Summarization of Contents
Preface
Additional Resources
Lists related publications from Rockwell Automation for further information.
Analog I/O Module Operation in a Logix5000 Control System
Construct a 5069 Compact I/O System
Explains the minimum components required to build a 5069 Compact I/O system.
Configure a 5069 Compact I/O System
Describes the process of creating a Logix Designer project for module configuration.
Requested Packet Interval
Explains the RPI parameter for setting the data exchange rate between modules.
Protected Operations
Restricts operations based on module mode for secure and predictable operation.
Common Analog I/O Module Features
Module Data Quality Reporting
Details how modules indicate the quality and accuracy of channel data.
Software Configurable
Explains that module features are enabled/disabled via Logix Designer.
Electronic Keying
Reduces device errors by comparing project definition to installed device.
Scaling
Configures the module to return data in signal or engineering units.
Current/Voltage Analog Input Module Features (5069-IF8)
Multiple Input Ranges
Describes selectable input ranges based on the chosen input type.
Notch Filter
Removes line noise by attenuating the input signal at a specified frequency.
Underrange/Overrange Detection
Detects when the module operates beyond the limits set by the input range.
Process Alarms
Alerts when module exceeds configured high or low limits for each channel.
Fault and Status Reporting
Details how the 5069-IF8 module reports fault and status data.
Current/Voltage/Temperature-sensing Analog Input Module Features (5069-IY4)
Multiple Input Ranges
Describes selectable input ranges for current, voltage, RTD, and thermocouple.
Cold Junction Compensation
Accounts for thermoelectric effect in thermocouple measurements for accuracy.
Fault and Status Reporting
Details how the 5069-IY4 module reports fault and status data.
Current/Voltage Analog Output Module Features (5069-OF4, 5069-OF8)
Connection Fault Handling
Configures module behavior when connection to owner-controller breaks.
Output Clamping
Limits output to configured range, even if controller commands outside range.
Output Ramping/Rate Limiting
Limits analog output signal change speed to prevent device damage.
Fault and Status Reporting
Details how the 5069-OF4/OF8 modules report fault and status data.
Configure the Module
Create a New Module
Adding modules to the Logix Designer project via discovery or manual selection.
Module Definition
Accessing parameters that define the module's series, revision, and keying.
Connection Category
Configuring RPI, connection type, and fault handling for the module.
Edit 5069-IF8 Module Configuration Categories
Specific configuration categories for the 5069-IF8 module.
Edit 5069-IY4 Module Configuration Categories
Specific configuration categories for the 5069-IY4 module.
Edit 5069-OF8 Module Configuration Categories
Specific configuration categories for the 5069-OF8 module.
Calibrate the Module
Calibrate the Input Modules
Steps for calibrating input modules using low/high signal references.
Calibrate the Output Modules
Steps for calibrating output modules using a digital multimeter (DMM).
Troubleshoot Your Module
Module Status Indicator
Describes the Module (MOD) Status Indicator states and recommended actions.
Use the Logix Designer Application for Troubleshooting
How Logix Designer indicates fault conditions through various means.
Module Diagnostics Dialog Box
Accessing detailed module diagnostic information via the properties dialog box.
Module Tag Definitions
5069-IF8 Module Tags
Lists configuration, input, and output tags for the 5069-IF8 module.
5069-IY4 Module Tags
Lists configuration, input, and output tags for the 5069-IY4 module.
5069-OF4, 5069-OF8 Module Tags
Lists configuration, input, and output tags for the 5069-OF4/OF8 modules.
