Page 1 Operator manual Simrad PI32 Catch monitoring system www.simrad.com M A X I M I Z I N G Y O U R P E R F O R M A N C E S E A...
Page 3 Simrad PI32 Catch monitoring system Operator manual Important notice Operation of the PI32 Catch monitoring system assumes that the communication between the Operator Unit and the sensors is fully functional. Ensure that the communication channels and update rates defined on the Operator Unit matches those of...
Page 4 The information contained in this document is subject to change without prior notice. Simrad AS shall not be liable for errors contained herein, or for incidental or consequential damages in connection with the furnishing, performance, or use of this document.
Page 5 This section provides a general introduction to the PI32 Catch monitoring system and the units in use. Refer to page 2. Getting started This section provides general guidelines to help you get started with the PI32 Catch monitoring system. Refer to page 8. Applications This section gives an overview of the various applications that the PI32 can offer.
Page 6 Simrad PI32 Sensor test procedures This section provides simple test procedure you can use to verify the the sensors are working properly. Refer to page 223. Technical specifications This section provides the basic technical specifications. Refer to page 243. 857-164636 / Rev.A...
Page 7: Table Of Contents
Operator manual INTRODUCTION ..........SYSTEM DESCRIPTION .
Page 8 Simrad PI32 How to set up a Twin Spread sensor for twin trawl applications ..How to access graphic display parameters .....
Page 9 Operator manual Factory presets ......... . Graphic setup .
Page 10 Simrad PI32 Sensors Use this table to write down the sensors you use on your PI32 Catch monitoring system. Sensor Serial Communication Update type number channel rate 857-164636 / Rev.A...
Page 11 Operator manual Sensors Use this table to write down the sensors you use on your PI32 Catch monitoring system. Sensor Serial Communication Update type number channel rate 857-164636 / Rev.A...
Page 12 Simrad PI32 VIII 857-164636 / Rev.A...
Page 13: Introduction
Introduction INTRODUCTION The Simrad PI32 is an integration of proven commercial fishing technologies which can dramatically increase the yield and effectiveness of purse/danish seining and bottom/pelagic trawling applications. By means of three underwater sensors mounted on the gear, this robust, maintenance-free catch monitoring system allows unparalleled control over fishing operations by providing continuous, centralised information on the vessel’s position, its...
Page 14: System Description
The system further comprises a number of small and robust sensors measuring the conditions on your fishing gear. The PI32 Catch monitoring system can work with three sensors simultanously. The sensors are powered by built-in rechargeable batteries. They are housed in titanium casings, and designed using advanced shock absorbing materials.
Page 15: System Diagram
System description System diagram (A) = Operator Unit (B) = PI charger (C) = Hydrophone (provides communication with the sensors) (D) = Optional echo sounder transducer. Several types are available. (E) = Sensors mounted on the net. Maximum three sensors may be used simultanously, and several types are available.
Page 16: Operator Unit
The PI32 electronics are sealed in the operator unit allowing the it to be flush or bracket mounted in the wheelhouse or at an exposed control station.
Page 17: Hull Mounted And Portable Hydrophones
Trawling: The hull mounted hydrophone for trawling operations has a 50 degrees horizontal beam and a 30degrees vertical beam to provide the PI32 with optimal reception from the sensors. This specific beam pattern is especially suited for trawling and the wide coverage area reduces the need for careful alignment.
Page 18: Sensor Overview
Simrad PI32 Sensor overview This chapter provides a very short description of each sensor. • Depth sensor - The Depth sensor provide information about the current depth as well as the descending or ascending rate related to the surface. • Catch sensor - The Catch sensor provides information about the amount of catch in the trawl.
Page 19: Battery Chargers
Battery chargers All sensors are power by internal batteries, and these need charging at regular intervals. The Simrad chargers have been designed to allow the sensors to be stored in charging positions whenever they are not used, and “overcharging” will not take place.
Page 20: Getting Started
This section contains an brief overview of the basic system operation. If you are a first time user, we recommend that you read through this chapter while operating the PI32 so that you can familiarize yourself with the buttons, menus and display presentations.
Page 21: How To Switch Power On And Off
Getting started How to switch power on and off Observe the following procedure to switch the PI32 on and off. Power on Press and hold the PWR button until the display is switched on. Observe that the start-up page appears.
Page 22: Defining Initial Presentation Pages
Defining initial presentation pages Observe the following procedure to set up the four display pages on the PI32. The presentations chosen are those commonly used, but using the guidelines in this procedure you can change the content of individual pages to suit your requirements.
Page 23 Several other display presentations are available, but you only have four different display pages to use. After some experience with the PI32 system, you will however soon find out which display presentations that are the most useful to you, and you can alter the setup accordingly.
Page 24: Introduction To The Main Menu
Simrad PI32 Introduction to the main menu The main menu is located across the top of the display. To open the menu, press the MENU button. Note that if it is left unactivated, the menu will disappear automatically after a few seconds.
Page 25: Introduction To The Keypad
Getting started Introduction to the keypad The keypad is used for direct user interface with the PI32 system, and allows you to control the functionality. Note that the majority of the buttons are mainly used only during echo sounder operations, and that some of them will only work when they are enabled by a specific function.
Page 26 GAIN: The two gain buttons are used to adjust the receiver gain on the echo sounder. PWR* (Power): This button is used to switch the PI32 system on and off. During operation, it is also used to adjust the display intensity and the background illumination of the buttons.
Page 27: Introducing The Sensors
Getting started Introducing the sensors The PI32 Catch monitoring can be used with a variety of sensors. All these sensors can be placed on your trawl or purse seine to monitor key parameters. On the PI32, you can use a maximum of three sensors simultanously.
Page 28 Simrad PI32 • Pelagic trawl: On a pelagic trawl, this sensor proves very useful when the trawl moves downwards. It will let you know immediately if the footrope touches bottom. • Purse seine: When you work with a purse seine, you need to know when the seine reaches the bottom.
Page 29 Getting started Depth: How deep can you go? When the sonar and echo sounder tell you how deep the school goes, it is good to know that you can place your fishing gear at the same depth. And even better, you can monitor and hold the desired depth.
Page 30 Simrad PI32 Rip: Check for damages! The Rip sensor is identical to the Catch sensor, and can thus be regarded as a application for the Catch sensor. Place the sensor on the trawl belly behind the footrope, and use it to detect if the trawl is torn or in any other ways damaged by rocks or other roughness on the bottom.
Page 31 Getting started The water temperature is an important parameter. Fish and bait are temperature sensitive, and they are normally found within specific temperature zones for feeding and spawning. However, the temperature layers in the water are changing constantly, and for this reason the temperature must be monitored constantly.
Page 32: Application Examples
Simrad PI32 APPLICATION EXAMPLES The Simrad PI32 system is designed to fulfill all your requirements within a range of specific applications. This chapter provides a few examples on how the various sensors can be placed on your fishing gear. It also provides a brief description of the echo sounder and graphic display functionality.
Page 33: Purse Seine
Applications Purse seine When used for purse seining, the PI32 system must have one or more of the following sensors attached to the net: Depth sensor, Bottom Contact sensor and Temperature sensor. The system is designed to be used with up to three sensors, optimally two Depth sensors and one Temperature or Bottom Contact sensor.
Page 34: Danish Seine
Simrad PI32 Danish seine When used for Danish seining the PI32 system needs up to three of the following sensors attached to the net: Depth and Bottom Contact. The system is designed to be used with up to three sensors.
Page 35: Bottom Trawl
Applications Bottom trawl When used for bottom trawling, the PI32 system will give you all necessary information about the trawl status. You should have minimum three of the following sensors attached to the net: Depth sensors(s), Bottom Contact sensor, Rip sensor and Catch sensors(s).
Page 36: Pelagic Trawl
Simrad PI32 Pelagic trawl When used for pelagic trawling the PI32 system must have one or more of the following sensors attached to the net: Depth sensor(s), Bottom Contact sensor, Temperature sensor, Rip sensor and Catch sensor(s). The system is designed to be used with up to three sensors. We recommend that you use a Catch sensor, a Depth sensor behind the headrope, and a Spread sensor.
Page 37: Echo Sounder
Applications Echo sounder The built-in echo sounder will provide information about depth, bottom contours and the presence of fish below the vessel. The echo sounder can use three frequencies; 38 kHz, 50 kHz and 200 kHz. Two frequencies can be operated simultanously. The following operational modes are available •...
