Simrad PI50
Three Depth versions are available. These are set up for maximum depth 300 m,
600 m or 1000 m. The depth range is fixed by the factory, and can not be changed
in the PI Configurator utility.
5 Observe that an error message appears if you try to add too many sensors to the
Selected Sensors
The PI50 can handle maximum six sensors. Remember that dual sensors each seize
two sensor communication channels.
6 In the
Selected Sensors
7 Click one of the [▲] or [▼] buttons to move the sensor up or down on the list in
the
Selected Sensors
The order in this list also controls the order in which the sensors are presented in the
Sensor Configuration
in the PI50 display presentation.
→ How to control the order of the sensor views on page 70
8 In the
Sensor Configuration
a Label ID
b Label Name
c Update Rate for each of the two sensors
d Sensor Value Name for each of the two sensors
e These names you enter are shown in the Sensor views.
→ PI Temperature/Depth sensor view on page 46
Channel Number
f
Offset for the depth sensor
g
The offset for the sensor is calculated automatically by means of the calibration
procedure. If you already know the offset value, you can enter it directly.
→ How to calibrate the depth sensors on page 93
Note
It is very important that the
for each sensor in the
programmed into the sensor. If these vital parameters do not match, you will not
receive information from the sensor.
9 If this is the only sensor you wish to set up, or the last sensor, click
settings and close the dialog.
Related topics
• PI Temperature/Depth sensor view on page 46
• PI Temperature/Depth trend view on page 60
• How to set up the PI Temperature/Depth sensor on page 83
• PI Temperature/Depth purpose and application on page 181
84
field.
field, click once on the sensor to select it.
field.
field, as well as the vertical order of the Sensor view rectangles
field, choose:
Channel number
dialog matches the corresponding parameters
Select Sensors
and parameters defined
Update Rate
to save the
Ok
