Installation Instructions
Original Instructions
Compact 5000 I/O Analog 8-channel Current/Voltage Input
Module
Catalog Number 5069-IF8
Topic
The 5069-IF8 analog 8-channel current/voltage input module offers differential, non-isolated input channels that can connect to current or voltage
input devices. The module supports multiple ranges for each input type.Differential inputs have greater resistance to the effects of electromagnetic
noise in a control system.
Compact 5000 I/O™ modules use the Producer/Consumer communication model. The Producer/Consumer communication model is an
intelligent data exchange between module and other system devices in which each module produces data without first being polled.
For more information on how to use Compact 5000 I/O modules, see the publications that are listed in
Summary of Changes
The following changes were made to this revision of this publication.
Topic
Updated graphics that shows the lower hook that can be used with a cable tie
Page
5
5
7
7
8
9
9
10
12
12
12
13
14
Page(s)
5, 5, and 10
5
8
10
12
13
Additional Resources on page
14.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compact 5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allen-Bradley Compact 5000

Summary of Contents for Allen-Bradley Compact 5000

  • Page 1: Table Of Contents

    For more information on how to use Compact 5000 I/O modules, see the publications that are listed in Additional Resources on page Summary of Changes The following changes were made to this revision of this publication.
  • Page 2 COMPACT 5000 Analog 8-channel Current/Voltage Input Module ATTENTION: Read this document and the documents listed in the Additional Resources section about installation, configuration and operation of this equipment before you install, configure, operate or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
  • Page 3 COMPACT 5000 Analog 8-channel Current/Voltage Input Module Waste Electrical and Electronic Equipment (WEEE) At the end of its life, this equipment should be collected separately from any unsorted municipal waste. Environment and Enclosure ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating.
  • Page 4 COMPACT 5000 Analog 8-channel Current/Voltage Input Module IEC Hazardous Location Approval The following applies to products with IECEx certification: Such modules: • Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and for short periods. Such locations correspond to Zone 2 classification to IEC 60079-0.

  • Page 5: Module Overview

    IMPORTANT: You must order RTBs separately. RTBs do not ship with Compact 5000 I/O modules. We recommend that you order only the RTB type that your system requires. An end cap ships with the CompactLogix 5380 controllers and the...
  • Page 6 5069-FPD field potential distributors to establish a new SA power bus. SA power buses are isolated from each other. If a system includes Compact 5000 I/O modules that use AC SA power and modules that use DC SA power, you must install them on separate SA power buses.

  • Page 7: Install The Removable Terminal Block

    SA power is ATTENTION: Do not discard the end cap. Use this end lost, MOD power remains available for the Compact 5000 I/O cap to cover the exposed interconnections on the last modules.

  • Page 8: Install The End Cap

    COMPACT 5000 Analog 8-channel Current/Voltage Input Module 5. Align the interlocking pieces of the module with the device on Install the End Cap the left. You must install an end cap on the last module in your system. The top interlocking pieces engage first.

  • Page 9: Wire The Removable Terminal Block

    COMPACT 5000 Analog 8-channel Current/Voltage Input Module Wire the Removable Terminal Block Disconnect Wires from the Removable Terminal Block WARNING: If you connect or disconnect wiring while power is WARNING: If you connect or disconnect wiring while power is applied, an electric arc can occur. This could cause an explosion in applied, an electric arc can occur.

  • Page 10: Wiring Diagram

    COMPACT 5000 Analog 8-channel Current/Voltage Input Module Wiring Diagram The following is an example wiring diagram for the 5069-IF8 analog input module in current mode. ANALOG INPUT 5069-IF8 – 2-wire Input 0 + Transmitter 24V DC Input 0 - Channel Connections –...
  • Page 11 COMPACT 5000 Analog 8-channel Current/Voltage Input Module The following is an example wiring diagram for the 5069-IF8 analog input module in voltage mode. ANALOG INPUT 5069-IF8 User Analog Input 0 + 24V DC Input Device Input 0 - – –...

  • Page 12: Use A Cable Tie

    After you connect the required wires to the RTB, you can use a cable After you install all Compact 5000 I/O modules, you can turn on tie to bundle the wires. There is a lower hook at the bottom of the MOD power and, if used, SA power to the system.

  • Page 13: Specifications

    COMPACT 5000 Analog 8-channel Current/Voltage Input Module Specifications This table lists a subset of the module specifications. For a list of all specifications, see the Compact 5000 I/O Modules and EtherNet/IP Adapters Technical Data, publication 5069-TD001. 5069-IF8 Analog 8-channel Current/Voltage Input Module Specifications...

  • Page 14: Additional Resources

    Provides declarations of conformity, certificates, and other certification details. overview.page You can view or download publications at http://www.rockwellautomation.com/global/literature-library/overview.page. To order paper copies of technical documentation, contact your local Allen-Bradley distributor or Rockwell Automation sales representative. Rockwell Automation Publication 5069-IN010B-EN-P - November 2017...