Page 38: Graphic Display
Simrad PI32 Graphic display By means of the built-in echo sounder and the information provided by the analogue sensors, you can set up a graphic display to give you a total overview of the underwater situation. The graphic display presents the echogram at the bottom of the screen while the numerical sensor presentations are listed at the top of the screen.
Page 39: Display Presentations
Display modes DISPLAY PRESENTATIONS The PI32 supports a range of display presentations. These are the information elements that you can choose to see on each page. Topics → Numeric display, page 28 → Graphic display, page 35 → Surface temperature, page 37 →...
Page 40: Numeric Display
Simrad PI32 Numeric display The numeric display provides vital sensor data in large, easy to read digits and symbols. In the following, all sensor presentations are explained in detail. This illustration shows a typical twin display setup with the numeric presentation from six sensors on the left side and an echo sounder presentation on the right hand side.
Page 41 The Bottom Contact sensor presentation is shown below. (A) The character and the number identifies the type of sensor, and which identification number the sensor has on the PI32 system. In this example, B4 means that it is a bottom contact sensor, and that it is sensor no.4.
Page 42 (A) The character and the number identifies the type of sensor, and which identification number the sensor has on the PI32 system. In this example, C3 means that it is a catch sensor, and that it is sensor no.3.
Page 43 The Depth sensor presentation is shown below. (A) The character and the number identifies the type of sensor, and which identification number the sensor has on the PI32 system. In this example, D1 means that it is a depth sensor, and that it is sensor no.1.
Page 44 The Height sensor presentation is shown below. (A) The character and the number identifies the type of sensor, and which identification number the sensor has on the PI32 system. In this example, H1 means that it is a height sensor, and that it is sensor no.1.
Page 45 The Spread sensor presentation is shown below. (A) The character and the number identifies the type of sensor, and which identification number the sensor has on the PI32 system. In this example, S3 means that it is a spread sensor, and that it is sensor no.3.
Page 46 The temperature sensor presentation is shown below. (A) The character and the number identifies the type of sensor, and which identification number the sensor has on the PI32 system. In this example, T2 means that it is a temperature sensor, and that it is sensor no.2.
Page 47: Graphic Display
Display modes Graphic display The graphic display provided by the PI32 offers an accurate echo sounder combined with numeric readouts from the net sensors. Note that some of the information provided by the graphic presentation assumes that you have the relevant sensors connected to your PI32 system.
Page 48 To change presentation parameters The presentation is controlled by the parameters defined in the PI32 setup. To change these parameters, press the ENT button to open the Graphic setup page. To change echo sounder parameters, press the MENU button to open the main menu, and select Echo sounder setup on the Echo menu.
Page 49: Surface Temperature
Fishery menu. To have this information available, you must have the relevant temperature feeler connected to your PI32 system. A suitable feeler is integrated with several Simrad echo sounder transducers, or it may be connected as a separate peripheral.
Page 50: Status Display
The sensor has not yet been triggered. (D) Information lines 1 and 2: The top line provides the following information: • The status of the MP (MultiPath) filter • The current software version of the PI32. 857-164636 / Rev.A...
Page 51 Display modes The second lines shows: • The current AGC status (Automatic Gain Control) • The status off the hydrophone cable. A yellow circle means that the cable is serviceable. A black circle means that it has broken, while a red circle indicates a short circuit. •...
Page 52: Echo Sounder Display
Simrad PI32 Echo sounder display The PI32 offers an accurate echo sounder with a colour display. The echo sounder can operate on 38, 50 or 200 kHz, and with two frequencies simultanously. In order to enjoy the echo sounder functionality, you must have one or two echo sounder transducers installed.
Page 53 Echo menu. Bottom expansion The PI32 provides a Bottom expansion function. When enabled the vertical area close to the seabed is expanded. The resulting presentation will not show the depth variations, as the bottom will appear flat.
Page 54 Simrad PI32 VRM expansion The PI32 provides an VRM expansion function. When enabled the vertical area on both sides on a vertical range marker (VRM) is expanded. The resulting echo sounder presentation is thus split in two with the lower half of the screen providing the expanded view.
Page 55: Navigation Display
Display modes Navigation display The navigation display provided by the PI32 offers all key information related to waypoint navigation. Note that the information provided by this presentation assumes that you have the relevant sensor (GPS) connected to your PI32 system.
Page 56: Position Display
Simrad PI32 Position display The Position display provided by the PI32 offers all key information related to safe navigation on one display presentation. Note that the information provided by the Position display assumes that you have the relevant sensors (GSP and temperature feeler) connected to your PI32 system.
Page 57: Operational Procedures
Operational procedures OPERATIONAL PROCEDURES Overview This chapter will provide you with basic procedures in order to help you set up the most common functions and parameters in the PI32. Sensor procedures Echo sounder procedures → → How to show or hide the graphic...
Page 58: How To Define Sensor Presentation
Simrad PI32 How to define sensor presentation The information from the various sensors are provided by the Numerical display, where each sensor is presented in its own rectangular data winsow. How to show or hide the graphic alarm Ensure that you have a Numeric display presentation in your active window.
Page 59 Operational procedures On the Setup menu, select Display colour. Observe the first palette page appear. It contains fixed colours, which can not be altered. Press the + button repeatedly until you reach a custom page. By means of the circular Selector pad and the + and - buttons, select the requested colour(s).
Page 60: How To Set Up The Sensors
Simrad PI32 How to set up the sensors The very first time you switch on the PI32, you will need to set up the sensor configuration. This will also be required if you perform a “master reset” on the PI32, and then reload the manufacturer’s default settings.
Page 61 MUST communicate on three different channels. • Other vessels near your use the same PI32 system (or a similar), and they have one or more of their sensors set up to the same communication channels as you have. This will create interference, as you will “read”...
Page 62 • A high update rate will give you frequent information updates, but the battery will run out faster. All sensors are provided from Simrad with a default update rate setting. In some cases you may find that this update rate does not suit your operational needs.
Page 63: How To Mount The Sensors On The Net
Operational procedures How to mount the sensors on the net Once the sensor has been coded correctly, you must mount it on the net. The mounting instructions for each sensor is provided in the Sensors chapter, and the same information can also be found on the Quick Reference Guide for each sensor.
Page 64: How To Use The Sensors
Once the sensors have been coded and installed on the net, they will automatically be switched on once they are submerged into water. The PI32 will then automatically retreive information from them, and provided that you have chosen the correct display presentation, the information will be provided to you.
Page 65: How To Replace The Sacrificial Water Switch
Insert the screw, mount firmly, but not too hard. Use maximum torque 1.5 NM A pack with ten screws and a tube of Aqua Shield can be ordered from Simrad as a spare parts kit. Aqua Shield is manufactured by D.A.Stuart, Warrenville, Illinois, USA (www.d-a-stuart.com).
Page 66: How To Test The Sensors
Simrad PI32 How to test the sensors By using the PI Configurator, you can test the operational status of each sensor. Test procedures for all the sensors have been provided in a separate chapter in this manual. Note that PI and PS sensors are tested using the same procedures.
Page 67: How To Calibrate The Depth Sensor
On the PI32, observe the numerical presentation of the sensor, and allow the reading to stabilize itself. On the PI32, press the MENU button to open the Main menu. Open the Setup menu, and select Sensor alarm/calibration.
Page 68: How To Define Sensor Offsets
If you have performed a Depth sensor calibration, you will see than an offset value may already be present. This value has been provided by the calibration routine. On the PI32, press the MENU button to open the main menu. Open the Setup menu, and select Sensor alarm/calibration.
Page 69: How To Set Up A Twin Spread Sensor For Twin Trawl Applications
How to set up a Twin Spread sensor for twin trawl applications By means of the Twin Spread sensor, you can set up your PI32 to monitor the openings on a twin trawl. Apart from the Twin Spread sensor, you will also need two Remote sensors.
Page 70 (F) = Forward (1) = Distance between port trawl door and centre clump, measured direcly by the Twin Spread sensor. (2) = Distance between the centre clump and the starboard trawl door, must be calculated by the PI32 system. 857-164636 / Rev.A...
Page 71 Operational procedures Sensor setup Observe the procedure below to set up a Twin Spread configuration with its default settings. In this procedure, sensors 1 and 2 are used, and no other sensors are shown. Due to the fact that the Twin Spread sensor occupy two communication channels, the setup program requires that it is configured as if it was two separate sensors, but not necessarily sensors 1 and 2.
Page 72 Spread 2 will measure the distance from the port trawl door to the starboard trawl door. Readout adjustments It is necessary to set certain parameters in order to have the PI32 to calculate the distance from the centre clump to the starboard trawl door.
