ± 0.8
130 - 90 426.2 ± 17.6
130 - 90 3300 ± 143
140 - 90 92.3
120 - 90 457.6 ± 19.5
120 - 90 25.6
120 - 90 25.6
120 - 90 25.6
120 - 90 25.6
± 4.3 1/2 – 14 NPTF
± 4.3 1/2 – 14 NPTF
± 4.3 1/2 – 14 NPTF
± 9 1/8 – 27 Dryseal NPTF
± 4.3 M14 x 1.5
± 4.3 M14 x 1.5
± 4.3 5/8 – 18 UNF-2A with taper seat
± 4.3 1/2 – 14 NPTF
± 4.3 1/2 – 14 NPTF
± 4.3 3/8 – 18 Dryseal NPTF
± 4.3 M18 x 1.5
± 2.7 M14 x 1.5
± 2.7 1/4 – 18 NPTF
± 2.7 5/8 – 18 UNF-2A with taper seat
M14 x 1.5
M14 x 1.5
M14 x 1.5
± 5.2 M14 x 1.5
M18 x 1.5
+ 2.8 -1.8 M18 x 1.5
± 3 1/4 – 18 NPTF
± 3 5/8 – 18 UNF-2A with taper seat
± 3 3/8 – 18 NPTF
10.8 ±0.4 40 ±0.4 G
10.8 ±0.4 40 ±0.4 G
10.8 ±0.4 40 ±0.1 G
8.2 22 C
11 29 G
11 29 G
11 29 G
11 29 G
11 29 G
11 29 G
11 29 G
11 29 G
11 29 G
11 29 G
8.5 -0.3 29 -0.3 H
7.5 29 H
8.5 29 H
8.5 29 H
13 ±0.2 35 ±0.6 H
9 29 A**
10.9 29 G**
11 29 G**
10.9 29 G**
