Page 1 Operating Instructions ND 1300 QUADRA-CHEK (QC 320) Optical Edge Detection and Crosshair Systems English (en) 2/2010...
Page 3 QC-300 Series User’s Guide Optical Edge Detection Systems QC-320, QC-321, QC-323, QC-324 QC-320E, QC-321E, QC-323E, QC-324E ...
Page 4 QC-300 Series Optical Edge Detection and Crosshair Systems User’s Guide Published by Metronics, Inc. 30 Harvey Road Bedford, New Hampshire 03110 www.Metronics.com User’s Guide part number: 11A10569 Revision 2 Publishing date: December, 2007 Printed in United States of America Copyright © 2007 by Metronics, Inc., Bedford, New Hampshire QC-300 software version: 2.00 All information set forth in this document, all rights to such information, any and all inventions disclosed herein and any patents that might be granted by employing the materials, methods, techniques or apparatus described herein are the exclusive property of Metronics Inc., Bedford, New Hampshire. Terms, conditions and features referenced in this document are subject to change without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permis- sion of Metronics, Inc.. Requests to Metronics, Inc. for permission should be addressed to the Technical Services Department, Metronics, Inc., 30 Harvey Road, Bedford, New Hampshire 03110. Limit of liability and disclaimer of warranty While this guide was prepared with great care, Metronics makes no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. The advice, methods and instructions contained in this book might not be suitable for your situation. When in doubt regarding suitability, you...
Page 5 Conventions & Terms QC-300 refers to any of the QC-300 series of instruments. System refers to the QC-300 and the measuring devices connected to it. Icons This guide uses the following icons to highlight information: WARNINGS The raised hand icon warns of a situation or condition that can lead to personal injury or death.
Page 6 WARNINGS Disconnect the QC-300 from power before cleaning. The QC-300 is equipped with a 3-wire power plug that includes a separate ground connection. Always connect the power plug to a 3-wire grounded outlet. The use of accessories that remove the third grounded connection such as a 2-wire power plug adapter create a safety hazard and should not be permitted.
Page 7: Table Of Contents
Contents 1 Contents Chapter 1 Overview Overview of the QC-300 features and functions ......... 1 Chapter 2 Installation Unpacking the QC-300 ................5 Assembling the mounting stand ..............6 Safety considerations ................... 6 Power cord and plug ................6 Electrical wiring and connections ............6 Location and mounting .................
Page 8 Contents 2 QC-300 Series User’s Guide Goto feature ................... 19 Multiple Extra tabs ................19 Command buttons and wide keys ..............20 Feature list ....................21 LCD Screen functions .................. 22 Number keys ....................23 System functions ..................24 Datum lock .................... 24 Undo .....................
Page 9 Contents 3 QC-300 Series User’s Guide Selecting a magnification ..............46 Lighting ....................46 Calibration .................... 47 Edge teach ..................47 Distance calibration ............... 47 Cross calibration ................47 Probing with edge detectors ................. 48 Automatic point entry ................48 Manual point entry ................
Page 10 Contents 4 QC-300 Series User’s Guide Constructing features ................... 70 Point constructions ................70 Point constructed from a point ............70 Point constructed from a point and a line ........70 Points constructed from an arc and a line ........71 Points constructed from a line ............
Page 11 Contents 5 QC-300 Series User’s Guide Lines constructed between two rectangles ........95 Line constructed from a rectangle ..........97 Line constructed from multiple features ........97 Distance constructions ................98 Distance constructed from a distance ..........98 Distances constructed from two points .......... 98 Distances constructed from a point and a line ....... 99 Distances constructed from a point and a rectangle ......
Page 12 Contents 6 QC-300 Series User’s Guide Creating features ..................121 Creating a point ..................121 Creating a line ..................122 Creating a circle ..................122 Creating an arc ..................123 Creating a slot ..................123 Creating a rectangle ................124 Chapter 7 Tolerancing Applying tolerances to features ..............
Page 13 Contents 7 QC-300 Series User’s Guide Chapter 8 Programming Creating programs ..................139 Start program recording ................ 140 Enter a program title (or user message) ..........141 Measure a skew and create a datum ............. 142 Measure a feature (include a message) ..........142 Apply a tolerance ..................
Page 14 Contents 8 QC-300 Series User’s Guide Chapter 10 Setup The Setup Menu ................... 164 Accessing and using the Setup Menu ..........164 Entering the supervisor password ..........165 Selecting items from the Setup Menu ........... 166 Selecting setup parameter choices ..........166 Entering and deleting setup data ............
Page 15 Contents 9 QC-300 Series User’s Guide Example .acf file ................... 181 Calibrating from features ..............182 Calibrating NLEC by adjusting station values ........184 Calibrating NLEC with existing NLEC correction text file ....185 Magnifications screen .................. 186 Adding magnifications ................186 Deleting magnifications ................ 186 Edge calibrations for routine measurements ......... 187 Edge calibrations for difficult measurements ........
Page 16 Contents 10 QC-300 Series User’s Guide Stop motion ................... 200 Goto feature ................... 200 Header screen ....................201 Creating report headers ................. 201 Print screen ....................202 Specifying a data type ................202 Specifying a data destination ..............202 Report Type ..................202 Lines per page ..................
Page 17 Contents 11 QC-300 Series User’s Guide Digital positioner screen ................214 Enabling digital positioner motion ............214 Specifying axis direction ..............214 Specifying normal and fine axis velocity ..........214 Specifying axis acceleration ..............214 Specifying a digital positioner counter debounce ......... 214 Current value display ................
Page 18 Contents 12 QC-300 Series User’s Guide Chapter 13 Product Options List of product options ................. 229...
Page 19: Overview
Chapter 1: Overview The Quadra-Chek 300 series is a family of advanced digital readout systems for performing 2, 3 and 4 axis measurements at very high levels of precision and accuracy. Dimensional inspection of components can be made using comparator or toolmaker’s microscope systems as part of in-line production activities or final qual ity inspection.
Page 20 QC-300 Series User’s Guide Wide keys Print/Send data Touch screen controls Numeric keypad Command keys Color touch screen LCD ON/OFF Front panel keys enter numeric data, turn the LCD on or off and send data to a printer or computer. Two wide keys located over the LCD can quickly be pressed without looking at the front panel to initiate frequently used functions programmed by the user. All front panel keys provide tactile sensory feedback, and key-press operations can be configured to generate an audible sound.
Page 21 Description of QC-300 Features External footswitch CNC outputs Speaker jack Optical inputs USB port Encoder inputs RS-232 port Tilt adjust Measurements viewed on the LCD can be transmit t ed to a PC over USB or RS-232 ports or to a printer over the USB port. The compact ergonomic design and adjustable-tilt front panel of the QC-300 allow users to locate and mount the instrument in a wide variety of environments that accommodate nearly any viewing require- ment.
Page 22 QC-300 Series User’s Guide...
Page 23: Installation
Chapter 2: Installation The QC-300 is easy to install in a variety of basic and advanced measurement applications. This chapter describes how to unpack and install the QC-300. Repackaging instructions are also included for return shipments and for distributors and OEM customers that are configuring a QC-300 and shipping it to an end-user.
Page 24: Assembling The Mounting Stand
QC-300 Series User’s Guide Assembling the mounting stand The QC-300 is secured to the swivel slots of the mounting stand by a shoulder screw, a cap screw and associated washers. Assemble the QC-300 to the mounting stand as shown. Tighten the shoulder screw (1), and then tighten the cap screw (5) and washers (3 &...
Page 25: Location And Mounting
Safety and Power Location and mounting Rest the QC-300 on a flat, stable surface, or bolt it to a stable surface from the bot- tom using four 10/32 screws fastened in the pattern shown at the right. Power surge suppressor Connect the QC-300 to power through a high-quality power surge suppressor. Surge suppressors limit the amplitude of potentially damaging power line transients caused by electrical machinery or lightning.
Page 26: Connecting A Printer
QC-300 Series User’s Guide Connecting a printer The QC-300 supports certain USB printers. Printer models must be specified by Metronics when the QC-300 is ordered, or approved by Metronics later. Verify that the QC-300 and printer power are off. Connect the USB printer to the USB Type A port on the side of the enclosure.
Page 27: Connecting An Optional Footswitch
Connections Connecting an optional footswitch The optional foot switch is connected to the RJ-45 connector on the rear of the QC-300. Verify that the QC-300 is off. Connect the foot switch to the RJ-45 con- nector on the rear connector panel. Footswitch connector Connecting the optical edge detector inputs The optional optical inputs are connected to the two optical jacks on the rear of the QC-300.
Page 28: Connecting Optional Cnc Outputs
QC-300 Series User’s Guide Secure the sensor cable to the plastic mounting plate. Point the reference sensor directly at the comparator lamp. Consult the comparator manufacturer’s information for specific mounting instructions. CAUTION Avoid mounting fiber-optic cables next to the lamp. High temperatures degrade fiber- optic cable performance.
Page 29: Warranty Registration Form
Warranty and Shipping Warranty registration form The warranty registration form included in the shipping carton should be completed and mailed as soon as possible. Also record the purchase and warranty information here so that it will be readily available later to support any necessary interactions with distributor or factory technical support personnel.
Page 30 QC-300 Series User’s Guide...
Page 31: User Interface
Chapter 3: User Interface The QC-300 user interface consists of hardware front panel buttons and number keys that work in coopera- tion with software menus, buttons, and data fields shown on the color LCD touch screen. The hardware/ software interface is divided into the function areas listed and shown below. • Measurement functions • LCD ON/OFF or delete features • Command buttons and wide keys • Number keys • Feature list • System functions...
Page 32: Measurement Functions
QC-300 Series User’s Guide Measurement functions The measurement functions are divided into two tabbed areas: • Measure Select a measurement type, such as circle or line • Program Record, edit or play back a program of measurement steps Selecting a measurement type Measurement types are selected from the Measure tab. Touch the Measure tab to display icons for the different measure types.