Page 73 Operational procedures • Numeric display: Rectangle S1 shows the distance between the port trawl door and the centre clump. Rectangle S2 shows the distance between the port trawl door and the starboard trawl door. • Additional information: The information bar directly below the numeric rectangles displays the abbreviation TS and a value.
Page 74: How To Access Graphic Display Parameters
Simrad PI32 How to access graphic display parameters The various parameters defining the Graphic display presentation are controlled from the following dialogues: • Graphic setup • Numeric setup • Trawl info How to use the most common parameters are explained in separate procedures.
Page 75: How To View Echo Sounder Data
Note that this feature will only work if you have mounted an echo sounder transducer to the PI32. Make sure that a Graphic display presentation is active. Press the ENT button to open the Graphic setup dialogue.
Page 76: How To Set Up Marker Lines
Note that the echo sounder data will only appear if you have mounted an echo sounder transducer to the PI32. The following parameters will affect the way the marker lines are displayed: •...
Page 77 Operational procedures Access to the marker line parameters Make sure that a Graphic display presentation is active. Press the ENT button to open the Graphic setup dialogue. The Marker line parameter allows you to switch the marker line on or off for sensors S1, S2 and S3. Depth and Height marker lines The purpose of these marker lines is to provide an easy way to monitor the depth of the gear.
Page 78 Such feelers are often built into the echo sounder transducers. Ensure that a proper feeler is connected to the PI32. Set the marker line to On. Enter the preferred settings for Marker line thickness and Marker line delay.
Page 79: Special Features For Trawl Marker Lines
Height or Depth sensor on the headrope, and one Depth sensor on the footrope. However, if you only use one of these sensors, place it on the headrope. The PI32 will then manually draw the trawl opening markers for you provided that you enter the typical height of the trawl opening.
Page 80 If you have only one sensor, enter a value for Manual trawl marker. - This value must represent the actual height of your trawl opening, based on your knowledge about your gear. The information will be used by the PI32 to draw a second trawl marker line. Related topics →...
Page 81: How To Access Echo Sounder Parameters
Operational procedures How to access echo sounder parameters The built-in echo sounder is easily controlled from separate dialogues. • The Echo presentation setup dialogue controls the visual parameters, such as Range, Gain, White line and Expansion window. • The Echosounder setup dialogue controls the operational parameters, such as alarms, sound velocity and transducer selection.
Page 82: How To Use Visual Aids And Filters
Simrad PI32 How to use visual aids and filters When you use the echo sounder, several visual aids and filters are available to make the echoes easier to read and interpret. Ping to ping filter This function employs a filter which compares the echo information from one ping with the information from the previous ping.
Page 83 Operational procedures Scroll speed This function controls how fast the presentation shall scroll from right to left across the display. By defining this speed you also control the time scale. If you slow down the scroll speed, you will also increase the time between each echo sounder transmission (ping).
Page 84: How To Define Echo Sounder Range
• Range: This is the vertical depth range for the echo sounder. The PI32 also offers a Phased range function, where the Range is fixed, but the Range start is modified. The two parameters in question are located at the top of the parameter list.
Page 85 Operational procedures You will see that different ranges are used, but the value for the Range start is always added. For example, if you set the Range start to 30 meters, and then select the 250 meters range, the total range achieved is from 30 to 280 meters. The upper 30 meters are however not shown in the echogram.
Page 86: How To Zoom In On Bottom Echoes
Simrad PI32 How to zoom in on bottom echoes The Bottom Expansion functions allows you to zoom in on the echoes closest to the bottom. When this function is active, the echo sounder presentation is split in two. The upper part is the ordinary presentation, while the lower part shows the echoes just above the bottom.
Page 87: How To Zoom In On Pelagic Echoes
Operational procedures How to zoom in on pelagic echoes The VRM Expansion functions allows you to zoom in on echoes in the water column. When this function is active, the echo sounder presentation is split in two. The upper part is the ordinary presentation, while the lower part shows the expansion window with the echoes over and under a reference depth.
Page 88: How To Enable A-Scope Presentation
Simrad PI32 How to enable A-Scope presentation The A-Scope presentation provides the echo from the latest ping only. The strength of the returned signal from various depths in the water column are indicated by the horizontal deflections from the Y-axis. This presentation is very useful if you wish to search for single fish, as those echoes are hard to see on the regular echogram.
Page 89: How To Define Alarm Limits
Operational procedures How to define alarm limits The PI32 will provide a variety of audible and visible alarms to keep you posted when something occur. Observe the following procedures to set up an enable the most common alarms. For more detailed information about the setup pages, refer to the References chapter.
Page 90 The Shear alarm will be triggered if the temperature changes faster per minute than the value you have entered. Note: In order to enable these alarms, your PI32 must have the relevant temperature feeler fitted! Clearance alarms The clearance alarm provide you with an audible and visual warning if a trawl or another towed object either moves too close to the bottom, or lifts too far off the bottom.
Page 91 Operational procedures Verify that the echo sounder is operational. Press the MENU button to access the main menu. On the Setup menu, select Sensor alarm/calibration. Select minimum and/or maximum distance for the alarms, and activate each alarm separately. Press the ENT key to store the parameters and exit. The clearance alarm will take the current depth reading from the echo sounder and subtract the current depth reading from the Depth sensor.
Page 92: How To Select Menu Language
Simrad PI32 How to select menu language The menus on the PI32 can be provided in several different languages. Observe the following procedure to select menu language. For more detailed information about the setup pages, refer to the References chapter.
Page 93: How To Control Automatic Page Rotation
Operational procedures How to control automatic page rotation You can set up the PI32 to automatically leaf through the four display pages. Each page will then be shown a set time before the next page is brought up. Observe the following procedure to set up automatic page rotation.
Page 94: How To Restore Default Settings
Caution: If you choose to do a master reset, you will need to redefine every single parameter you have made on the PI32. This includes all echo sounder settings, sensor selections and setup, system interfaces and alarms. Related topics →...
Page 95: Practical Use Of The Sensors
For all other practical purposes the two types may be regarded as identical. The PI32 system will automatically adapt to and work with both types, and you can also use PS and PI sensors together.
Page 96: Sensor Configuration
MUST communicate on three different channels. • Other vessels near your use the same PI32 system (or a similar), and they have one or more of their sensors set up to the same communication channels as you have. This will create interference, as you will “read”...
Page 97 Changing the update rate It may be required to change the update rate on a sensor, that is how often it sends information back to the PI32 system. A high update rate will give frequent information updates, but the sensor will use more battery power. If you need your batteries to last as long as possible, you must consider lowering the update rate.
Page 98 Simrad PI32 You can select the communication channels between the PI Spread sensors and the vessel to suit your preferences. 857-164636 / Rev.A...
Page 99: Pi Bottom Contact Sensor
Sensors PI Bottom Contact sensor Purpose The PI Bottom Contact sensor detects if a trawl is accidentally lifted off the seabed, or a purse seine is touching the bottom. (A) = The trawl follows the bottom. The detection wire on the sensor is not released. (B) = The trawl has lifted off the bottom, and the detection wire is released.
Page 100 Simrad sensor charging documentation. Bottom Contact presentation On the PI32 display, the Bottom Contact sensor status is displayed with graphic symbols. Note that the timers count the total number of minutes the sensor has lost contact with bottom.
Page 101 Sensors • Normal (~5,3 sec): Recommended for normal fishing. • Slow (~33 sec): Recommended if maximum operational battery life before charging is required. The system will be more sensitive to bad communication conditions due to the slow data update. System configuration Sensor configuration: The sensor must be configured with a unique sensor number.
Page 102 Simrad PI32 Set up: Correct function requires that the length of the stay (F) and the detection chain (G) are trimmed with regard to each other and the gear in use. Standard delivery includes a 63 cm stay and 39 cm detection chain for use with 14 to 16 inch bobbins or rock hoppers (C).
Page 103: Ps Bottom Contact Sensor
Sensors PS Bottom Contact sensor Purpose The PS Bottom Contact sensor detects if a trawl is accidentally lifted off the seabed, or a purse seine is touching the bottom. (A) = The trawl follows the bottom. The detection wire on the sensor is not released. (B) = The trawl has lifted off the bottom, and the detection wire is released.
Page 104 Simrad sensor charging documentation. Bottom Contact presentation On the PI32 display, the Bottom Contact sensor status is displayed with graphic symbols. Note that the timers count the total number of minutes the sensor has lost contact with bottom.
