Summarization of Contents
Installation Instructions
Safety Clearances
Essential for safe installation, adhering to national/local regulations and consulting chimney sweeps.
Distance Regulations
Specifies required gaps to flammable/non-flammable walls and minimum distances.
Floor Requirements
Ensure the floor can bear the stove's weight and is nonflammable.
Chimney Connection
Chimney opening must meet regulations; area should never be less than 175 cm².
Chimney and Draft Considerations
Connecting to Chimneys
Guidance for connecting to brick and steel chimneys, ensuring proper flue gas flow.
Draft Conditions and Performance
Explains required draft (13 PA), factors influencing it, and common causes of reduced draft.
Operating Procedures
Combustion Air Flow
Details on regulating airflow via front handle for optimal combustion.
First Firing
Initial firing process to harden coating, requiring ventilation and specific door handling.
Fuel Guidelines
Guidelines on using only clean, dry wood, avoiding treated or refuse materials.
Lighting and Adding Fuel
Procedures for lighting the stove and adding new fuel for optimal combustion.
Advanced Operation and Safety
Reduced Burning and Chimney Fires
Techniques for reduced output burning and procedures for handling chimney fires.
Optimal Combustion and Air Supply
Ensuring efficient heating and preventing soot by managing primary and secondary air.
Risk of Explosion
Warning about potential explosion risks from overfilling or insufficient airflow.
Troubleshooting and Maintenance
Operational Problems
Addresses common issues like chimney blockage, draft problems, and seal integrity.
Maintenance and Cleaning
Guidance on cleaning the stove's exterior, glass, and handling soot deposits.
Guarantee and Modifications
Heta Stove Guarantee
Details the five-year guarantee, exclusions for wear parts, and conditions for claims.
Warning Against Modifications
Highlights that unauthorized modifications or non-original spares will void the guarantee.
External Air Inlet Installation
Fitting External Air Inlet - From Below
Step-by-step instructions for installing an external air inlet kit.
Cleaning Procedures
Clearing Soot After Sweeping or Renewing Stones
Sequence of removal for stones, baffle, and cleaning air ducts behind rear stone.
Model Specific Information
Rear Stone Assembly
Details on the two-part rear stone and its fitting mechanism.
Scan-Line 95/100 Without Pedestal
Special conditions regarding floor distance for models without a pedestal.
Transportation Safety
Transportation Safety Device
Instruction to remove a specific screw before using or turning the stove.
