Simrad PI50 - REFERENCE MANUAL REV A Reference Manual page 76

Simrad PI50
Note
The
Update Rate
comply to the update rate programmed into the sensor. If these do not match,
the communication will not work.
The default update rates for the various sensors are listed in chapter PI50
Sensors.
→ Default communication channels and update rates on page 190
To change the channel number on the sensor, use the PI Configurator utility.
→ PI Configurator on page 192
d Choose
Sensor Value Name
•
Sensor Value Name
sensor name listed in the
connected to the PI50 computer, you can click in the field, and enter another
name. You can also open the on-screen keyboard.
The
Sensor Value Name
dual sensor, you can enter two different names.
→ Sensor views on page 39
Example: If you have three PI Catch sensors on your trawl, you can name
them "Catch Rear", "Catch Middle" and "Catch Forward".
Choose
e
Channel Number
•
Channel Number
sensor and the PI50 system.
Note
The
Channel Number
you choose here must comply to the channel number programmed into the
sensor. If these do not match, the communication will not work. By default,
the channel number will match the factory setting.
If you use more than one sensors of the same type, the channel number of
one of the sensors must be changed to make it unique for the sensor. This
must be changed both in the actual sensor, and in the
during configuration.
The default communication channels for the various sensors are listed in
chapter PI50 Sensors.
To change the channel number on the sensor, use the PI Configurator utility.
→ Default communication channels and update rates on page 190
→ Changing a communication channel on page 191
→ PI Configurator on page 192
Observe the
f
• : Each sensor measuring spread and depth will have an offset value.
Offset
74
parameter is vital. The update rate you choose here must
.
: By default, the
Available Sensors
is used in the Sensor views. If you are setting up a
.
: This is the communication channel used between the
parameter is vital. The communication channel number
value.
Offset
is the same as the
Sensor Value Name
list. If you have a keyboard
Select Sensors
dialog
328458/A