Page 105 Sensors Normal (~5,3 sec): Recommended for normal fishing. Slow (~33 sec): Recommended if maximum operational battery life before charging is required. The system will be more sensitive to bad communication conditions due to the slow data update. System configuration Sensor configuration: The sensor must be configured with a unique sensor number.
Page 106 Simrad PI32 Set up: Correct function requires that the length of the stay (F) and the detection chain (G) are trimmed with regard to each other and the gear in use. Standard delivery includes a 63 cm stay and 39 cm detection chain for use with 14 to 16 inch bobbins or rock hoppers (C).
Page 107: Pi Catch Sensor
Sensors PI Catch sensor Purpose The PI Catch sensor detects when the trawl has been filled with fish. The sensor monitors the opening of the meshes in the cod end, and will be activated once the volume caught is enough to pull the detector wires.
Page 108 Simrad sensor charging documentation. Presentation On the PI32 display, the Catch sensor status is displayed with graphic symbols. The timers count the total number of minutes the sensor has been activated (red rectangle). If only predicted timer values exist, the timer characters are shown in grey.
Page 109 The Catch sensor can be configured (using the PI Configurator software) to act as a FA701 catch sensor. This will allow the sensor to be used with the Simrad FS trawl sonar. The communication channel on the FS sonar must be set up to correspond to the equivalent sensor number (1, 2 3 or 4).
Page 110 Simrad PI32 Mounting Location: Attach the sensor on top of the cod-end where the catch is to be monitored. As the cod-end fills, the net’s meshes will open pulling the detector wires and thus activating the sensor. Sensor attachment to a net with an approximate mesh size of 140 mm. The distance between the anchor points for the attachment rings and rubber straps will vary according to mesh size and sensitivity required.
Page 111 Sensors Sensitivity: The sensitivity of the Catch sensor is determined by the number of meshes separating the rubber straps. You can simulate this by stretching the net’s meshes to approximate the mesh opening estimated to trigger the sensor. Mark the location (with colored thread) for future references.
Page 112: Ps Catch Sensor
Simrad PI32 PS Catch sensor Purpose The PS Catch sensor detects when the trawl has been filled with fish. The sensor monitors the opening of the meshes in the cod end, and will be activated once the volume caught is enough to pull the detector wires.
Page 113 Simrad sensor charging documentation. Catch presentation On the PI32 display, the Catch sensor status is displayed with graphic symbols. The timers count the total number of minutes the sensor has been activated (red rectangle). If only predicted timer values exist, the timer characters are shown in grey.
Page 114 The Catch sensor can be configured (using the PI Configurator software) to act as a FA701 catch sensor. This will allow the sensor to be used with the Simrad FS trawl sonar. The communication channel on the FS sonar must be set up to correspond to the equivalent sensor number (1, 2, 3 or 4).
Page 115 Sensors Mounting Location: Attach the sensor on top of the cod-end where the catch is to be monitored. As the cod-end fills, the net’s meshes will open pulling the detector wires activating the sensor. Sensor attachment to a net with an approximate mesh size of 140 mm. The distance between the anchor points for the attachment rings and rubber straps will vary according to mesh size and sensitivity required.
Page 116: Pi Depth Sensor
Simrad PI32 PI Depth sensor Purpose The PI Depth sensor monitors the current depth of the net, as well as the rate of any depth changes. All measurements are related to the surface. (A) = Two Depth sensors are mounted to the ground rope to monitor the depth.
Page 117 Simrad’s sensor charging documentation. Numerical presentation On the PI32 display, the depth is displayed in the numeric display. The descending or ascending rate is shown in units per minute supported by an arrow indicating the direction. In order...
Page 118 Fast update rate. If you use more than one sensor, you must set them up to operate in different channels. Note: The sensor and the PI32 system setup must correspond, otherwise the communication will not work. To change the sensor setup (channel selection), use the PI Configurator utility.
Page 119 Sensors Mounting Purse seine: In order to secure stable communication with the vessel’s hydrophone, it is very important that the sensor is allowed to hang freely with the top end pointing towards the surface during shooting and pursing. Attach the sensor to a standard purse ring with two separate wires (A).
Page 120 Simrad PI32 Tuna purse: The sensor must not be attached to the footrope wire, but to the foot-rope chain. Use a safety wire in addition in case the sensor is ripped off the net. Trawl or Danish seine: The depth sensor is normally attached to the headrope (A).
Page 121: Ps Depth Sensor
Sensors PS Depth sensor Purpose The PS Depth sensor monitors the current depth of the net, as well as the rate of any depth changes. All measurements are related to the surface. (A) = Two Depth sensors are mounted to the ground rope to monitor the depth.
Page 122 Simrad’s sensor charging documentation. Numerical presentation On the PI32 display, the depth is displayed in the numeric display. The descending or ascending rate is shown in units per minute supported by an arrow indicating the direction. In order...
Page 123 If you use more than one sensor, you must set them up to operate in different channels. Note: The sensor and the PI32 system setup must correspond, otherwise the communication will not work. To change the sensor setup (channel selection), use the PI Configurator utility.
Page 124 Simrad PI32 Mounting Purse seine: In order to secure stable communication with the vessel’s hydrophone, it is very important that the sensor is allowed to hang freely with the top end pointing towards the surface during shooting and pursing. Attach the sensor to a standard purse ring with two separate wires (A).
Page 125 Sensors Tuna purse: The sensor must not be attached to the footrope wire, but to the foot-rope chain. Use a safety wire in addition in case the sensor is ripped off the net. Trawl or Danish seine: The depth sensor is normally attached to the headrope (A).
Page 126: Pi Height Sensor
Simrad PI32 PI Height sensor Purpose The PI Height sensor monitors the current height of the trawl, as well as the rate of any height changes. All measurements are related to the bottom. (A) = The PI Height sensor is normally...
Page 127 Simrad’s sensor charging documentation. Numerical presentation On the PI32 display, the distance to the bottom is displayed in the numeric display. If the height is increasing or decreasing, this is shown with two arrows and the variation in meters per second.
Page 128 On delivery, all Height sensors are configured in Channel 14 and with Fast update rate. Note: The sensor and the PI32 system setup must correspond, otherwise the communication will not work. To change the sensor setup (channel selection), use the PI Configurator utility.
Page 129 Ensure that you mount the sensor with the reverse side (D) and the echo sounder transducer (E) pointing towards the bottom! The SIMRAD print on the sensor (C) must point up towards the water surface! Mounting: Secure the two forward fastening lugs (A) using two snap hooks and rope.
Page 130: Pi Rip Sensor
Simrad PI32 PI Rip sensor Purpose The PI Rip sensor is identical to the PI Catch, and it must be regarded as a second application for the Catch sensor. The PI Rip sensor will monitor if your net is damaged and ripped apart due to obstructions or foreign objects on the seabed.
Page 131 Simrad’s sensor charging documentation. Numeric presentation On the PI32 display, the Rip sensor status is displayed with graphic symbols. The timers count the total number of minutes the sensor has been activated (red rectangle). If only predicted timer values exist, the timer characters are shown in grey.
Page 132 Note: The sensor and the PI32 system setup must correspond, otherwise the communication will not work. To change the sensor setup (channel selection), use the PI Configurator utility.
Page 133 Sensors Mounting Location: Place the sensor where you wish to check the net condition. This is normally close to the footrope at the center of the net. If the net is torn, the slack will release one or both of the sensor’s detection wires.
Page 134 Simrad PI32 Attachment: The sensor’s orientation towards the vessel is maintained by the steel and nylon attachment rings. The number of meshes the attachment rings are supported between must be restricted to avoid unnecessary stress on the sensors fastening lugs. The use of both nylon and steel attachment rings is required to secure the sensor lugs if excessive forces are applied on them.
Page 135: Pi Spread And Remote Sensors
Sensors PI Spread and Remote sensors Purpose The PI Spread and Remote sensors measure the physical distance between the trawl doors. Note: Each Spread sensor can be configured to communicate with one of two remote sensors; Remote 1 or Remote 2. Label the Spread sensor accordingly, and ensure that you only use the sensors in the correct pairs.
Page 136 Note: Note that charging sensors at sub-zero temperatures can create explosive gasses. Simrad AS assumes no liability for the improper charging of sensors or the use of chargers not specified in Simrad’s sensor charging documentation.
Page 137 Sensors Numerical presentation On the PI32 display, the distance between the trawl doors is displayed in the numeric display. If the distance is increasing or decreasing, this is shown with two arrows and the variation in meters per second. When the readings are stable, the digits are shown in black colour.
