Chapter 4 Current/Voltage/Temperature-sensing Analog Input Module Features (5069-IY4)
Table 20 - 5069-IY4 Module - Fault and Status Data Tags
Data Type Tag Name
ConnectionFaulted
Chxx.Fault
CJChxx.Fault
Chxx.OpenWire
Fault
CJChxx.OpenWire
Chxx.Underrange
CJChxx.Underrange
Chxx.Overrange
CJChxx.Overrange
RunMode
DiagnosticActive
DiagnosticSequenceCount
Chxx.Uncertain
CJChxx.Uncertain
Chxx.OverTemperature
CJChxx.Temperature
Chxx.FieldPowerOff
CJChxx.FieldPowerOff
Chxx.NotANumber
Chxx.LLAlarm
Chxx.LAlarm
Status
Chxx.HAlarm
Chxx.HHAlarm
Chxx.RateAlarm
Chxx.Data
RollingTimestamp
(1) This tag provides module-wide data and affects all channels simultaneously.
72
Triggering Event That Sets Tag
(1)
The owner-controller loses its connection to the module.
The channel data quality is bad.
The cold junction data quality is bad.
The following conditions:
• The channel uses a Voltage input type in any input range and the input signal value reaches full scale.
• The channel uses a Current input type in only the 4...20 mA input range and the input signal goes below 100
μA. The input signal at the channel is below 100 μA.
• When the channel uses RTD or Thermocouple input type and a wire is disconnected from the channel.
When a wire is disconnected from the cold junction.
The channel data is beneath the absolute minimum for this channel.
The cold junction at the channel is beneath the absolute minimum for this channel.
The channel data is above the absolute maximum for this channel.
The cold junction at the channel is above the absolute maximum for this channel.
(1)
The module is in Run Mode.
Indicates if any diagnostics are active or if the prognostics threshold is reached.
The count increments a diagnostic.
The channel data can be imperfect but it is not known to what degree of inaccuracy.
The cold junction data can be inaccurate but it is not known to what degree of inaccuracy.
The module is operating at a higher temperature than its rated operating limits.
Current temperature of the cold junction.
Field power is not present on the channel.
Field power is not present at the cold junction.
The most recently received data value was not a number.
The following conditions exist:
• The I.Chxx.Data tag value is less than the C.Chxx.LLAlarmLimit tag value or the alarm is latched.
• The O.Chxx.LLAlarmEn tag is set.
• Alarms are enabled for the channel.
The following conditions exist:
• The I.Chxx.Data tag value is less than the C.Chxx.LAlarmLimit tag value or the alarm is latched.
• The O.Chxx.LAlarmEn tag is set.
• Alarms are enabled for the channel.
The following conditions exist:
• The I.Chxx.Data tag value is greater than the C.Chxx.HAlarmLimit tag value or the alarm is latched.
• The O.Chxx.HAlarmEn tag is set.
• Alarms are enabled for the channel.
The following conditions exist:
• The I.Chxx.Data tag value is greater than the C.Chxx.HHAlarmLimit tag value or the alarm is latched.
• The O.Chxx.HHAlarmEn tag is set.
• Alarms are enabled for the channel.
The following conditions exist:
• The absolute change between consecutive channel samples exceeds the C.Chxx.RateAlarmLimit tag value or the
alarm is latched.
• The O.Chxx.RateAlarmEn tag is set.
• Alarms are enabled for the channel.
The channel data in scaled Engineering Units.
(1)
A continuously running, 15-bit timer that counts in milliseconds and is not related to the CST.
Whenever a module scans its channels, it records the value of RollingTimestamp then. The controller program uses
the last two rolling timestamp values to calculate the amount of time between the samples.