Page 33: Accessing Programming Functions
Measurement Functions Accessing programming functions Programming functions are accessed from the Program tab. Touch the Program tab to display a list of programs and programming tools. Details regarding programming and the use of programming tools are provided in Chapter 8: Programming. Touch the Program tab...
Page 34: Sending Data To A Computer From The Extra Tab
QC-300 Series User’s Guide Sending data to a computer from the Extra tab Touch a data icon shown in the Extra tab to send the corresponding data element for the current position or selected feature to a computer over the serial port. Touch the Extra tab to display the data choices. Touch the Extra tab...
Page 35 Measurement Functions The Extra tab is typically used to send abbreviated data to the serial port since complete reports or screens of data can be sent using the Print function described in Chapter 10: Setup. However, a complete data set can be sent for a feature from the Extra tab by touching the required series of icons in succession.
Page 36: Cnc And Other Extra Tab Functions
QC-300 Series User’s Guide CNC and other Extra tab functions Additional CNC functions for programming, motion control, edge probe calibration and Extra tab format- ting functions can also be made available in the Extra tab as described in Chapter 10: Setup, in the Display screen section.
Page 37: Part Following
Extra tab Functions Part following The Part following function is included in the Extra tab of sys- tems with the CNC option. Part following changes the motion reference from the machine coordinate system to the part coordi- Part following Part following nate system after a part skew has been performed.
Page 38: Command Buttons And Wide Keys
QC-300 Series User’s Guide Command buttons and wide keys The command buttons and wide keys are primarily used to support measurement and setup activities. The command wide keys are duplicates of the Enter and Finish functions which are the most frequently used command buttons, and can be located and pressed easily by the operator without looking at the front panel.
Page 39: Feature List
Command Buttons, Wide Keys and the Feature List Feature list The feature list provides access to all fea- tures that have been measured, constructed or created. Measurements are selected by touching them in the feature list, and then viewed or toleranced in other screens. Feature list When the feature list contains too many...
Page 40: Lcd Screen Functions
QC-300 Series User’s Guide LCD Screen functions LCD Screen functions The LCD functions are used to select the screen that will be presented on the color touch LCD, generally in support of the next operator activity Touch a button to select the desired screen. • DRO Displays the digital readout • VIEW Displays the selected feature’s data cloud • TOL Displays the tolerance screens for entering and editing tolerances DRO screen View screen...
Page 41: Number Keys
LCD Screen Functions and Number Keys Number keys The number keys are used to enter data into feature constructions and creations, tolerances, programs, and Number setup data fields. keys Numbers are entered into data fields in the conventional manner, and can be erased when necessary by back- spacing over them using the Cancel button.
Page 42: System Functions
QC-300 Series User’s Guide System functions System functions System functions support a wide variety of mea- surement and setup activities. System functions include: • Datum lock • Undo • Probe • Magnification (Mx) • Unit of measure (mm/Inch) • Setup Datum lock The lock icon indicates that features are locked to the datums used when they were measured. When the lock icon is not shown, new datums are applied to all features in the feature list as they are created.
Page 43: Magnification
System Functions Touch the desired probe type to select it. Touch the Probe button... to select a probe type... from the drop-down list Magnification The Magnification function provides access to a drop down list of available measurement magnifications. Touching the Magnification button shows the list of available magnifications. Touch the desired magnifi- cation to select it.
Page 44: Setup
QC-300 Series User’s Guide Setup The setup function provides access to all of the system setup screens required for configuring QC-300 measurement and operation. Touch the setup button to display the setup screen and menu. Access to the setup menu is given through two introductory screens that show the software version, the system options and a caution regarding the use of setup functions.
Page 45: Lcd On/Off And Deleting Feature Data
System Functions and LCD On/Off LCD ON/OFF and deleting feature data The LCD screen can be turned off without cycling power when the QC-300 will not be used for an extended period, but it is desirable to retain the original machine zero en- coder references. Press the red LCD ON/OFF button to toggle the LCD on and off.
Page 46 QC-300 Series User’s Guide...
Page 47: Quick Start Demonstration
Chapter 4: Quick Start Demonstration This chapter demonstrates the operation of the QC-300 system. The demonstration is provided as a means of quickly helping experienced operators to use the system. This demonstration will be most helpful if you perform the measurements and other activities as you follow along. The demonstration will use the Metronics QC Quickie slide to create a part skew and datum, measure a part feature, apply a few tolerances, print a tolerance report and save all these activities as a program that can be recalled and run again later.
Page 48: Start Recording A Program
QC-300 Series User’s Guide Start recording a program To record the following activities as a program: Touch the Program tab to dis- play the program screen and then touch the Record icon. The text entry screen will be displayed. Enter a program title and press the Finish key.
Page 49: Create Part Skew And Datum References
Measuring a Part Skew Create part skew and datum references When the part is misaligned (twisted) in the X-Y plane, errors can be generated during the measurement process. These errors can be eliminated by creating a skew alignment for the part. The skew alignment includes a precise measurement of the part misalignment.
Page 50: Create A Datum Zero Point
QC-300 Series User’s Guide Create a datum zero point Creating the datum zero point is the final step in establishing a valid Cartesian or polar coordinate system for subsequent measurements. The datum zero point will be used as the origin of the measurement system. The datum zero point can be positioned in any location that satisfies the measurement requirements of the user and can be created by probing a point or by constructing a point from parent features.
Page 51: Constructing A Datum Zero Point
Creating a Datum Constructing a datum zero point The datum zero point can be constructed from parent features when simply probing the desired point is not practical. It would not be possible to provide a single description of this process for all measurement applications that require feature constructions.
Page 52 QC-300 Series User’s Guide While the point feature is selected touch the X and Y axis Zero buttons to zero the values and establish a datum zero at the probed point. The point will then be shown in blue in the feature list.
Page 53: Measure A Feature
Measuring a Feature Measure a feature In this example, the largest of the three holes of the QC Quickie slide will be measured using the crosshair probe. NOTES More information regarding feature measurements and constructions is contained in Chapter 6: Measuring. More information regarding the use of crosshair or optional edge detection probes is contained in Chapter 5: Probes.
Page 54 QC-300 Series User’s Guide Press the Finish key to com- plete the feature measurement and store the feature in the fea- ture list. The feature and probed points can be reviewed in detail by touching the View button if desired.
Page 55: Apply Tolerances To A Feature Measurement
Applying Tolerances Apply tolerances to a feature measurement In this example, a true position tolerance will be applied to the circle measurement. To apply a tolerance: With the circle feature select- ed, touch the Tol screen button to display the tolerance screen. Touch the desired toler- ance type icon button to select a tolerance type.
Page 56 QC-300 Series User’s Guide Enter nominal, limit or tolerance values. In this example, the Nominal and Tol Dia (Tolerance diam- eter around the nominal position) values are entered by touching the desired data fields and entering new values using the number keys. Error and Deviation values are generated as soon as the Nominal and Tol Dia values are entered.
Page 57: Print A Report
Printing Reports Print a report To print a report of the current position (Display), the feature list (Report) or tolerances (Tol Report): Verify that the QC-300 is attached to a USB printer as described in Chapter 9: Communication. Verify that the report content and printer formatting are specified correctly in the Print setup screen described in Chapter 9: Communication and Chapter 10: Setup.
Page 58: Stop Program Recording
QC-300 Series User’s Guide Stop program recording To end a recording session: Touch the Program tab to display the programming tools, and then touch the Stop icon to stop record- ing the program. The program title will be shown on the left side of the screen. The program is now saved and can be edited or run on new parts.
Page 59: Running The Program
Saving an Running Programs Running the program To run a program, touch the Pro- gram tab to display the program screen, select the desired program and then touch the Run icon to run the selected program.
Page 60 QC-300 Series User’s Guide...
Page 61: Chapter 5 Probes
Chapter 5: Probes Measurements are conducted using crosshairs or (optional) optical edge detection. In either case, point entry can be manual or automatic. In addition, part probing can be entirely manual or assisted by programs that are prepared by the user. Crosshair and edge detection probes are described in this chapter.
Page 62: Probes
QC-300 Series User’s Guide Probes Edge detector and crosshair probes can be used to collect data points for feature measurements. Both probe types include manual and automatic point entry func- tions. Touch the Probe button icon to select a probe. Auto-enter optical edge detection Points are entered automatically when edges are crossed Manual optical edge detection...
Page 63: Automatic Point Entry
Probe Descriptions Automatic point entry When automatic point entry is used to measure features, the point is entered each time the stage is moved to position the part under the crosshair. The automatic point entry is delayed until the stage has been motionless for a short time after the move to ensure that the crosshair is located where the user intended.
Page 64: Preparing To Use Probes
QC-300 Series User’s Guide Preparing to use probes The accuracy and repeatability of measurements depend on the mechanical condition of the system, the condition of the part, system optics, lighting and calibration. System and part condition The measuring system is presumed to be undamaged and well maintained, which implies a recent calibra- tion, and a clean stage with acceptably small amounts of mechanical backlash.
Page 65: Calibration
Preparing to Use Probes Calibration Specification of encoder resolution is the first essential setup step explained in Chapter 10: Setup. NOTE All the essential setup steps described at the beginning of Chapter 10: Setup must be performed before conducting measurements. In some cases, it might also be necessary to perform error correction calibration to eliminate the effects of encoder and machine travel in accuracies.
Page 66: Probing With Edge Detectors
QC-300 Series User’s Guide Probing with edge detectors Points can be probed at light to dark or dark to light transitions using automatic or manual point entry. Automatic point entry To probe using edge detection and automatic point entry: 1 Select the auto point entry edge probe. 2 Teach the edge detector at the beginning of a measurement session, when lighting changes, when magnification changes or when other measurement conditions change.
Page 67: Manual Point Entry
Probing with Edge Detectors Manual point entry To probe using edge detection and manual point entry: 1 Select the manual point entry edge probe. 2 Teach the edge detector at the beginning of a measurement session, when lighting changes, when magnification changes or when other measurement conditions change.