Page 138 Simrad PI32 • Slow (~34 sec): Recommended to monitoring a stable situation over time, focus on door not falling over, broken sweep lines etc. during the tow. The system will be more sensitive to bad communication conditions due to slow data update.
Page 139 Sensors Top view: (A) = Starboard door (B) = Port door (C) = Communication link to vessel’s hydrophone (D) = Angle of attack (E) = Direction of tow (F) = Transverse communication link (R) = PI Remote sensor in its adapter (S) = PI Spread sensor in its adapter Sacrificial water switch sensor...
Page 140: Pi Twin Spread
Simrad PI32 PI Twin Spread Purpose The PI Twin Spread is used with two Remote sensors to measure the physical distance between the trawl doors during twin trawl operations. (A) = The PI Twin Spread sensor communicates with the PI system on the vessel.
Page 141 Note: Note that charging sensors at sub-zero temperatures can create explosive gasses. Simrad AS assumes no liability for the improper charging of sensors or the use of chargers not specified in Simrad’s sensor charging documentation.
Page 142 Simrad PI32 Numerical presentation On the PI32 display, the distances between the trawl doors are displayed in the numeric display. Two rectangles are used, one for each distance. If the distance is increasing or decreasing, this is shown with two arrows and the variation in meters per second.
Page 143 Twin Spread 2 set-up you must re-configure a Twin Spread 1 sensor using the PI Configurator utility. Note: The Twin Spread sensor and the PI32 system setup must also correspond, otherwise the communication will not work. The sensor update rate controls how often the sensor reads and reports the door spread.
Page 144 Simrad PI32 Mounting The Spread and Remote sensors must be mounted in special adapters on each trawl door and on the centre clump. These adapters must be installed aforehand. Detailed information on how to install the adapters are provided with the installation kit.
Page 145: Pi Temperature Sensor
Sensors PI Temperature sensor Purpose The PI Temperature sensor monitors the current water temperature at the chosen location on the purse seine or trawl. (A) = The sinking rate of the net is monitored by two Depth sensors (B) = One Temperature sensor is mounted on the footrope to monitor the location of the thermo-cline.
Page 146 +10 to +25° C. Note that charging sensors at sub-zero temperatures can create explosive gasses. Simrad AS assumes no liability for the improper charging of sensors or the use of chargers not specified in Simrad’s sensor charging documentation.
Page 147 Sensors Temperature presentation On the PI32 display, the temperature is displayed in the numeric display. If the temperature is falling or rising, this is shown with an arrow. When the readings are stable, the digits are shown in black colour. When the values are predicted, the digits are grey, and if the contact with the sensor is lost, the characters *.* * are...
Page 148 Simrad PI32 System configuration Sensor configuration: The sensor must be configured with a unique sensor number. Select channel number according to the sensor’s configuration. Write down the configuration for future reference. Status & Receiver: The Interference filter must be switched on.
Page 149 Sensors Mounting Purse seine: In order to secure stable communication with the vessel’s hydrophone, it is very important that the sensor is allowed to hang freely with the top end pointing towards the surface during shooting and pursing. Attach the sensor to a standard purse ring with two separate wires (A).
Page 150 Simrad PI32 Tuna purse: The sensor must not be attached to the footrope wire, but to the foot-rope chain. Use a safety wire in addition in case the sensor is ripped off the net. Trawl or Danish seine: The sensor is normally attached to the headrope.
Page 151: Ps Temperature Sensor
Sensors PS Temperature sensor Purpose The PS Temperature sensor monitors the current water temperature at the chosen location on the purse seine or trawl. (A) = The sinking rate of the net is monitored by two Depth sensors (B) = One Temperature sensor is mounted on the footrope to monitor the location of the thermo-cline.
Page 152 +10 to +25°C. Note that charging sensors at sub-zero temperatures can create explosive gasses. Simrad AS assumes no liability for the improper charging of sensors or the use of chargers not specified in Simrad’s sensor charging documentation.
Page 153 Sensors Temperature presentation On the PI32 display, the temperature is displayed in the numeric display. If the temperature is falling or rising, this is shown with an arrow. When the readings are stable, the digits are shown in black colour. When the values are predicted, the digits are grey, and if the contact with the sensor is lost, the characters *.* * are...
Page 154 Simrad PI32 Mounting Purse seine: In order to secure stable communication with the vessel’s hydrophone, it is very important that the sensor is allowed to hang freely with the top end pointing towards the surface during shooting and pursing. Attach the sensor to a standard purse ring with two separate wires (A).
Page 155 Sensors Tuna purse: The sensor must not be attached to the footrope wire, but to the foot-rope chain. Use a safety wire in addition in case the sensor is ripped off the net. Trawl or Danish seine: The sensor is normally attached to the headrope.
Page 156: Sensor Chargers
Simrad PI32 SENSOR CHARGERS Overview Two different battery chargers can be used to charge the PI and PS sensors: • PI Charger • PS30 Charger Even though both chargers can be used to charge any of the sensors (except the PI Height sensor), only the PI Charger will provide fast and intelligent charging of the PI sensors.
Page 157: Pi Charger
Sensor chargers PI Charger Purpose The PI Charger is an intelligent battery charger for fast and secure charging of the PI sensors. The charger will automatically set up the correct charging current depending on the sensor type and the battery temperature. Even though the PI Charger is designed for fast charge of the PI sensors, it can also charge the PS sensors, but only at normal charge rate.
Page 158 Warning: Charging a sensor at sub-zero temperature might develop explosive gases representing a potential danger. Simrad assumes no liability for improper charging, or the use of other chargers than those approved by Simrad. Automatic configuration The charger communicates with the sensor at regular intervals.
Page 159: Ps30 Charger
+50°C or below 0°C! Warning: Charging a sensor at sub-zero temperature might develop explosive gases representing a potential danger. Simrad assumes no liability for improper charging, or the use of other chargers than those approved by Simrad. 857-164636 / Rev.A...
Page 160 Simrad PI32 General guidelines Operational time and service life of the sensor’s NiCd battery depends on proper use and regular charging. Observe the following precautions, as these will have an influence on the battery performance: • Observe the charging temperatures.
Page 161: Menu System
Menu system MENU SYSTEM The PI32 is controlled using a small meny system. Although several shortcuts exist, the main functions and setup parameters can be accessed from the main menu. To access the main menu, press the MENU button. Topics →...
Page 162: The Main Menu
→ Echo sounder setup, page 157 Setup On the Setup menu, you can access setup parameters to control the operation of the PI32. Note that additional parameters are accessed directly from the presentations by pressing the ENT button. → Speed alarm, units and language: →...
Page 163 Menu system → Interface setup remote/alarm, page 167 → Sensor alarm/calibration, page 177 → Sensor setup, page 179 → Receiver setup, page 174 → Display colour, page 172 → Master reset, page 159 857-164636 / Rev.A...
Page 164: References
PI32 system. You do not need to read and understand thic chapter to operate the PI32, but the information may guide you to a more efficient use. The setup pages are provided in alphabetical order. Some are accessed from the Setup menu, others directly from the display presentations by means of the ADJ button.
Page 165: Depth Calibration
References Depth calibration This function is used to enable calibration of the PI32 Depth sensor. To access this function, press the MENU button to open the main menu. Then, open the Setup menu, and select Sensor alarm/calibration. The Depth calibration feature will calibrate the current depth of the Depth sensor to one -1- meter.
Page 166: Echo Presentation Setup
Echo presentation setup These settings are used to set up the echo sounder presentation parameters on the PI32. The operational parameters are set up using the Echo sounder setup dialogue. To access the parameters, press the ENT button when you have an echo sounder presentation on the screen.
Page 167 Sound speed: This parameter allows you to fine tune the performance of the PI32 echo sounder to the speed of sound in the water. However, in most cases, the speed is not known, and this parameter is not important at all when operating in shallow waters.
Page 168 Simrad PI32 Note: The echo sounder frequency you choose must be supported by the transducer you have installed! Related topics → How to define the echo sounder range, page 72 → Echosounder setup, page 157 → Graphic setup, page 160 →...
Page 169: Echo Sounder Setup
References Echo sounder setup These settings are used to set up the operational parameters for the PI32 echo sounder. To access dialogue, press the MENU button to access the main menu. Then, select Echo sounder setup on the Echo menu.
