Output Tags - Allen-Bradley 5069-OF8 User Manual

Table 38 - 5069-OF4, 5069-OF8 Module - Output Tags
Name
Chxx.LLimitUnlatch
Chxx.HLimitUnlatch
Chxx.RampAlarmUnlatch
Chxx.Calibrate
Chxx.CalOutputLowRef
Chxx.CalOutputHighRef
Chxx.CalLowRefPassed
Chxx.CalHighRefPassed
Chxx.CalFinishCalibration
Chxx.Data

Output Tags

Table 38 describes the 5069-OF4, 5069-OF8 module output tags.
Size Definition
BOOL Unlatches a latched Low Limit alarm at the first instance of the bit
transitioning from 0 to 1.
BOOL Unlatches a latched High Limit alarm at the first instance of the bit
transitioning from 0 to 1.
BOOL Unlatches a latched Ramp alarm at the first instance of the bit transitioning
from 0 to 1.
BOOL Initiates the Calibration process.
This tag must remain set until a valid Low Reference and High Reference
values are applied to the channel.
BOOL A 0 to 1 transition commands the channel to produce the Low Calibration
Reference Point for the chosen current or voltage output range.
BOOL A 0 to 1 transition commands the channel to produce the High Calibration
Reference Point for the chosen current or voltage output range.
BOOL A 0 to 1 transition indicates that the Chxx.Data output tag data contains the
recorded Low Reference value for the channel that is used by the module in
Calibration.
BOOL A 0 to 1 transition indicates that the Chxx.Data output tag data contains the
recorded High Reference value for the channel that is used by the module in
Calibration.
BOOL Data value change that triggers the channel to complete the Calibration
procedure, applying the Valid Low and High References received.
Channel exits the Calibration state if successful.
REAL The value that is converted to the signal on the RTB in scaled Engineering
Units.
Rockwell Automation Publication 5000-UM005B-EN-P - November 2015
Module Tag Definitions Appendix B
Valid Values
• 0 = Alarm remains latched
(default)
• 1 = Alarm is unlatched
• 0 = Alarm remains latched
(default)
• 1 = Alarm is unlatched
• 0 = Alarm remains latched
(default)
• 1 = Alarm is unlatched
• 0 = Calibration process is
not started (default)
• 1 = Calibration process is started
• 0 = Do not output Cal Low
Reference
• 1 = Output Calibration Low
Reference
Do not set this tag and the
CalOutputHighRef tag to 1
simultaneously.
• 0 = Do not Output Cal High
Reference
• 1 = Output Calibration High
Reference Signal
Do not set this tag and the
CalOutputLowRef tag to 1
simultaneously.
• 0 = Not sending Recorded Cal
Low Ref
• 1 = Sending Recorded Cal Low
Reference in Output Data for
Calibration Verification
• 0 = Not sending Cal High
Reference
• 1 = Sending recorded Calibration
High Reference Signal in Output
Data for Calibration Verification
• 0 = Channel not triggered to
complete the calibration
procedure
• 1 = Channel triggered to
complete the calibration
procedure
Any valid engineering unit
159