Page 68: Probing With Crosshairs
QC-300 Series User’s Guide Probing with crosshairs Points can be probed using automatic or manual point entry. Automatic point entry To probe using crosshairs and automatic point entry: 1 Select the auto point entry crosshair probe. 2 Touch the desired measure icon button and then position the cross- hair over the first target point.
Page 69 Chapter 6: Measuring Measurements can be performed manually or automatically (CNC option) using crosshairs or optional optical edge detection. Measurements can be limited to probing feature points, or can include the con- struction or creation of new features in addition to probing. However measurements are conducted, the fundamental measurement process and the tools required to perform measurements remain unchanged.
Page 70: Measurement Activities
QC-300 Series User’s Guide Measurement activities QC-300 measurement sessions can include two or more of the following activities: • Establishing a measurement reference • Constructing features • Probing and measuring features • Creating features The measurement process The basic measurement process shown here is identical for all feature types. The details of individual measurement steps are described in the remaining pages of this section.
Page 71: Establishing The Measurement Reference
The Measurement Process NOTE When edge detection is used, the edge detection must be calibrated, and the optical system must be clean. The edge calibration is described in Chapter 5: Probes. Establishing the measurement reference A reliable measurement reference must be established before part features can be probed and measured. This reference will be created by the user and ensures a level part surface, precise part alignment and a coordinate origin or datum zero.
Page 72: Skewing The Part
QC-300 Series User’s Guide 2 Touch the Level icon and perform the leveling measurement by probing three or more points that are well distributed across the surface of the desired part plane. Use the Crosshair to probe, move the Z-axis of the stage to focus the part surface under the Crosshair and then press the Enter key to enter each point. Press the Finish key to complete the level measurement.
Page 73: Creating A Datum Zero Point
Establishing a Measurement Reference Perform the skew alignment by probing 2 or more points well distributed along the entire length of the desired part reference edge. Press the Enter key to enter each point. Press the Finish key to com- plete the Skew measurement.
Page 74: Constructing A Datum Zero Point
QC-300 Series User’s Guide While the point feature is selected touch the X and Y axis Zero buttons to establish a datum zero at the probed point. Constructing a datum zero point The datum zero point can be constructed from parent features when simply probing the desired point is not practical.
Page 75 Establishing a Measurement Reference Probe two or more points well distributed along the left side of the part, and then press the Finish button. The line feature will be added to the Features list. Touch the Measure Point icon, and then touch each of the two lines in the feature list to checkmark them.
Page 76: Probing And Measuring Features
QC-300 Series User’s Guide Probing and measuring features Part features are measured by creating a part datum, and then by probing points that define the feature’s shape and location. Feature points can be probed using Measure Magic or by using a specific measure- ment function such as the line or circle function.
Page 77: Probing Specific Feature Types
Probing and Measuring Features Probing specific feature types When measure magic is not used a measure icon must be touched before each specific feature type is probed. However, a series of features of the same type can be probed by touching the desired measure icon and then touching multiple measurement icon.
Page 78: Probing Process
QC-300 Series User’s Guide Probing process The feature probing process is essentially the same for all feature types. Touch the desired measure icon Probe and enter features, then press Results are displayed in the DRO Finish to complete measurements and View windows Supported feature types The following feature measurements are supported by the QC-300: • Points • Slots...
Page 79: Backward/Forward Annotation
Probing and Measuring Features Backward/forward annotation Forward annotation is used to specify a required number of probed points for each feature type. Backward annotation allows the user to probe any number of points beyond the minimum requirement for any feature type.
Page 80: Probing Specific Feature Types
QC-300 Series User’s Guide Probing specific feature types While the probing process is essentially the same for all feature types, the minimum number of points required and the geometric placement of these points are different. The unique requirements for probing each feature type are described in the remainder of this section.
Page 81: Probing Lines
Probing and Measuring Features Probing lines A minimum of two probed points is required to measure a line. There is no practical limit to the number of points that can be probed, and in general accuracy is increased by probing more points. In this example, three points are probed to measure a line When only two points are probed, Measure Magic will correctly recognize a line and assign the correct feature.
Page 82: Probing Arcs
QC-300 Series User’s Guide Probing arcs A minimum of three probed points is required to measure an arc. There is no practical limit to the number of points that can be probed, and in general accuracy is increased by probing more points. In this example, three points are probed to measure an arc When the arc is less than 185 degrees, Measure Magic will correctly recognize the arc and assign the cor- rect feature.
Page 83 Probing and Measuring Features Probing circles A minimum of three probed points is required to measure a circle. There is no practical limit to the number of points that can be probed, and in general accuracy is increased by probing more points. In this example, four points are probed to measure an circle When 185 degrees or more of the circle is probed, Measure Magic will correctly recognize the circle and assign the correct feature.
Page 84: Probing Slots
QC-300 Series User’s Guide Probing slots Five probed points are required to measure a slot. The five points must be probed in a prescribed pattern, and must be probed in a clockwise or counterclockwise sequence. As shown above, the correct pattern of points probed around the slot is: • Two points well distributed along one long side, followed by • One point on the closest end, followed by • One point on the approximate center of the second long side, followed by...
Page 85: Probing Rectangles
Probing and Measuring Features Probing rectangles Five probed points are required to measure a rectangle. The five points must be probed in a prescribed pattern, and must be probed in a clockwise or counterclockwise sequence. As shown above, the correct pattern of points probed around the rectangle is: • Two points well distributed along one long side, followed by • One point on the closest end, followed by • One point on the approximate center of the second long side, followed by...
Page 86: Probing Distances
QC-300 Series User’s Guide Probing distances Two probed points are required to measure a distance. Measurement results are shown in the Feature list, View window, and the DRO window. The View window shows the fea- ture and the points used to define it.
Page 87: Probing Angles
Probing and Measuring Features Probing angles A minimum of four probed points are required to measure an angle. The points must be probed in a pre- scribed pattern on the two lines that form an angle. There is no practical limit to the number of points that can be probed, and in general accuracy is increased by probing more points.
Page 88: Constructing Features
QC-300 Series User’s Guide Constructing features Features can be constructed from one or more existing features. Existing features used to construct new features are called parent features, and can be features that were measured, constructed or created. Existing features are shown in black, and constructed features are shown in blue in the View window. Point constructions Points can be constructed from: • Points • Angles...
Page 89: Points Constructed From An Arc And A Line
Constructing Features Points constructed from an arc and a line Up to three point constructions can be made from an arc and a line: • Intersection point 1: The first intersection of the arc and line • Intersection point 2: The second intersection of the arc and line • Perpendicular point: The intersection of the line and the perpendicular from the arc center to the line Intersection point 1...
Page 90: Points Constructed From A Line
QC-300 Series User’s Guide Points constructed from a line Up to four point constructions can be made from a line: • Midpoint: The center of the line • End point 1: The first endpoint of the line • End point 2: The second endpoint of the line • Anchor point: The intersection of the line and the perpendicular from the datum to the line Midpoint...
Page 91: Point Constructed From Two Lines
Constructing Features Point constructed from two lines The intersection point of the lines will be constructed. The virtual intersec- tion point will be calculated and shown if the lines do not actually cross. To construct a point from two lines: Touch the Measure Point icon Touch one desired line feature Press the Enter key...
Page 92: Point Constructed From A Distance And A Point
QC-300 Series User’s Guide Point constructed from a distance and a point A point feature will be constructed and offset from the parent point fea- ture by the parent distance feature. To construct a point from a point and a distance: Touch the Measure Point icon Touch the point feature Press the Enter key...
Page 93: Points Constructed From A Circle And A Line
Constructing Features Points constructed from a circle and a line Up to three point constructions can be made from an circle and a line: • Intersection point 1: The first intersection of the circle and line • Intersection point 2: The second intersection of the circle and line • Perpendicular point: The intersection of the line and the perpendicular from the circle center to the line Intersection point 1...
Page 94: Points Constructed From Two Circles
QC-300 Series User’s Guide Points constructed from two circles Up to three point constructions can be made from two circles: • Intersection point 1: The first intersection of the two circles • Intersection point 2: The second intersection of the two circles • Midpoint: The midpoint of the congruent portion of the two circles Intersection point 1 Intersection point 2...
Page 95: Point Constructed From A Slot
Constructing Features Point constructed from a slot A point feature will be constructed at the center of a slot. To construct a point from a slot: Touch the Measure Point icon Touch the slot feature Press the Enter key Press the Finish key A point feature will be constructed at the center of the slot.
Page 96: Point Constructed From An Arc
QC-300 Series User’s Guide Point constructed from an arc A point feature will be constructed at the center of an arc. To construct a point from an arc: Touch the Measure Point icon Touch the arc feature Press the Enter key Press the Finish key A point feature will be constructed at the center of the arc.
Page 97: Line Constructions
Constructing Features Line constructions Lines can be constructed from: • Points • Angles • Lines • Arcs • Distances • Slots • Circles Line constructed from a line A duplicate feature can be useful when it becomes desirable to perform new operations with the original while retaining a copy.
Page 98: Lines Constructed From A Point And A Line
QC-300 Series User’s Guide Lines constructed from a point and a line Two line constructions can be made from a point and a line: • Perpendicular line: The line from the point to the line, perpendicular to the line • Parallel line: The line through the point parallel to the line To construct a line from a point and a line:...
Page 99: Lines Constructed From A Point And A Circle
Constructing Features Lines constructed from a point and a circle Up to three line constructions can be made from a point and a circle: • Two point line: The line from the point to the center of the circle • Tangent line 1: The line from the point to the first tangent of the circle • Tangent line 2: The line from the point to the second tangent of the circle Two point line...
Page 100: Line Constructed From A Point And A Slot
QC-300 Series User’s Guide Line constructed from a point and a slot The line will be constructed from the point to the center of the slot. To construct a line from a point and a slot: Touch the Measure line icon Touch the point feature Press the Enter key Touch the slot feature...
Page 101: Lines Constructed From A Point And An Arc
Constructing Features Lines constructed from a point and an arc Up to three line constructions can be made from a point and an arc: • Two point line: The line from the point to the center of the arc • Tangent line 1: The line from the point to the first tangent of the arc • Tangent line 2: The line from the point to the second tangent of the arc Two point line...