Page 170 OFF (to observe the ambient sea noise), SHORT, MEDIUM, LONG or AUTO. In most cases, select AUTO. The PI32 will then automatically choose the pulse length depending on your current depth range. If you choose to try a manual mode, try long pulse lengths when you operate in deeper waters, and shorter pulses with higher frequency in shallower waters.
Page 171: Factory Presets
References Factory presets This function allows you to restore the PI32 parameters to the default settings chosen by Simrad. To access this function, press the MENU button top open the main menu. Open the Setup menu, and select Master reset.
Page 172: Graphic Setup
Simrad PI32 Graphic setup These settings are used to set up the PI32 parameters related to the Graphic display. To access the parameters, press the ENT button when you have a Graphic display on the screen. Superimpose echo sounder: When activated, the presentation from the echo sounder is added to the graphic display.
Page 173 References Marker line: Certain sensors will provide information that can be superimposed on the graphic display. This parameter allows you to switch up to three marker lines on and off. The identifications S1 to S3 relate to sensors 1, 2 and 3, and if the sensor in question does not provide information that can be superimposed, the related switch can not be switched on.
Page 174: Interface Setup Nmea
Then, select Interface setup NMEA on the Setup menu. Background By means of the connectors on the rear side of the PI32 cabinet, it can communicate with several peripheral devices. This is useful, as it allows you to export and import information to and from these devices.
Page 175 References Input By default, the PI32 is only equipped with one NMEA interface connector. For this reason, you can only receive data from one peripheral device. However, this device may provide you with more than one type of information. For example, GPS systems...
Page 176 Simrad PI32 Output The PI32 is only equipped with one NMEA connector, but you can still export several information types, as these will be transmitted sequentially using different telegram types. Whether this information can be accepted and interpreted on your peripheral device(s) at the other end of the cable depends on the functionality of this device.
Page 177 References Applicable telegram formats The following NMEA telegram formats are used by the PI32. APB = Autopilot Sentence ”B”. The information provided includes Status, Cross track error magnitude, Direction to steer, Cross track units, Bearing origin to destination, Destination waypoint identification, Bearing, and Heading to steer.
Page 178 Simrad PI32 VTG = Track made good and Ground speed. The information provided inludes Track degrees (true and magnetic) and Speed (in knots and kilometers per hour). XTE = Cross-Track Error, Measured. The information provided inludes Status, Cross track error and Direction to steer.
Page 179: Interface Setup Remote/Alarm
RMA, RMC or VTG. Then, switch the interface on or off. Navigation: The telegrams used to receive navigational data are fixed, and the PI32 will receive APB, RMB and XTE telegrams. Switch the interface on or off. Water temperature: The telegram used to receive water temperature data is fixed, and the PI32 will receive this information using the MTW telegram.
Page 180: Navigation Setup
Simrad PI32 Navigation setup These settings are used to set up the PI32 parameters related to the navigation display presentation. To access the parameters, press the ENT button when you have the navigation display in view. Course & bearing as: Select True or Magnetic reading.
Page 181: Numeric Setup
References Numeric setup These settings are used to set up the PI32 parameters related to the Numeric display. To access the parameters, press the ENT button when you have the Numeric display presentations in view. Data window 1/2/3: Select which sensor data to appear in the three numeric presentations.
Page 182: Offset Adjust
Simrad PI32 Offset adjust These settings are used to set up offset values for the Depth and Spread sensors. To access the parameters, press the MENU button to open the main menu. Then, open the Setup menu and select Sensor alarm/calibration.
Page 183: Page Setup
References Page setup These settings are used to set up the PI32 parameters related to the page; automatic page rotation and menu language. To access the parameters, press the MENU button to access the main menu. Then, open the Setup menu and select Speed alarm, units &...
Page 184: Palette Setup
Simrad PI32 Palette setup These settings are used to set up the PI32 parameters related to presentation colours. The information provided by the PI32 can be presented using one out of nine palettes. In each palette, the text and background colours are defined.
Page 185: Position Display Setup
References Position display setup These settings are used to set up the PI32 parameters related to the position display presentation. To access the parameters, press the ENT button when you have the Position display in view. Log 1/2: Use this parameter to reset the two distance logs.
Page 186: Receiver Setup
Setup menu. The Receiver setup parameters have a major influence on the PI32 performance. The default settings are those we have found to be the best for general use, but for individual installations optimized settings may enhance the performance.
Page 187 References Sensor filter: The PI32 is designed to quickly update data. After the sensors have been submerged, the receiver requires only three consecutive pings from individual sensors to calculate and display their respective information. However, if you experience problems with the reception, you may also try this filter: it will average the data received from the sensors.
Page 188 If the Detection Threshold (DT) value is set higher than 28 dB, all signals will be prevented from being detected. Max shooting speed: The PI32 has a built in doppler compensation function which is configured using this parameter. The parameter and related function is however only relevant if sensor data is desired while the purse seine is being deployed.
Page 189: Sensor Alarms
References Sensor alarms These settings are used to set up the PI32 parameters related to sensor alarms. To access the parameters, press the MENU button to open the main menu. Then, open the Setup menu, and select Sensor alarm/calibration. Each sensor has an individual alarm setting, and you can also trigger alarms to warn you about sudden temperature changes and shallow water.
Page 190 Simrad PI32 Clearance pre-warning: These alarms are used to warn you if a trawl or another towed object either moves too close to the bottom, or lifts too far off the bottom. You must have the echo sounder switched on to use this alarm. To enable it, set the...
Page 191: Sensor Setup
The settings you choose for update rate and communication channel must be identical to the settings in the relevant sensor. If these settings are not matched, your PI32 will not be able to read the information from the sensor! Related topics →...
Page 192: Speed Setup
Simrad PI32 Speed setup These settings are used to set up the PI32 parameters related to speed. To access the parameters, press the MENU button to access the main menu. Then, select Speed alarm, units & language on the Echo menu.
Page 193: Surface Temperature Setup
References Surface temperature setup These settings are used to set up the PI32 presentation parameters related to the surface temperature presentation. To access the parameters, press the ENT button when you have a Surface temperature display in view. Temperature scale max/min: Use these settings to define the maximum and minimum values in your temperature scale.
Page 194: Trawl Info Setup
Simrad PI32 Trawl info setup These settings are used to set up the PI32 parameters related to the trawl presentations on the Graphic display. When enabled, marker lines providing trawl depth information will be superimposed on the display. To access the parameters, press the ENT button when you have a graphic display in view.
Page 195: Units Setup
References Units setup These settings are used to set up the PI32 parameters related to units. To access the parameters, press the MENU button to access the main menu. Then, select Speed alarm, units & language on the Setup menu.
Page 196: Pi Configurator
Simrad PI32 PI CONFIGURATOR Purpose The purpose of the PI Configurator utility is to be able to configure sensors so that they can operate on different communication channels. Several PI equipped vessels may then operate simultaneously in the same area without interference.
Page 197: Basic Information
PI Configurator Basic information Default sensor settings PI and PS sensors are delivered from Simrad configured with common default settings. When required, the individual sensors may be re-configured with regard to: • Communication channel • LED control • Ping control •...
Page 198 Simrad PI32 Available equipment The following is available from Simrad: • User Guide (857-164924) • Software (889-204037) • Programming cable for stationary PCs (380-204624) • Programming cable for portable PCs (380-208429) • Service hydrophone (314-204480) The configuration equipment is also is available in kits: •...
Page 199: About Sensor Configuration
PI Configurator About sensor configuration All sensors are provided from the factory with pre-defined communication channels and update rates. Sensor Com.channel Update rate PI Bottom Contact Normal PI Catch Normal PI Depth (300 m) Fast PI Depth (600 m) Fast PI Depth (1000 m) Fast PI Height...
Page 200 • A high update rate will give you frequent information updates, but the battery will run out faster. All sensors are provided from Simrad with a default update rate setting. In some cases you may find that this update rate does not suit your operational needs.
Page 201: Main Dialogue Description
PI Configurator Main dialogue description Observe the illustration and descriptions below. Note that the apperance of function buttons will differ depending on the sensor type connected to the application. When functions are unavailable, the fields are identified accordingly with a shaded appearance.
Page 202 Simrad PI32 Button/Function Terminate communication Click to disconnect the sensor from the PC. Message field Displays program and sensor data. Communication channel Select channel number to be uploaded to the sensor. If a Twin Spread sensor is connected, two communication channels must be defined.
Page 203: Operational Procedures
PI Configurator Operational procedures Observe the following procedures. → How to perform software installation, page 192 → How to interface the sensor, page 193 → How to perform basic sensor configuration, page 194 → How to set up a Twin Spread system, page 195 →...
