Technical data

4.1

General data and operating conditions

Conformity and approval
Conformity
CE
Approval
UL
Protection of persons and devices
Enclosure
Insulation resistance
Insulation of control
circuits
Short−circuit strength
Protective measures
against
Discharge current
Cyclic mains switching
Starting current
Supply conditions
AC mains operation
Power systems
TT
TN
IT
DC−bus operation
Motors
EDS84ASC552 EN 6.0
efesotomasyon.com - Lenze
General data and operating conditions
2006/95/EG Low−Voltage Directive
l
UL 508C Approved:
– Device size 1 ... 5 (0.25 ... 15 kW)
– Device E84AV ... with safety unit
l
In preparation:
– Device size 6 (18.5 ... 22 kW)
IP 20 ^ 106
EN 60529
NEMA 250 Protection against accidental
contact according to type 1
EN 61800−5−1 Overvoltage category III
above 2000 m amsl: overvoltage category II
EN 61800−5−1 Safe mains isolation by double/reinforced insulation.
EN 61800−5−1 Motor connection: limited, controller is inhibited, error
acknowledgement is required
Control terminals: full
l
Short circuit
l
Earth fault
l
Overvoltage
l Motor stalling
l
Motor overtemperature
(PTC or thermal contact, I
EN 61800−5−1 > 3.5 mA AC, > 10 mA DC
Cyclic mains switching at intervals of 3 min is permissible. If
the mains is exceptionally switched three times in one
minute, a pause of 9 min must follow.
A circuit that can be reset automatically protects the device
against destruction.
£ 2 x I
N
Direct connection
Operation is permitted without restrictions.
Observe instructions with regard to specific measures.
Direct connection for devices with 400 V mains connection
possible
EN 60034 Only use motors suitable for inverter operation. Insulation
resistance:
min. û ³1.5 kV, min. du/dt ³5 kV/ms
l
Technical data
in ready−for−use mounted
state
2
t monitoring)
Observe the regulations
and safety instructions!
4
23