Page 102: Lines Constructed From Two Lines
QC-300 Series User’s Guide Lines constructed from two lines Up to three line constructions can be made from two lines: • Midline 1: Bisects the acute angle between the two lines • Midline 2: Bisects the obtuse angle between the two lines • Gage line: The line of a specified length perpendicular to bisector 1 (The user will be prompted for the length)
Page 103: Line Constructed From A Line And A Distance
Constructing Features Line constructed from a line and a distance A line feature will be constructed and offset from a parent line feature by a parent distance feature. To construct a line from a line and a distance: 1 Touch the Measure Line icon Touch the line feature Press the Enter key Touch the distance feature...
Page 104: Lines Constructed From A Line And A Slot
QC-300 Series User’s Guide Lines constructed from a line and a slot Two line constructions can be made from a line and a slot: • Perpendicular line: The line from the center of the slot, to the line, perpendicular to the line • Parallel line: The line through the center of the slot, parallel to the line To construct a line from a line and a...
Page 105: Line Constructed From A Line And An Angle
Constructing Features Line constructed from a line and an angle The line will be constructed and rotated counterclockwise the amount equal to the parent angle. To construct a line from a line and an angle: 1 Touch the Measure Line icon Touch the line feature Press the Enter key Touch the angle feature Press the Enter key...
Page 106: Lines Constructed From Two Circles
QC-300 Series User’s Guide Lines constructed from two circles Up to three line constructions can be made from two circles: • Two point line: The line between the two circle centers • Tangent line 1: The first line tangent to both circles on the same side • Tangent line 2: The second line tangent to both circles on the opposite side Two point line...
Page 107: Lines Constructed From A Circle And An Arc
Constructing Features Lines constructed from a circle and an arc Up to three line constructions can be made from a circle to an arc: • Two point line: The line between the circle and arc centers • Tangent line 1: The first line tangent to the circle and arc on the same side • Tangent line 2: The second line tangent to the circle and arc on the opposite side To construct a line between a circle and an arc:...
Page 108: Lines Constructed From A Circle And A Slot
QC-300 Series User’s Guide Lines constructed from a circle and a slot Up to three line constructions can be made from a slot to a circle: • Two point line: The line between the slot and circle centers • Tangent line 1: The first line tangent to the slot and circle on the same side • Tangent line 2: The second line tangent to the slot and circle on the opposite side To construct a line from a slot and a circle:...
Page 109: Line Constructed From A Slot
Constructing Features Line constructed from a slot The line feature will be constructed from the arc center at one end of the slot to the arc center at the other end. To construct a line from a slot: 1 Touch the Measure Line icon Touch the slot feature Press the Enter key Press the Finish key...
Page 110: Lines Constructed From A Rectangle And A Circle
QC-300 Series User’s Guide Lines constructed from a rectangle and a circle Up to three line constructions can be made from a rectangle to a circle: • Two point line: The line between the rectangle and circle centers • Tangent line 1: The first line tangent to the rectangle and circle on the same side • Tangent line 2: The second line tangent to the rectangle and circle on the opposite side To construct a line from a rectangle and a circle:...
Page 111: Lines Constructed From A Slot And An Arc
Constructing Features Lines constructed from a slot and an arc Up to three line constructions can be made from a slot to an anc: • Two point line: The line between the slot and arc centers • Tangent line 1: The first line tangent to the slot and arc on the same side • Tangent line 2: The second line tangent to the slot and arc on the opposite side To construct a line from a slot and an arc:...
Page 112: Lines Constructed From A Rectangle And An Arc
QC-300 Series User’s Guide Lines constructed from a rectangle and an arc Up to three line constructions can be made from a rectangle to an anc: • Two point line: The line between the rectangle and arc centers • Tangent line 1: The first line tangent to the rectangle and arc on the same side • Tangent line 2: The second line tangent to the rectangle and arc on the opposite side To construct a line from a rectangle and an arc:...
Page 113: Lines Constructed From A Slot And A Rectangle
Constructing Features Lines constructed from a slot and a rectangle The line feature will be constructed from the center of the slot to the center of the rectangle. To construct a line from a slot and a rectangle: 1 Touch the Measure Line icon Touch the slot feature Press the Enter key Touch the rectangle feature...
Page 114 QC-300 Series User’s Guide Line constructed from two arcs Up to three line constructions can be made from two arcs: • Two point line: The line between the two arc centers • Tangent line 1: The first line tangent to both arcs on the same side • Tangent line 2: The second line tangent to both arcs on the opposite side Two point line...
Page 115: Line Constructed From A Rectangle
Constructing Features Line constructed from a rectangle The line feature will be constructed from the radius center at one end of the rectangle to the radius center at the other end. To construct a line from a slot: 1 Touch the Measure Line icon Touch the rectangle feature Press the Enter key Press the Finish key...
Page 116: Distance Constructions
QC-300 Series User’s Guide Distance constructions Distances can be constructed from: • Points • Circles • Lines • Arcs • Distances • Slots Distance constructed from a distance A duplicate feature can be useful when it becomes desirable to perform new operations with the original while retaining a copy.
Page 117: Distances Constructed From A Point And A Line
Constructing Features Distances constructed from a point and a line The distance feature will be construct- ed from the point to the line perpen- dicular to the line, or perpendicular to the extended virtual line if the line feature is short. To construct a distance from a point and a line: Touch the Measure Distance icon...
Page 118: Distances Constructed From A Point And A Circle
QC-300 Series User’s Guide Distances constructed from a point and a circle Up to three distance constructions can be made from a point to a circle: • Distance between features: The distance between the point and circle center • Nearest distance: The distance between the point and nearest circle circumference • Farthest distance: The distance between the point and farthest circle circumference Distance between features...
Page 119: Distance Constructed From A Point And A Slot
Constructing Features Distance constructed from a point and a slot The distance feature will be constructed between the point and the cen- ter of the slot. To construct a distance from a point to a slot: Touch the Measure Distance icon Touch the point Feature Press the Enter key Touch the slot Feature...
Page 120: Distances Constructed From A Point And An Arc
QC-300 Series User’s Guide Distances constructed from a point and an arc Up to three distance constructions can be made from a point to an arc: • Distance between features: The distance between the point and arc center • Nearest distance: The distance between the point and nearest arc circumference • Farthest distance: The distance between the point and farthest arc circumference Distance between features...
Page 121: Distance Constructed From A Line
Constructing Features Distance constructed from a line The length-of-axis distance feature will be constructed from a parent line feature. To construct a distance from a line: Touch the Measure Distance icon Touch the line Feature Press the Enter key Press the Finish key The new distance feature will be constructed over the line.
Page 122: Distances Constructed From Two Lines
QC-300 Series User’s Guide Distances constructed from two lines Up to three distance constructions can be made from two lines: • Center distance: The perpendicular distance from the first line in the features list to the center of the second • Min distance: The perpendicular distance from the first line in the features list to the nearest point of the second • Max distance: The perpendicular distance from the first line in the features list to the farthest point of the second...
Page 123: Distances Constructed From A Line And A Circle
Constructing Features Distances constructed from a line and a circle Up to three distance constructions can be made from a line and a circle: • Center distance: The perpendicular distance from the line to the center of the circle • Min distance: The perpendicular distance from the line to the nearest point of the circle • Max distance: The perpendicular distance from the line to the farthest point of the circle...
Page 124: Distances Constructed From A Line And An Arc
QC-300 Series User’s Guide Distances constructed from a line and an arc Up to three distance constructions can be made from a line and an arc: • Center distance: The perpendicular distance from the line to the center of the arc • Min distance: The perpendicular distance from the line to the nearest point of the arc • Max distance:...
Page 125: Distance Constructed From A Line And A Slot
Constructing Features Distance constructed from a line and a slot The distance feature will be constructed from the center of the slot per- pendicular to the line. To construct a distance from a line and a slot: Touch the Measure Distance icon Touch the line Feature Press the Enter key Touch the slot Feature...
Page 126: Distances Constructed From Two Circles
QC-300 Series User’s Guide Distances constructed from two circles Up to three distance constructions can be made from two circles: • Center distance: The distance from the center of one circle to the center of the other • Min distance: The minimum distance between the two circle circumferences • Max distance: The maximum distance between the two circle circumferences Center distance...
Page 127: Distances Constructed From A Slot And A Circle
Constructing Features Distances constructed from a slot and a circle The distance feature will be constructed between the centers of the slot and the circle. To construct a distance from a slot and a circle: Touch the Measure Distance icon Touch the slot Feature Press the Enter key Touch the circle Feature...
Page 128: Distances Constructed From An Arc And A Circle
QC-300 Series User’s Guide Distances constructed from an arc and a circle Up to three distance constructions can be made from an arc and a circle: • Center distance: The distance from the center of the circle to the center of the arc • Min distance: The minimum distance between the arc and circle circumferences • Max distance:...
Page 129: Distance Constructed From Two Slots
Constructing Features Distance constructed from two slots The distance feature will be constructed between the centers of two slots. To construct a distance between two slots: Touch the Measure Distance icon Touch the first slot Feature Press the Enter key Touch the second slot Feature Press the Enter key Press the Finish key...
Page 130: Distances Constructed From A Rectangle And An Arc
QC-300 Series User’s Guide Distances constructed from a rectangle and an arc The distance feature will be constructed between the centers of the rect- angle and the arc. To construct a distance from a rectangle and an arc: Touch the Measure Distance icon Touch the rectangle Feature Press the Enter key Touch the arc Feature...
Page 131: Distances Constructed Between Two Rectangles
Constructing Features Distances constructed between two rectangles The distance feature will be constructed between the centers of two rectangles. To construct a distance between two rectangles: Touch the Measure Distance icon Touch the first rectangle Feature Press the Enter key Touch the second rectangle Feature Press the Enter key Press the Finish key...