Page 204 Simrad PI32 Software installation Observe the following procedure to install the PI Configurator software on a stationary or portable computer. Note that the computer must have either Microsoft WindowsE 2000 or Microsoft WindowsE XP operating system. You must also have the Winzip utility installed on your computer.
Page 205 PI Configurator How to interface the sensor Before you can configure the sensor, you need to connect it to the computer. Observe the procedure below. Start the PI Configurator utility. Plug the programming cable into one of computer’s COM ports (COM1 is recommended). Ensure that the sensor to be connected is switched off.
Page 206 Simrad PI32 How to perform basic configuration Once the sensor is connected to the computer, and you have established communication, you can use the PI Configurator utility to change the basic sensor parameters. Click the Read Senor Data button. - Observe that the current sensor configuration parameters are displayed in the message field.
Page 207 PI Configurator How to configure a Twin Spread system This procedure describes hot to set up a Twin Spread system using one Twin Spread sensor and two Remote sensors. Setting up the Twin Spread sensor Connect the Twin Spread sensor to the PI Configurator. Press Establish communication with Sensor.
Page 208 Simrad PI32 Setting up the second Remote sensor Connect the second Remote sensor to the PI Configurator. Press Establish communication with Sensor. - Observe that the current sensor configuration parameters are displayed in the message field. Use the spin box next to the Number label to define the sensor’s number in the Twin Spread system.
Page 209 PI Configurator How to upload factory settings Once the sensor is connected to the computer, and you have established communication, you can use the PI Configurator utility to upload the applicable sensor’s factory settings. Click the Read Senor Data button. - Observe that the current sensor configuration parameters are displayed in the message field.
Page 210: References
Simrad PI32 References The features available when using PI Configurator software depend which mode it is in (Standard or Professional) and the type of sensor that is interface. All commands are described here, and they are listed in alphabetical order.
Page 211 PI Configurator Communication Channel This parameter allows you to redefine the sensor’s transmission channel (1 to 30). Sensors send information using specific frequencies, each designated as an individual channel. PI and PS sensors have 30 channels to choose from, and the FA701 sensors have four. The frequency range of these channels are of from 43.5 to 49.5 kHz for PI and PS systems, and 70 to 80 kHz for FA710 systems.
Page 212 Simrad PI32 Communication Port Setup This button opens the Com Port Setup dialogue. The integrated slider bar is used to designate which COM port (COM1 to COM8) the programming cable is plugged into. COM1 is the factory default setting and recommended parameter.
Page 213 PI Configurator Configure Sensor This button is used to re-program the currently interfaced sensor with the new parameters selected (those presently displayed). This operation can not be “undone” however, the sensor’s previous status information and parameter configuration is still available in the main dialogue box and may be re-entered if necessary.
Page 214 Simrad PI32 Data Update Rate This parameter is used to select an interfaced sensor’s data update rate. Note: This is a key parameter. Unless the data update rate defined in the sensor matches the rate defined on the host PI system, the...
Page 215 PI Configurator Establish Communication With Sensor This button initiates contact between the computer and a well charged sensor by sending it a ”wake-up” command. Once two-way communication is established the following occurs: • The indicator lamp (in the lower right-hand corner of the dialogue) will be turned on and off every two seconds.
Page 216 Simrad PI32 Factory Default This button is used to restore a sensor’s factory default values, according to the type of sensor currently interfaced. Factory default settings include: • Sensor Communication Channel • LED control • Ping control • Data Update rate •...
Page 217 PI Configurator Help This button opens the on-line Help. The on-line help include general information concerning the use of PI Configurator software and sensor interface. To operate, click the Help button to open the on-line help. To access context sensitive help, click the right mouse button over a given button or parameter.
Page 218 Simrad PI32 Language This button opens the Language dialogue. The dialogue allows you to select operational language by clicking on one of the flag icons. Clicking an icon will convert the PI Configurator’s buttons, information, help functions and interfaced sensor data to the respective language.
Page 219 PI Configurator LED Control This parameter can only be accessed in the Professional mode. The dialogue box is used to control the behaviour of the interfaced sensor’s internal LED during normal operation. LED behaviour in both the charge and communication modes can not be altered.
Page 220 Simrad PI32 Message field This message field displays present and past configuration data, communication status, error messages and other information. Configured parameters can not be “undone” however, the previous parameter configuration is still available in the main dialogue box and may be re-entered if necessary.
Page 221 PI Configurator Number This box allows you to define the identification number for the currently connected Remote sensor. This is a key parameter when you set up a Twin Spread system. Related topics → How to set up a Twin Spread system, page 195 857-164636 / Rev.A...
Page 222 Simrad PI32 Ping control This parameter is only available for depth sensors, and can only be accessed in the Professional mode. The dialogue box is used to control when a sensor will “ping” (transmit an acoustic signal). For example, it is possible to...
Page 223 PI Configurator Quit Click this button to close the PI Configurator utility. 857-164636 / Rev.A...
Page 224 Simrad PI32 Read Sensor Data This button requests that configuration data be sent from the interfaced sensor to the PC. When the Read Sensor Data button is clicked, the sensor will download information to the PC. This data is then used to populate the message field just as when the Establish Communication with Sensor button is clicked.
Page 225 PI Configurator Remote This parameter is only available for Spread, Twin Spread and Remote sensors. The dialogue box allows selection of the channels used to communicate between Spread and the Remote sensors. Note: These are key parameters when you work with Spread and Remote sensors.
Page 226 Simrad PI32 Sensor Type This parameter is to be configured in accordance with the sensor’s label and can only be accessed in the Professional mode. The dialogue box is used to select which of the sensor’s internal programs to run when activated. When using the PI Configurator in the Standard mode, it will only display the type of sensor interfaced.
Page 227 PI Configurator Serial number This text box displays the interfaced sensor’s serial number. It can not be re-configured. This feature is not available for PS sensors. 857-164636 / Rev.A...
Page 228 Simrad PI32 Show Channel At Startup This dialogue box controls weather or not the interfaced sensor will flash a channel identification code using its internal LED when first energized. When Enabled is selected, the sensor will flash its presently configured communication channel number at startup when in the normal mode (not in the charge or communication modes).
Page 229 PI Configurator Examples Example of channel number 16 at startup (below): (1) = A one second “long flash” (2) = A start ”flash” (3) = One “quick flash” (first digit of 16 is 1) (4) = A start ”flash” (5 - 10) = Six ”quick flashes” (second digit of 16 is 6) Normal operation starts Example of channel 2 at startup (below): (1) = A one second flash...
Page 230 Simrad PI32 Terminate Communication Press this button to terminate the serial data flow between the sensor and the computer. Operation Press the button to terminate the communication, then disconnect the cable. If you disconnect the cable before you terminate the data flow, the PI Configurator will issue a error message.
Page 231: Maintenance
PI Configurator Maintenance This chapter contains information related to maintenance, setup and troubleshooting. Topics → Programming modes, page 220 → Making a programming cable, page 221 → Troubleshooting, page 222 857-164636 / Rev.A...
Page 232 Available modes The PI Configurator utility has two programming modes: • Standard - default mode, described in this manual. • Professional - for use by Simrad personnel only. Caution: The use of PI Configurator software in the Professional mode is for qualified Simrad personnel only. Improper...
Page 233 PI Configurator Making a programming cable Should a Simrad programming cable not be available, it is possible to make an adequate substitution as described below. It is only possible to make programming cables for stationary computers. If you wish to use a portable computer the cable must be ordered from Simrad.
Page 234 Simrad PI32 Troubleshooting Most problems are easily solved. Troubleshoot interface, configuration or other complications by checking the following: • The interfaced sensor is sufficiently charged. • The correct PI sensor programming cable is used and in good condition • The PI sensor programming cable is connected to the PC’s COM port correctly.
Page 235: Sensor Test Procedures
Sensor test procedures SENSOR TEST PROCEDURES Overview Using the PI Configurator application, you can test the operational status of each sensor. In the following, you will find the test procedures. Note that PI and PS sensors are tested using the same procedures. Topics →...
Page 236: Bottom Contact Test Procedure
Simrad PI32 Bottom Contact test procedure Tools and equipment required • Multimeter • A small piece of wire • PI Service Hydrophone (Order no. 314-204480) • PI System Initial check and setup identification Keep the area between the negative charging lug (A) and the water detector (B) clean to reduce the risk of activating the sensor.
