Chapter 3 - Allen-Bradley 5069-OF8 User Manual

Current/Voltage Analog Input Module
Features (5069-IF8)
Topic
Module Features
Fault and Status Reporting
The 5069-IF8 input module has eight differential, non-isolated channels. Each
channel supports connection to the following input types:
• Current
• Voltage
Differential inputs have a greater resistance to the effects of electromagnetic noise
and provide improved flexibility regarding cable length when wiring your
module.
Remember the following:
IMPORTANT
• This module also has features that apply to all 5069 Compact I/O™ analog
I/O modules that are described in Chapter 2,
Features on page
• You can configure the features that are described in this chapter with the
Logix Designer application.
For more information on how to configure the module, see Chapter 6,
Configure the Module on page