Page 132: Distances Constructed From Two Arcs
QC-300 Series User’s Guide Distances constructed from two arcs Up to three different distance constructions can be made from two arcs: • Center distance: The distance from the center of one arc to the center of the other • Min distance: The minimum distance between the two arc circumferences • Max distance: The maximum distance between the two arc circumferences Center distance...
Page 133: Circle Constructions
Constructing Features Circle constructions Circles can be constructed from: • Points • Slots • Lines • Distances • Circles • Arcs Circle constructed from a circle A duplicate feature can be useful when it becomes desirable to perform new operations with the original while retaining a copy.
Page 134: Circle Constructed From A Circle And A Distance
QC-300 Series User’s Guide Circle constructed from a circle and a distance An offset circle will be constructed from circle and distance parent fea- tures. A circle equal to the parent circle will be constructed, offset the amount equal to the parent distance. To construct a circle from a circle and a distance: Touch the Measure Circle icon Touch the circle feature...
Page 135: Circle Constructed From Multiple Features
Constructing Features Circle constructed from multiple features A circle feature can be constructed from any number of parent features. The parent features can be any combination of points, slots, rectangles, arcs and circles. The center points of the parent features will be used to construct the new circle feature.
Page 136: Arc Constructions
QC-300 Series User’s Guide Arc constructions Arcs can be constructed from: • Points • Slots • Lines • Distances • Circles • Arcs Arc constructed from an arc A duplicate feature can be useful when it becomes desirable to perform new operations with the original while retaining a copy.
Page 137: Angle Constructions
Constructing Features Angle constructions Angles can be constructed from: • An angle • Two lines Angle constructed from an angle A duplicate feature can be useful when it becomes desirable to perform new operations with the original while retaining a copy. To construct an angle from an existing angle: Touch the Measure Angle icon Touch the desired angle Press the Enter key...
Page 138: Angle Constructed From Two Lines
QC-300 Series User’s Guide Angle constructed from two lines Up to four angle constructions can be made from two lines: • Interior angle: The angle included between the lines • 180 minus: 180 degrees minus the angle included between the lines • 180 plus: 180 degrees plus the angle included between the lines • 360 minus 360 degrees minus the angle included between the lines...
Page 139: Creating Features
Creating Features Creating features Features can be created by entering information that describes feature size and position. Information can be entered in metric or English units of measure. The following feature types can be created: • Points • Lines • Distances • Rectangles • Circles • Arcs • Slots Creating a point To create a point:...
Page 140: Creating A Line
QC-300 Series User’s Guide Creating a line To create a line: Touch the measure line icon, and then touch the data entry icon. The data entry box will be dis- played. Enter the feature data in the fields provided and press Finish. Creating a circle To create a circle: Touch the measure circle icon, and then touch the data entry icon.
Page 141: Creating An Arc
Creating Features Creating an arc To create an arc: Touch the measure circle icon, the measure arc icon and then touch the data entry icon. The data entry box will be displayed. Enter the feature data in the fields provided and press Finish. Creating a slot To create a slot: Touch the measure slot icon, and then touch the data entry icon.
Page 142: Creating A Rectangle
QC-300 Series User’s Guide Creating a rectangle To create a rectangle: Touch the measure slot icon, the measure rectangle icon and then touch the data entry icon. The data entry box will be displayed. Enter the feature data in the fields provided and press Finish.
Page 143: Chapter 7 Tolerancing
Chapter 7: Tolerancing Tolerances can easily be applied to position, size, orientation, form, runout and concentricity measure- ments using the tools found in the tolerance screens. CAUTION Discrete point measuring machines estimate the size, position, orientation, and form of geometric features based on points probed. When parts are designed with critical tol- erances, be sure that you have probed sufficient points to calculate a reliable estimate.
Page 144 QC-300 Series User’s Guide This chapter includes the following tolerance information: Applying tolerances to features ................127 Selecting a feature ..................127 Displaying the tolerance screen ..............127 Selecting a tolerance type .................127 Selecting a specific tolerance ..............128 Entering nominal, limit or tolerance values ..........128 Omitting a tolerance category ..............129 Tolerance types ....................130 Bidirectional ....................130...
Page 145: Applying Tolerances To Features
Applying Tolerances to Features Applying tolerances to features Tolerances are applied to feature measurements using tolerance screens. The method of applying toler- ances to features is diagrammed below and is nearly identical for all tolerance types. In the following example, a true position tolerance is applied to a circle feature. Selecting a feature Touch the desired feature in the feature list to select it.
Page 146: Selecting A Specific Tolerance
QC-300 Series User’s Guide Selecting a specific tolerance Touch the Tolerance menu title and then select the specific tolerance from the drop-down menu. The true position tolerance is selected in this example. Entering nominal, limit or tolerance values In this example, the Nominal and Tol Dia (Tolerance diameter around the nominal position) values are entered by touching the desired data fields and entering a new values using the number keys.
Page 147: Omitting A Tolerance Category
Applying Tolerances to Features Omitting a tolerance category When a tolerance category is unnecessary, it can be omitted. To omit a category, select the Nominal data field, remove any data by repeatedly pressing the Cancel key and press the Enter key. In this example, the Diameter category is omitted.
Page 148: Tolerance Types
QC-300 Series User’s Guide Tolerance types As mentioned earlier, the method of applying tolerances to features is nearly identical for all tolerances. This section describes the tolerance screen for each tolerance type. The following tolerances can be ap- plied to feature measurements: • Bidirectional • True position • MMC • LMC • Runout • Roundness • Concentricity • Straightness • Parallelism • Perpendicularity • Angle • Width...
Page 149: Circles And Arcs
Tolerance Types Circles and arcs The tolerance screens for circles and arcs are identical, and are used to specify the acceptable deviation from nominal positions in the X and Y axes, and from the nominal diameter or radius. The bidirectional tolerance compares the measured location of the center point of the arc or circle to the nominal center point and compares the measured diameter or radius to the nominal.
Page 150: True Position
QC-300 Series User’s Guide True position True position tolerances can be applied to points, lines, circles and arcs. Points and lines The tolerance screens for points and lines are identical, and are used to specify the acceptable deviation from the nominal feature position. The true position tolerance compares the measured location of the center point to the nominal center point.
Page 151: Mmc/Lmc (Material Condition)
Tolerance Types MMC/LMC (Material condition) MMC and LMC tolerances can be applied to bosses or to bores, compare measured center locations to the nominal centers and compare measured diameters to nominal diameters. MMC and LMC tolerances can be applied to circles and arcs. MMC Circles and arcs The MMC tolerance screens for circles and arcs are identical, and are used to specify the maximum mate- rial that can exist within a bore or on the surface of a boss.
Page 152: Lmc Circles And Arcs
QC-300 Series User’s Guide LMC Circles and arcs The LMC tolerance screens for circles and arcs are identical, and are used to specify the minimum material that can exist within a bore or on the surface of a boss. LMC tolerances can generate position bonuses as a result of size tolerance surpluses.
Page 153: Runout
Tolerance Types Runout Runout tolerances can be applied to circles and arcs. The tolerance screens are identical, and are used to specify the acceptable deviation from a circle or arc around the center of the Reference feature axis. Enter the acceptable position deviation into the Tol Zone data field and then enter the number of the reference feature for the runout toler- ance into the Ref Feature data field.
Page 154: Parallelism
QC-300 Series User’s Guide Parallelism Parallelism tolerances can be applied to lines and are used to specify the acceptable deviation from a line perfectly parallel to a Reference feature. Enter the acceptable parallelism deviation into the Tol Zone data field, and then enter the number of the reference feature for the Parallelism tolerance into the Ref Feature data field.
Page 155: Width
Tolerance Types Width Width tolerances can be applied to distances and are used to specify the acceptable deviation from a nomi- nal length. The length can be specified as a vector length (L) or as separate X, Y and Z lengths. Enter the allowed width lim- its into the Limit data fields as +/- ranges or as absolute limits. Touch the Limit data fields to toggle between +/- ranges or ab- solute limits.
Page 156 QC-300 Series User’s Guide...
Page 157: Creating Programs
Chapter 8: Programming QC-300 programs are sequences of measurement activities performed on a part by the operator and stored by the system for playback later on other identical parts. Using the programming capabilities of the QC- 300 greatly increases productivity by compressing the many manual steps required to measure, tolerance and report part dimensions into a few semi-automated steps which are little more than operator responses to system prompts.
Page 158: Start Program Recording
QC-300 Series User’s Guide Start program recording Touch the Program tab to display the programming tools. When no previous programs have been recorded, only the record icon will be shown. When other programs already exist, all the program tool icons will be shown.
Page 159: Enter A Program Title (Or User Message)
Creating a Program Enter a program title (or user message) The method used to enter a program title is also used to enter any text message that will be played back during program execution as a user prompt. To enter a program title: Touch the character and control keys on the text entry screen to enter a unique name for your new...
Page 160: Measure A Skew And Create A Datum
QC-300 Series User’s Guide Measure a skew and create a datum Skew and datum operations are described in Chapter 6: Measuring. In this example, the bottom edge of the part is measured for skew compensation, the left edge is measured and the intersection point of the bot- tom and left edges is zeroed in the X, Y and Z axes and used as a datum for subsequent measurements.
Page 161: Apply A Tolerance
Creating a Program Then measure the largest hole in the QC Quickie slide. Details of performing circle measurements are described in Chapter 6: Mea- suring. Measurement data is displayed Apply a tolerance Tolerance operations are described in Chapter 7: Tolerancing. In this example, a true position tolerance is applied to the hole feature measured in the last step.
Page 162: Stop The Program Recording
QC-300 Series User’s Guide Stop the program recording Touch the Program tab to display the programming icons, and then touch the Stop icon to stop recording the program. The program title will be shown. the new program name will be Touch the Program tab...
Page 163: Specifying Part Fixturing (Cnc Option)
Creating a Program Specifying part fixturing (CNC option) Default part fixturing is configured in the CNC General setup screen by OEMs and Distributors for CNC systems. In most cases, part fixturing will remain unchanged. However, if fixturing requirements change, the part fixture configuration can also be changed to insure that subsequent program runs will include the correct measurement reference and datum.