Page 237 Sensor test procedures (4) = A second start flash: This signals that the second digit of the channel number is next. (5) = None to nine short flashes: The number of short flashes signifies the second digit of the configured channel number.
Page 238 Switch on the vessel’s echo sounders and other hydroacoustical equipment used during normal fishing operations. Switch the PI32 interference filter on and off, and observe the numeric display. If the interference symbol is not shown when the filter is off, leave the interference filter switched off to increase the system’s range and...
Page 239: Catch Sensor, Test Procedure
Sensor test procedures Catch sensor, test procedure Tools and equipment required • Multimeter • A small piece of wire • PI Service Hydrophone (Order no. 314-204480) • PI System Initial check and setup identification Keep the area bteween the negative charging lug (A) and the water detector (B) clean to reduce the risk of activating the sensor.
Page 240 Simrad PI32 (3) = None, one, two or three short flashes: The number of short flashes signifies the first digit of the configured channel number. (4) = A second start flash: This signals that the second digit of the channel number is next.
Page 241 Switch on the vessel’s echo sounders and other hydroacoustical equipment used during normal fishing operations. Switch the PI32 interference filter on and off, and observe the numeric display. If the interference symbol is not when the filter is off, leave the interference filter switched off to increase the system’s range and performance.
Page 242: Depth Sensor, Test Procedure
Simrad PI32 Depth sensor, test procedure Tools and equipment required • Multimeter • A small piece of wire • PI System Initial check and setup identification Keep the area between the negative charging lug (A) and the water detector (B) clean to reduce the risk of activating the sensor.
Page 243 Check that the depth read-out on the PI32 corresponds to the actual measured depth at which the sensor is suspended. - If these values vary, calibrate the PI32 depth offset. The procedure is described below. Hoist and lower the sensor in the water, and observe that the depth readout changes accordingly.
Page 244 Simrad PI32 Switch the PI32 interference filter on and off, and observe the numeric display. If the interference symbol is not shown when the filter is off, leave the interference filter switched off to increase the system’s range and performance.
Page 245: Height Sensor, Test Procedure
Sensor test procedures Height sensor, test procedure Tools and equipment required • Multimeter • A small piece of wire • A reference echo sounder • PI System Initial check and setup identification Keep the area between the negative charging lug (A) and the water detector (B) clean to reduce the risk of activating the sensor.
Page 246 - If the interference symbol is not displayed, leave the interference filter switched off to increase the system’s range and performance. Use the PI32 Status display to monitor the sensor’s signal strength. - If the interference filter is activated, the spectrum...
Page 247 Sensor test procedures Switch the PI32 interference filter on and off, and observe the numeric display. If the interference symbol is not shown when the filter is off, leave the interference filter switched off to increase the system’s range and performance.
Page 248: Spread & Remote Sensors Test Procedure
Simrad PI32 Spread & Remote sensors test procedure Tools and equipment required • Multimeter • A small piece of wire • PI Service Hydrophone (Order no. 314-204480) • PI System Initial check and setup identification On both sensor types, keep the area between the negative charging lug (A) and the water detector (B) clean to reduce the risk of activating the sensor.
Page 249 Sensor test procedures (4) = A second start flash: This signals that the second digit of the channel number is next. (5) = None to nine short flashes: The number of short flashes signifies the second digit of the configured channel number.
Page 250 Switch on the vessel’s echo sounders and other hydroacoustical equipment used during normal fishing operations. Switch the PI32 interference filter on and off, and observe the numeric display. If the interference symbol is not shown when the filter is off, leave the interference filter switched off to increase the system’s range and...
Page 251 Sensor test procedures Use a water-proof pen, write the sensor’s number, configured channel number and any other pertinent information on its label. - A dedicated form has also been provided in the front of the PI Operator Manual to record this information. Note: Do not write on the sensor! Such information may be misunderstood when future service or replacement is performed.
Page 252: Temperature Sensor, Test Procedure
Simrad PI32 Temperature sensor, test procedure Tools and equipment required • Multimeter • A small piece of wire • PI Service Hydrophone (Order no. 314-204480) • Waterproof thermometer • PI System Initial check and setup identification Keep the area between the negative charging lug (A) and the water detector (B) clean to reduce the risk of activating the sensor.
Page 253 Sensor test procedures (3) = None, one, two or three short flashes: The number of short flashes signifies the first digit of the configured channel number. (4) = A second start flash: This signals that the second digit of the channel number is next. (5) = None to nine short flashes: The number of short flashes signifies the second digit of the configured channel number.
Page 254 Switch on the vessel’s echo sounders and other hydroacoustical equipment used during normal fishing operations. Switch the PI32 interference filter on and off, and observe the numeric display. If the interference symbol is not shown when the filter is off, leave the interference filter switched off to increase the system’s range and...
Page 255: Technical Specifications
Technical specifications TECHNICAL SPECIFICATIONS This chapter provides the basic technical specifications. Topics → PI Sensors, page 243 857-164636 / Rev.A...
Page 256: Sensors
Simrad PI32 Sensors Specifications can be altered without prior notification. PI Bottom Contact • PI System: PI32, PI44 or PI54 • Update rates: - Fast: Every 3,2 second (approx.) - Normal: Every 5,3 second (approx.) - Slow: Every 33 second (approx.) •...
Page 257 - To 100% capacity: 4 hours • Charging time with PS Charger: - To 100% capacity: 16 hours PI Depth • PI Systems: PI32, PI44 or PI54 • Update rates: - Fast: Every 4,5 second (approx.) - Normal: Every 14 second (approx.) - Slow: Every 34 second (approx.)
Page 258 - To 100% capacity: 4 hours • Charging time with PS Charger: - To 100% capacity: 16 hours PI Height • PI System: PI32, PI44 or PI54 • Update rates: - Fast: Every 5,5 second (approx.) - Normal: Every 14 second (approx.) - Slow: Every 34 second (approx.)
Page 259 - To 100% capacity: 4 hours • Charging time with PS Charger: - To 100% capacity: 16 hours PI Temperature • PI Systems: PI32, PI44 or PI54 • Update rates: - Fast: Every 4,5 second (approx.) - Normal: Every 14 second (approx.) - Slow: Every 34 second (approx.)
Page 260 Simrad PI32 • Charging time with PI Charger: - To 70% capacity: 1 hour - To 100% capacity: 4 hours • Charging time with PS Charger: - To 100% capacity: 16 hours 857-164636 / Rev.A...
Page 261: Index
Operator manual INDEX The next pages provide an alphabetical index to this manual. Bottom expansion, How to: Operational procedures 75 A-Scope, How to: Operational procedures 77 Bottom trawl, Application example: Applications 24 A-SCP, Button description: Getting started 15 Parameter: References 176 Status: Display modes 40 C/B filter, Parameter: References 176 Alarm...
Page 262 Simrad PI32 DBK, NMEA Parameter: References 165 Display colours: References 173 Display presentations, Overview: Display DBS, NMEA Parameter: References 165 modes 28 DBT, NMEA Parameter: References 165 Display text in, Parameter: References 172 Default settings Door sensor, Parameter: References 183...
Page 263 Operator manual Graphic alarm Signal threshold: Operational procedures 71 Spread sensor offset: Operational procedures How to: Operational procedures 47 Parameter: References 170 Superimpose echo data on graphic display: Graphic display Operational procedures 64 Application example: Applications 27 Switch power on and off: Getting started 10 Description: Display modes 36 Trawl information: Operational procedures Graphic setup: References 161...
Page 264 Simrad PI32 Introduction: Getting started 13 Numeric setup: References 170 Manual gain, Parameter: References 176 Manual trawl marker, Parameter: References Offset adjust, Setup: References 171 Marker line, Parameter: References 162 Operator Unit, Description: System description 5 Marker line delay, Parameter: References 162...
Page 265 Operator manual How to: Operational procedures 73 Shear alarm, Parameter: References 178 Parameter: References 155 Signal threshold Range start, Parameter: References 155 How to activate: Operational procedures 71 Parameter: References 156 Receiver setup: References 175 Sound speed, Parameter: References 156 Remote sensor Speed, NMEA Parameter: References 164, Practical use: Sensors 124...
Page 266 Simrad PI32 Temperature sensor Water temperature, NMEA Parameter: References 164, 168 Numeric presentation: Display modes 35 Practical use (PI): Sensors 134 White line Practical use (PS): Sensors 140 How to activate: Operational procedures 72 Specifications: Technical specifications 248 Parameter: References 155...
Page 268 E 2005 Simrad AS ISBN 82-8066-059-3...