Page 164: Editing Programs
QC-300 Series User’s Guide Editing Programs Programs can be edited to: • Revise units of measure • Revise tolerances • Revise user prompt messages • Append new steps to the end of the list of program steps Editing existing steps The process for editing existing steps is diagrammed below and is identical for all types of revisions. A message will be displayed at the beginning of an edit session warn- ing the user that the current feature list will be cleared and asking for confirmation before continuing.
Page 165 Editing Programs Touch the first or second step to display the desired settings fields and perform the required edits. Select the first step to edit units, fixturing, loop count or probing characteristics. Select the second step to edit magnification. The first two steps contain program settings Press the Finish key to save the changes and return to the program list.
Page 166: Editing Tolerances
QC-300 Series User’s Guide Editing tolerances Tolerances are contained in the feature measurement data associated with each feature in the feature list. Tolerances are initially assigned in tolerance screens when features are measured, as described in Chapter 7: Tolerancing. To edit tolerances: Touch the Program tab, the program title and the Edit icon.
Page 167: Editing User Prompt Messages
Editing Programs Editing user prompt messages To revise message text: Touch the Program tab, the program title and the Edit icon. Program steps will be displayed. Touch the Program tab... select a program and touch the Edit icon, settings will be displayed Touch the desired message icon and then touch the message text to display the text entry screen.
Page 168: Inserting Or Appending New Program Steps
QC-300 Series User’s Guide Inserting or appending new program steps To insert new steps into an existing program: Touch the Program tab, the program title and the Edit icon. Program steps will be displayed. Touch the Program tab... select a program and touch the Edit icon, settings will be displayed To insert steps, touch the program step before the insertion point for the new program steps.
Page 169 Editing Programs Touch the Program tab and the Stop icon. The new program steps will be displayed at the insertion point. Touch the Program tab... and then press the Stop icon to complete the addition of new steps Press the Finish key to save the changes and return to the program list.
Page 170: Running Programs
QC-300 Series User’s Guide Running programs The operator will position the part and collect measurement data points in response to program text and the green run-time arrow displayed on the screen. When the program has successfully completed executing, feature data will be shown in the feature list and the screen will leave the program execution mode and display the current position.
Page 171: Saving And Retrieving Programs
Running, Saving and Retrieving Programs Saving and retrieving programs Programs can be saved by themselves, or included in settings files and saved as part of the complete col- lection of all QC-300 system settings. In either case, the files can be retrieved later and used again. Refer to Chapter 10: Setup for details regarding saving system settings files.
Page 172 QC-300 Series User’s Guide Select the desired program and touch the Copy icon. The selected program will be copied to the local drive (C:). Touch the drive letter again to shown the contents of the local drive. Select a program... touch the Copy icon...
Page 173: Deleting Programs
Deleting Programs Deleting programs Programs are deleted by selecting the desired program and pressing the Cancel key. You will be asked to confirm your intention to delete the program. To delete a program: Touch the Program tab to display the program screen, touch a program title to select the desired program and press the Cancel key to delete the program.
Page 174 QC-300 Series User’s Guide...
Page 175: Connecting To A Computer
Chapter 9: Communication The QC-300 can communicate with a computer over the RS232 serial port and with printers over the USB port. Connecting to a computer Verify that the QC-300 and computer power are off. Connect a computer COM port to the QC-300 RS-232 serial port using a standard straight-through serial cable (Metronics part number 11B12176).
Page 176: Sending Data To A Computer
QC-300 Series User’s Guide Sending data to a computer Measurement data can be sent to a computer over the RS-232 serial port in the following formats: • None No data will be sent to the computer • Select User will be prompted to select the data that will be sent • Report A standard report of all feature data or a tolerance report of only features that have tolerances applied will be sent To send data to a computer: Touch the question mark Icon and display the setup menu, then touch Print to display the Print setup...
Page 177: Connecting A Printer
Printing Reports Connecting a printer The QC-300 supports certain USB printers. The printer must be approved for use by Metronics. The cur- rent printer is shown in the Print setup screen discussed in Chapter 10: Setup. Verify that the QC-300 and printer power are off. Con- nect the USB printer to the USB Type A port on the side of the enclosure.
Page 178: Printing A Report
QC-300 Series User’s Guide Printing a report Feature measurement data or records of QC-300 system settings can be printed at the USB port. Printing feature measurement data Feature measurement data can be printed in the following formats: • None No data will be printed • Select User will be prompted to select the data that will be printed • Report A standard report of all feature data or a tolerance report of only features that have tolerances applied will be printed...
Page 179: Printing Qc-300 System Settings
Printing Reports Printing QC-300 system settings To print a report of the QC-300 setup parameters: Touch the question mark Icon and display the setup menu. Press the Print key.
Page 180: Rs232 Connector Pin Designations
QC-300 Series User’s Guide RS232 connector pin designations Pin No. Description Direction Data in Input Data out Output Signal ground Reference Power on Output (always high) ASCII Code table...
Page 181 Chapter 10: Setup The operating parameters of the QC-300 must be configured prior to using the system for the first time, and any time part measurement, reporting or communication requirements change. Day to day use of the QC-300 does not require reconfiguration of the system settings. The Setup Menu ....................164 Accessing and using the Setup Menu ..............164 Essential setup requirements ................168...
Page 182: The Setup Menu
QC-300 Series User’s Guide The Setup Menu All setup operating parameters of the QC-300 are con- figured using screens accessed from the setup menu. Touching setup menu items on the left side of the setup screen display the corresponding setup parameter data fields and choice fields on the right side of the screen.
Page 183: Entering The Supervisor Password
Accessing and Using the Setup Menu Entering the supervisor password The supervisor password must be entered into the Supervisor setup screen to access most setup fields. To enter the supervisor password: Access the setup menu as described on the previous page. Touch the Supervisor menu item, enter the supervisor password using the number keys on the front...
Page 184: Selecting Items From The Setup Menu
QC-300 Series User’s Guide Selecting items from the Setup Menu Setup menu items are selected by touching the item on the left side of the screen. Menu items will become highlighted to indicate that the selection is complete and the correspond- ing setup parameter choice and data fields will be shown on the right side of the screen.
Page 185: Storing A Parameter And Advancing To The Next Step
Accessing and Using the Setup Menu Storing a parameter and advancing to the next step Press the Enter key to store the highlighted value and advance to the next setup field. Leaving the setup menu Press the Finish key to conclude the setup session.
Page 186: Minimum Setup Requirements
QC-300 Series User’s Guide Minimum setup requirements In most cases, the QC-300 will be provided by a Metronics distributor or an OEM and will be configured and ready to use. Setup by the end-user will be Page 169 unnecessary. However, if some setup is required, a minimum sequence of steps should be performed in the order shown by the block diagram.
Page 187: Setup Screen Descriptions
Minimum Setup Requirements and Language Screen Setup screen descriptions The setup screen descriptions are presented in the order of their appearance in the setup menu. However, the first time the QC-300 is configured, the order of setup screen use should follow the es sential setup requirements diagram, and then continue in the order that best satisfies the ap plication or the user’s prefer- ences.
Page 188: Supervisor Screen
QC-300 Series User’s Guide Supervisor screen The Supervisor screen contains fields for entering the supervisor password, choosing to keep privileges until the power is cycled and locking the setup menu so that setup parameters cannot be viewed. Button controls are also provided for saving system settings to, or loading setting from the USB port.
Page 189: Saving And Loading Settings
Supervisor Screen Saving and loading settings System settings can be saved to storage devices, or loaded from storage devices attached to the USB port by connecting the USB storage device and touching the Save Settings or Load Settings button.
Page 190: Encoders Screen
QC-300 Series User’s Guide Encoders screen The Encoders screen contains data and choice fields for specifying encoder resolution, units of measure, en- coder type, reference marks and other critical encoder parameters for each measurement axis. Selecting an axis to configure Selections are made by repeatedly touching the Axis choice field to cycle through all the available measure- ment axes.
Page 191: Selecting Reference Marks
Encoders Screen Selecting reference marks Selections are made by repeatedly touching the Reference marks choice field to cycle through all the avail- able encoder reference mark types. In this example, the reference mark choices (None, Manual, Single and Absolute) are cycled by repeatedly touching the Axis choice field.
Page 192: Setting A New Machine Zero Reference
QC-300 Series User’s Guide Setting a new machine zero reference A machine zero is established each time the QC-300 is powered. However, it might be necessary or con- venient to change the location of the machine zero position to a new “home” position for measurements. To set a new machine zero position: Select the Machine Zero Offset data field, move the stage to the desired new machine zero position and touch the Set button.
Page 193: Squareness Screen
Encoders and Squareness Screens Squareness screen The Squareness screen contains data and choice fields for calibrating the squareness of the measuring system. The calibration of stage squareness requires the use of a certified square artifact. To calibrate squareness: Place the square calibration artifact on the stage with one edge along the X-axis.
Page 194: Slec Screen
QC-300 Series User’s Guide SLEC screen The SLEC screen contains fields for enabling and con- figuring linear error correction (LEC) or segmented linear error correction (SLEC) for each encoder axis. LEC or SLEC, which is right for my application? Any channel input device can include slight nonlineari- ties over its measurement range. LEC compensates for nonlinearities by applying a single linear correction value to the entire range of measurement. SLEC compensates for nonlinearities by applying correction values to the individual non linear segments of the measurement range.
Page 195 SLEC Screen Make sure the Enabled choice field is toggled to Off, and erase any existing data in all the data fields using the methods described earlier in this chapter. Station 0 should be displayed with zeros in the Standard, Observed and MZ Offset fields when this step is com- plete.
Page 196: Slec (Segmented Linear Error Correction)
QC-300 Series User’s Guide SLEC (Segmented linear error correction) SLEC compensates for encoder non-linearities by applying correction values to individual nonlinear seg- ments. These SLEC correction values are created by the QC-300 system using data provided by the user in the SLEC Setup screen. The SLEC setup data provided by the user consists of Standard (certified) and Observed (measured) values of a standard, or standards that cover the entire range of axis motion. The SLEC measurements can divide the axis range of motion into up to 150 segments. The example diagrammed on the next page shows standard values compared to observed values for 6 segments.
Page 197 SLEC Screen Make sure the Enabled choice field is toggled to Off, and erase any existing data in all the data fields using the methods described earlier in this chapter. Sta- tion 0 should be displayed with zeros in the Standard, Observed and MZ Offset fields when this step is complete.
Page 198 QC-300 Series User’s Guide Enter the MZ Offset value noted earlier in step 2. Zero the DRO for the axis being calibrated at the part zero position of the standard and enter zeros into the Standard and Observed data fields for Station zero.
Page 199: Nlec Screen
NLEC Screen NLEC Screen The NLEC screen contains fields for enabling and configuring nonlinear error correction (NLEC) for the X and Y encoder axes. Nonlinear error correction minimizes or eliminates the small inaccuracies in the X-Y measurement plane due to encoder linearity, mounting and ma- chine-travel imperfections. Error correction coef- ficients are obtained by measuring a certified cali- bration grid.
Page 200: Calibrating From Features
QC-300 Series User’s Guide Nonlinear error correction calibration can be performed using one of three methods: • Calibrate from features obtained by measuring the calibration grid using the QC-300. • Edit existing QC-300 calibration values if calibration adjustments are required. • Import calibration values (NLEC text file) collected earlier by measuring the calibration grid using a QC-5000. The first two methods listed above can use artifact calibration files (.acf files) to specify certified artifact calibration grid values.
Page 201 NLEC Screen Exit the setup mode, measure the skew through the bottom grid points of the calibration grid and create a zero datum at the lower left point of the grid. Skew Zero datum Measure the grid values starting at the bottom left corner of the grid (X1, Y1) and proceed from left to right and from bottom to top.
Page 202: Calibrating Nlec By Adjusting Station Values
QC-300 Series User’s Guide Calibrating NLEC by adjusting station values The process of calibrating by adjusting sta- tion values is shown by this chart and de- scribed below. This process is generally used to adjust existing NLEC calibration data. 1 Make sure that NLEC is disabled (En- abled checkbox is cleared).
Page 203: Calibrating Nlec With Existing Nlec Correction Text File
NLEC Screen Measure only the grid values that need to be adjusted, starting at the bottom left corner of the grid (X1, Y1) and proceeding from left to right and from bottom to top. 6 Return to the NLEC setup screen. Touch the (Machine 0 Offset) Use Feature button to set the zero datum.
Page 204: Magnifications Screen
QC-300 Series User’s Guide Magnifications screen The magnifications screen contains fields and tools for adding and deleting magnifications, installing and calibrating optical edge detection, cross-calibrating crosshair and edge detector probes and performing par- centric calibrations. Adding magnifications To add a magnification, touch the New button. The next higher ID number and default button label will be added.
Page 205: Edge Calibrations For Routine Measurements
Magnifications Screen Edge calibrations for routine measurements Teaching the edge detector calibrates it to correctly recognize dark to light transitions (edges) on the com- parator screen. Perform a teach calibration after each startup or whenever the part or magnification level changes.
Page 206: Specifying An Active Edge Detection Zone For Program Playback
QC-300 Series User’s Guide Touch the Dist Cal button. You will be prompted to repeatedly place the edge detector probe over the standard parts edge and to press the Enter key. Follow the instructions provided in the upper left corner of the screen to complete the calibra- tion.
Page 207: Performing Parcentric Calibrations
Magnifications Screen will be entered into the Cross Cal Offset value fields automatically by the system during the calibration process. When the cross calibration is complete, use the crosshairs, and then the edge detector probe to measure the same circle and compare the measurement results to verify that the teach calibration was successful. Performing parcentric calibrations Parcentric calibration eliminates X and Y axis measurement offset errors that can occur when changing magnifications.
Page 208 QC-300 Series User’s Guide Select the next lower mag- nification. This is M2 in this example. Focus the circle artifact image at the new magnification. Measure the circle artifact at the new magnification, and enter the X and Y positions of the new circle feature shown in the DRO into the Par- centric Offset X and Y fields of the Magnification setup screen.
Page 209: Measure Screen
Measure Screen Measure screen The Measure screen contains fields for specifying the method of data point collection, specifying the mini- mum number of points required to measure different geometries, locking the reference frame, selecting dis- tance presentations and configuring point filtration. Annotation The annotation type defines the method of data point collection.
Page 210: Locking Features To Their Original Datums
QC-300 Series User’s Guide Locking features to their original datums Features can be locked to their original datums or can be referred to new datums as datums are created. In the following example illustrating locked and unlocked features, 6 features are measured using 2 datums. Measurement activity Datum 1 is created, then Feature 1 is measured, feature 2 is measured and feature 3 is measured...
Page 211: Enabling Point Filtration
Measure Screen Enabling point filtration Touch the Point Filtration choice field and toggle the choice to Yes to enable point filtration. Specifying a filtration error limit The quantization factor is the maximum acceptable error. For most measurements, a quantization factor of 3 microns or less can be applied.
Page 212: Crosshair Timeout Delay
QC-300 Series User’s Guide Crosshair timeout delay When the auto-enter crosshair probe is used, a point is automatically col- lected by the system each time the stage is moved to position the part under the crosshair. This automatic point entry is delayed until the stage has been motionless for a short time to ensure that the crosshair is located where the user intended.
Page 213: Display Screen
Display Screen Display screen The Display screen contains fields for configuring dis- play resolution and other LCD display parameters. Display resolution The display resolution fields are used to specify the res- olution of measurements shown on the DRO and other screens. Displayed numbers will be round ed as the dis- play resolution is decreased below that of the input.
Page 214: Default Units Of Linear Measure
QC-300 Series User’s Guide Default units of linear measure The Startup Units field is used to spec ify the default display of linear measurements when power is applied to the system. These display settings can be changed temporarily but will revert to the startup de faults when the power is cycled.
Page 215: Display Mode Switching
Display Screen Display mode switching The QC-300 provides two display modes for measurements, Single View and Dual View. In the Single View mode, the screen used for a measurement will be displayed again when the measurement is complete. In the Dual View mode, the last screen used for a measurement will be used again for the current mea- surement.
Page 216: Configuring The Extra Tab
QC-300 Series User’s Guide Configuring the Extra tab The Extra tab can be configured to contain controls for transmitting measurement data, controlling CNC functions, performing datum operations and a variety of other functions. Up to 99 Extra tabs can be configured to be available on each system. Repeatedly touching the Extra tab cycles through the available configurations.
Page 217: Extra Tab Functions
Display Screen Extra tab functions Space menu insert The space insert are included in the Ex- tra tab to separate control functions into groups on the tab. Extra tab divided by space into data and CNC groups Divider line menu insert The divider line insert are included in the Extra tab to separate control functions into groups on the tab without using a space insert.
Page 218: Stop Motion
QC-300 Series User’s Guide performed along the part’s X-axis, when part following is enabled, subsequent X-axis motion will follow the part skew, not the machine coordinate’s X-axis. When the user touches the Part following function, part following is toggled on or off. Stop motion The Stop motion function is included in the Extra tab of systems with the CNC option to stop all stage motion.
Page 219: Header Screen
Display and Header Screens Header screen The Header screen contains fields for formatting text headers for printed and exported reports. Creating report headers Two columns of three text headers can be created for the top left and right sides of reports, as shown in this example.
Page 220: Print Screen
QC-300 Series User’s Guide Print screen The Print screen contains fields for formatting printed reports and RS232 data streams of feature measurement data. Specifying a data type The Print button initiates the transfer of data to the USB port for printing, or to the RS232 serial port for com- munication with a computer.
Page 221: Specifying Column Separators
Print Screen Specifying column separators Columns of feature measurement data in printed reports and in transmitted data can be contiguous or can be separated by dividing lines, commas or Tabs. Touch the Column Separator choice field to cycle through the choices. RS232 control characters Control characters can be added to the beginning and end of line and form data streams to accommodate the requirements...
Page 222: Ports Screen
QC-300 Series User’s Guide Ports screen The ports screen contains fields for configuring the RS-232 serial communication port. The RS-232 com- munication port is used to send data to computers. RS- 232 port settings can be changed to match those of the receiving system.
Page 223: Clock Screen
Ports and Clock Screens Clock screen The clock screen contains fields for setting the date and time included in data transmissions and printed on reports. To change a date or time value, touch the desired choice or data field and enter the desired value. Touch and enter numbers Touch and cycle through choices...
Page 224: Sound Screen
QC-300 Series User’s Guide Sound screen A sound can be generated by the system to call atten- tion to point entries. The sound is generated each time the Enter button is pressed to enter a point as part of a measurement.
Page 225: Miscellaneous Screen
Sound and Miscellaneous Screens Miscellaneous screen The Miscellaneous screen contains fields for calibrating and configuring the LCD touchscreen. Return to DRO threshold The display automatically switches to display current position on the DRO from the View, Tolerance or DRO screens when the stage movement reaches or exceeds the DRO threshold value.
Page 226: Calibrating The Touchscreen
QC-300 Series User’s Guide Calibrating the touchscreen The touch-pressure of the touchscreen should be calibrated as part of the initial setup and when a new operator begins using the system. To calibrate the touchscreen: Confirm that the number of calibration rows and columns provide adequate touch-points to satisfy typical use requirements.
Page 227: Touch Zone Size
Miscellaneous Screen Touch zone size The size of the touch zone can be changed to accommodate different users. When the touch zone size value is zero, the touch zone extends only to the limits of the choice or data field. As the touch zone value is increased, the touch zone is increased beyond the perimeter of the field on all sides.
Page 228: Buttons Screen
QC-300 Series User’s Guide Buttons screen The Buttons screen contains fields for assigning fre- quently used QC-300 functions to joystick and foot switch buttons. Using preassigned buttons saves the time normally required to navigate menus. Each of the joystick and foot switch buttons can be assigned to functions shown in the choice fields.
Page 229: Selecting Button Responses
Buttons Screen Selecting button responses All button responses are either momentary or toggle. Momentary functions are level-based and are ac- tive only while the button is pressed and held. Toggle functions are activated when the button is pressed and released, and deactivated when the button is pressed and released again. Configure any of the button responses as momentary (level-based) by checking the button’s Level box. Clear the Level box to configure the button response as toggle.
Page 230: Joystick Screen
QC-300 Series User’s Guide Joystick screen The Joystick screen contains fields calibrating and configuring overall joystick motion. Enabling joystick motion Check an axis Enable box to enable joystick motion, or clear the box to disable joy- stick motion on that axis. Joystick Specifying a joystick deadband A deadband area of joystick inactivity is specified around the zero position of each axis to eliminate er-...
Page 231: Specifying Linear And Nonlinear Joystick Motion Control
Joystick Screen Specifying linear and nonlinear joystick motion control The axis velocity controlled by the joystick is changed from linear to varying degrees of exponential by entering values into the axis Expo% fields. Expo % values are entered from 0 (linear) to 100 (very expo- nential.
Page 232: Qc-300 Series User's Guide
QC-300 Series User’s Guide Digital positioner screen The Digital positioner screen contains fields for cali- brating and configuring digital positioner motion. Enabling digital positioner motion Check an axis Enable box to enable digital positioner motion, or clear the box to disable digital positioner motion on that axis.
Page 233: Probe Path Screen
Digital Positioner and Probe Path Screens Probe path screen CNC probing parameters are specified in the Probe path screen to control CNC probing and non-probing velocities as well as data point approach and search distances during program execution. Probing and non-probing velocities Transitions from one target edge to the next are made at relatively high non-probing velocities.
Page 234: Approach And Search Distances
QC-300 Series User’s Guide Approach and search distances The probing velocity is maintained over the approach distance to the target data point. The approach distance should be large enough to allow the system to reach a constant probing velocity, and small enough to facilitate rapid measurement.
Page 235: Edge Values Screen
Probe Path and Edge Values Screen Edge values screen The optical probe input from the edge detection cir- cuit is debounced by time and distance to eliminate false edge indications due to noise and vibration. The Debounce time and distance must be non-zero values. Time is entered in seconds and distance is entered in the current unit of measure.
Page 236: Hardware Screen
QC-300 Series User’s Guide Hardware screen The Hardware screen contains fields that describe the software and hardware configuration of your system. This information will be essential to Metronics tech- nical support personnel if your system is upgraded or repaired.
Page 237: Chapter 11 Problem Solving
Chapter 11: Problem Solving The QC-300 is based on years of experience manufacturing the Metronics QC-100, QC-200 and QC-5000 products. Years of continuous improvement have resulted in extremely reliable operation and few, if any problems. Problems experienced with the operation of the QC-300 are likely to be the result of printer or cable incompatibilities, instrument configuration or setup errors, encoder incompatibilities or malfunctions or setup and calibration issues.
Page 238: Symptoms, Probable Causes And Solutions
QC-300 Series User’s Guide Symptoms, probable causes and solutions Some common symptoms of problems are listed in the following pages with probable causes and possible solutions. No image is visible on the LCD screen Probable cause 1: Power is not applied to the QC-300 Possible solutions: Activate the main power source.
Page 239 Symptoms, Probable Causes & Solutions Probable cause 4: The wrong encoder is connected to the axis Possible solutions: Connect the axis encoder specified in the Encoders setup screen. Confirm that the each encoder is connected to the correct axis input. Probable cause 5: The wrong in/mm unit of measure is specified Possible solution:...
Page 240: Reports Are Not Printed Or Are Incomplete
QC-300 Series User’s Guide Reports are not printed or are incomplete Probable cause 1: The channel input device is not connected or is malfunctioning Possible solution: The printer is not supported by the QC-300. Probable cause 2: The USB cable is not firmly connected or is damaged Possible solution: Connect or replace the printer cable.
Page 241: Optical Edge Detection Is Not Working Properly
Symptoms, Probable Causes & Solutions Optical edge detection is not working properly Probable cause 1: Reference or sensor light levels are incorrect Possible solution: Refer to Evaluating optical light levels in Chapter 10: Setup for instructions regarding light levels, and then reorient, repair or replace light sources or optical cables. Probable cause 2: Edge detection is not calibrated: Possible solution:...
Page 242: Data Cannot Be Transmitted To A Computer
QC-300 Series User’s Guide Data cannot be transmitted to a computer Probable cause 1: The wrong serial cable (or no cable) is connected between the computer and the QC-300 Possible solution: Connect the computer to the QC-300 using an RS-232 serial cable that does not include crossed transmit and receive wires.
Page 243: Chapter 12 Reference Material
Chapter 12: Reference Material This chapter contains technical information regarding: • QC-300 product specifications • Footswitch wiring • RS-232 connector wiring • Tolerances Product specifications Electrical Input Voltage Range: 85 VAC to 264 VAC. 1.0 Amp maximum (Auto switching) Fuse: 1.6 Amp 250 VAC Slow Blow 5 x 20 mm Input Frequency: 43 Hz to 63 Hz Environmental...
Page 244: Footswitch Wiring
QC-300 Series User’s Guide Footswitch wiring The optional foot switch is connected to the RJ-45 connector on the left side of the QC-300. The wiring of the footswitch is sometimes dupli- cated by other external switching devices to fa- Footswitch and cilitate remote operation in conjunction with other keypad connector devices in a larger semi-automated system.
Page 245: Rs-232 Connector Wiring
Connector wiring RS-232 connector wiring The RS-232 wiring is shown by the table below. Pin No. Description Direction Data in Input Data out Output Signal ground Reference Power on Output (always high) RS-232 connector...
Page 246: Tolerance Definitions
QC-300 Series User’s Guide Tolerances The following information is supplemental to the tolerance discussions provided earlier in Chapter 7: Tolerancing. Concentricity tolerance The mathematical definition of concentricity is explained in detail in the ASME Y14.5M-1994 standard and involves “the midpoints of opposing elements” in the determination of actual concentricity. This is not practical in a discrete point measuring system, so the QC-300 uses the center of the feature (determined by the best fit) to estimate the concentricity.
Page 247 Chapter 13: Options Available options for the QC-300 are listed and shown here with Metronics part numbers: • Foot switch for remote operation • RS-232 cable without crossed cable wiring for communication with computers • Arm-mounting bracket and bracket adapter for mounting the QC-300 on vertical surfaces (must be ordered together) • Taltech WinWedge©...
Page 248 QC-300 Series User’s Guide...
Page 249 Index 1 Axis error messages 174 INDEX Backlighting 220 Backup battery 164 Backward/forward annotation 61 Symbols Backward annotation 61, 191 .acf files 181 Baud rate 204 2-Wire 6 Best-fit algorithm 65, 125 2-Wire to 3-wire adapters 6 Bidirectional tolerance 130 Bits 3-Wire 6 3-Wire adapters 6 Data 157 Stop 157...
Page 250 Index 2 QC-300 Series User’s Guide Circle Creating features 121 Constructions 115 Creating programs 139 Maximum inscribed 228 Cross calibration 47 Measuring a 35 Crosshair and edge probe offset 188 Probing 65 Crosshair delay restart distance 194 Minimum superscribed 228 Crosshair probes 1, 43, 44 50 Circles 60, 65, 131 Crosshairs and optical edge detection 61...
Page 251 Index 3 QC-300 Series User’s Guide Distance), iso (least radial 228 Environmental specifications 225 Distance EOC delay 204 Approach 216 EOL delay 204 Calibration 47 Error Constructions 98 Correction 47 Debounce 217 Messages 174 Search 216 Essential setup requirements 168 Distances 60, 68, 192 Export results 29 Distributor, contacting 224 Extra tab 16, 199...
Page 252 Index 4 QC-300 Series User’s Guide LEC (linear error correction) 176 LEC or SLEC, which is right for me? 176 Getting help from your distributor 224 Leveling the part (optional) 53 Grid, NLEC 181, 184 Lighting 46 Light levels 46, 188 Lightning 7 Limit, filtration error 193 Hard stop 173 Limiting access to program functions 170 Hardware setup screen 224 Line constructions 79 Headers, report 201 Lines 60, 63, 130, 132 Help 224 List, feature 21 Here, goto 15 LMC tolerances 133 Hiding setup parameters 170 Loading settings 171...
Page 253 Index 5 QC-300 Series User’s Guide MMC and LMC tolerances 133 MMCcircles and arcs 133 Page, lines per 202 Mode, edit 15 Parallelism tolerances 136 Motion Parallel port configuration 222 Calibrating the joystick range of 213 Parameter choices 166 Digital positioner 214 Parcentric calibrations 189 Joystick 212 Parity 157, 204 Stop 19, 200...
Page 254 Index 6 QC-300 Series User’s Guide Printer 8, 159 Printer QC-300 USB 203 Mounting the 229 Format strings 159 Version information 224 Probe QC Quickie slide 29 Crosshair 50 Quit 20 Edge detection 48 Screen 43 Select a new 30 Offset 188 Radix for numeric displays 196 Preparing to use 46...
Page 255 Index 7 QC-300 Series User’s Guide RS-232 Sending data to a computer 26, 158 Cable 229 Sensor cable 9 Connector wiring 162 227 Separators, column 203 Port settings 224 Serial cable 224 Serial port 3, 8, 157, 158 Serial port 158 Runout tolerances 135 Settings, saving and loading 171 Setup 24, 26, 163...
Page 256 Index 8 QC-300 Series User’s Guide Touchscreen Calibration rows and columns 207 Tab, extra 15, 16, 19, 198 Cursor 208 Tab, measure 14 Repeat delay 208 Tab, program 15 Zone size 209 Tabs, multiple extra 19 Transients 7 Taltech winwedge© 229 Troubleshooting list 219, 224 Teach, edge 47 True position tolerance 132...
Page 257 734 904 · 00 · A · 02 · 2/2010...
